Technical Description
|
Dimension:
|
60*62*701mm
|
Mode of operation:
|
S1
|
|
Materials Impeller:
|
aluminum alloy
|
Bearing:
|
ball bearings
|
|
Materials Housing:
|
SPCC+S45C
|
Motor protection:
|
self-resetting TOP wired internally
|
|
Direction of rotation :
|
clockwise,seen on rotor
|
Air Flow:
|
155.38CFM/264M³/H
|
|
Number of Blades:
|
–
|
Static Pressure:
|
0.069inH2O/17.4Pa
|
|
Speed Control:
|
0~10VDC / PWM
|
Life Expectance:
|
50,000 Hours(L10)
|
|
Operating Voltage:
|
24 VDC
|
Operating Humidity:
|
5%-90% RH
|
|
Type of protection:
|
IP20
|
Signal Output:
|
FG (Frequency Generator)
|
|
Insulation class:
|
B
|
Authentication:
|
UL,CE,ROHS,CCC,ISO
|
Related Product
Parameter summary table
|
Model
|
Nominal voltage[VDC]
|
Speed (RPM)
|
Power input max(W)
|
Current max(A)
|
Sound pres level[dB(A)]
|
Perm amb temp[*c)
|
Electrical connection
|
|
CD24-F030A-EC-01
|
24
|
2600
|
4.08
|
0.17
|
35
|
-25 ºC ~ +60 ºC
|
D
|
|
CD24-F030A-EC-02
|
24
|
2600
|
4.08
|
0.17
|
35
|
-25 ºC ~ +60 ºC
|
D
|
|
CD24-F030A-EC-03
|
24
|
2550
|
4.8
|
0.2
|
42
|
-25 ºC ~ +60 ºC
|
D
|
|
CD24-F040A-EC-01
|
24
|
2200
|
5
|
0.21
|
38
|
-25 ºC ~ +60 ºC
|
D
|
