Fan Coil Unit, Ceiling, 340-1360m3

The fan coil unit listed here carries airflow 340-1360m3/h, type Fan Coil Unit, documented exactly as the manufacturer publishes it. Made by Shenzhen Monchrui Industry Development Co., Ltd. (9 years on the platform, typical reply ≤5h). For a binding price and lead time, send the volume you need and where it ships to.

Key Features of This Fan Coil Unit

• Operating Voltage: 230 VAC
• Heating Capacity: 1.7-10.8Kw
• Cooling Capacity: 1.1-7.2Kw
• Airflow: 340-1360m3/h
• Warranty: 1 Year
• Place Of Origin: Guangdong, China

Technical Specifications

Product Details

Product Overview

Control system

1 Wireless remote controller is standard; Wired wall controller is optional; Autoreset,operation mode control; with room sensor & coilsensor;

2 Daily timer or weekly timer

 3 Auto-diagnose,protection sand error codedisplay; jumpers configurations on electronic board

4 RS485 ModBus,master-slave network control-Optional

Design feature

1 Centrifugal Fan Well-known brand centrifugal fan with statically and dynamically balanced. 2 High Efficiency Coil Coil are made of copper tubes and high exchange surface area aluminum blue fins. 3 All coils are 100% tested against leaks by 30bar(3Mpa) air pressure. Drain Pan 4 Steel drain pan with powder coating for easy cleaning and corrosion resistance, anti-rust. The drain pan is insulated to prevent condensation water. 5 Drianpump 700mm head drain pump with no return valve is installed in the unit; an float switch inside as well to prevent from leaking.

PRODUCT SPECIFICATIONS

Model:MRCW*AC-AE(EE)						MRCW200 AC-AE	MRCW300 AC-AE	MRCW400 AC-AE
CFM						200	300	400
Air Flow Rate		High	m3/h	340	510	680
				Medium	m3/h	280	390	520
				Low	m3/h	180	260	350
Cooling	Total Capacity	High	kw	1.8	2.7	3.6
				Medium	kw	1.5	2.3	2.8
				Low	kw	1.1	1.4	2
		Water Flow Rate		L/H	345	465	620
		Water Pressure Drop		kPa	15	27	15
Heating	Heating Capacity	High	kw	2.7	4.2	5.4
		Heating Capacity	Medium	kw	2.5	3.5	4.2
		Heating Capacity	Low	kw	1.7	2.1	3.0
Power Supply					220V/1Ph/50Hz
Power Input				W	39	52	62
Current				A	0.18	0.24	0.27
Sound Pressure				dB(A)	37	39	41
Fan blower	Type			Centrifugal Fan
		Model		mm	YPB145-145
		Quantity			2
Dimensions	A		mm	700	900	1100
		B		mm	732	932	1132
Control					Wireless Remote Control(Wired  wall control is optional)
Net Weight				kg	15.9	19	23
Water Connection	in		inch	ZG3/4"
		out		inch	ZG3/4"
		Drian Pipe(OD)		mm	26
1.Cooling: inlet air temp. DB+27oC/WB+19.5oC, water inlet/outlet temp. +7oC/+12oC  2.Heating: +21oC, water inlet temp. +60oC; Same water flow rate as for the cooling

Product images

Recommend Products

Certifications

Exhibition

About Us

Monchrui

Shenzhen Monchrui Industrial Development Co., Ltd.As the member of HongKong Monchrui International Group in Mainland China, which was established in response to the "Belt and Road" and "Industrial Power" initiative in 2015, and the team with more than 15 years experience in HVAC field.The company is located in Shenzhen, China's high and new technology development and innovation forefront , mainly engaged in high quality and energy-saving HVAC products & accessories research & development, manufacturing, sales, application and professional service, and also is the communication platform between China and International market in this field business.Mission: Provide maximum value added service for our customers, to help our customers be more successful!Vision: Become a well-known international HVAC system solution enterprise.Position: One-stop professional HVAC system solution provider!

Ordering and Pricing

• Minimum order quantity: 1 set
• Volume pricing:
  • 1–19 set: US $219 / set
  • 20+ set: US $209 / set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this fan coil unit?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Can the fan coil unit be supplied for my local voltage?

The standard configuration is 230 VAC. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
