Aluminum Fan, GKW, 800mm, Wall, Axial

This aluminum fan is published with the manufacturer’s full specification — 220V/380V, air flow 17000-27000 CBM/h. Made by Fujian Huada Electric Co., Ltd. (12 years on the platform, typical reply ≤2h). Quantity and destination market determine the final price — tell us both for a firm quote.

Key Features of This Aluminum Fan

• Model Number: GKW
• Power Source: Electric
• Power: 3kw
• Voltage: 220V/380V
• Rated Voltage: 230v/380v
• Air Flow: 17000-27000 CBM/h

Technical Specifications

Product Details

GKW/GWF series drying kiln special high temperature high humidity axial fan,is special designed for drying kiln.It has remarkable characteristic of resistant to high temperature,resistant to high humidity,large air volume,high efficiency,energy saving,and convenient installation.The axial fan is used in the ventilation system for wood drying kiln and other drying equipment.As the blades diameter is different,there are 7 model,No.4,5,6,7,8,9,10.The angle of fan can be adjusted according to the clients' requirements.

Features:

The fans blades can be direct connected with the motor.The circumferential velocity of the impeller does not exceed the condition,there are three different rotational speed:2900 r/min,1450 r/min,960r/min.

Since the frame size and the blades diameter are different,the installation angle of the blades,speed of main shaft is different.Air flow,air pressure and motor output are different.The air pressure from 60Pa to 400Pa,the air flow from 1000 cbm/h to 60000cbm/h.(details as per performance table).

Applied conditions:Max. Ambient Temp:<130℃，Relative humidity:<98%,in the ambient of weak alkali,vapor and no flammable gas,the motor can be also used in the vacuum drying equipment according to the specific conditions.

Tech Data

Item No.	Speed （rpm)	Airflow(m³/h)	Total pressure (Pa)	Hydrostatic(Pa)	Motor No.	Power(kw)	Noise(dB)	No. of blades
4	2900	3000-5000	110-200	60-180	712-2	0.55	≤74	6
				4000-6500	160-250	70-200	801-2	0.75	≤74	6
				4500-7000	200-280	80-210	802-2	1.1	≤75	6
		1450	2000-3500	60-70	30-55	711-4	0.25	≤66	6
				2500-4000	70-78	35-55	712-4	0.37	≤68	6
				2800-4300	72-80	36-58	801-4	0.55	≤70	6
5	1450	5500-7000	130-145	70-105	801-4	0.55	≤71	6
				6000-8500	138-150	80-100	802-4	0.75	≤74	6
6	1450	7500-11500	140-160	80-130	90S-4	1.1	≤76	6
				8000-13500	160-180	80-135	90L-4	1.5	≤78	6
7	1450	10000-17500	180-220	140-175	90L-4	1.5	≤79	6
				12000-20000	200-250	145-180	100L1-4	2.2	≤80	6
8	1450	15000-25000	180-270	100-260	100L1-4	2.2	≤81	6
				17000-27000	210-300	120-260	100L2-4	3	≤82	8
				20000-30000	240-330	125-265	112M-4	4	≤86	8
		960	13000-20000	110-145	53-105	100L-6	1.5	≤78	8
				15000-22000	120-155	500-100	112M-6	2.2	≤80	8
9	1450	20000-34000	240-340	160-320	112M-4	4	≤86	8
				22000-36000	250-350	150-310	132S-4	5.5	≤87	8
		960	13000-22000	100-140	70-120	112M-6	2.2	≤82	8
				15000-24000	12–160	70-136	132S-6	3	≤83	8
10	1450	23000-36000	250-400	160-370	132S-4	5.5	≤87	8
				28000-40000	270-420	165-380	132M-4	7.5	≤88	8
		960	20000-31500	150-220	90-170	132M1-6	4	≤85	8
				21000-33000	160-230	90-176	132M2-6	5.5	≤86	8

Installation Data

Company Introduction

Fujian Huada Motor Factory established in 1998,registered as Fujian Huada Electric CO.,LTD,located in Fujian Province.It is a modern enterprise which engaged in Scientific research,production,sales and service.Covering an area of 50,000 square meters,of which 40,000 square meters are standard workshop. Huada is more than ten years to focus on the research and development of high temperature motor,high temperature fan;Strictly control the production process ,making the high-quality goods.Products are included MSW series high temperature motor,GKF series flue-cured tobacco special-purpose fan,GKW series full aluminum high temperature and high humidity fan,CRF series grain drying dedicated fan,DJF series multistage high -pressure fan,DRF series diversion type high temperature fan,HTF series high temperature fire smoke exhaust fan,SWF series mixed flow fan and all kinds of high temperature and centrifugal fan and so on. Besides our products passed the CCC certification,European Union CE certification. Best selling in China and overseas markets,Huada as well known brand reputation in the domestic complete set of drying industry. GKF series fan was chosen as the industry standard by the national tobacco administration in 2009. The project of Flue-cured tobacco asynchronous motor with variable speed multistage won the third prize in Ningde science and technology progress and the second prize in Fuan Science and technology progress.

More Information

Application

Packing Details

Ordering and Pricing

• Minimum order quantity: 1 set
• Volume pricing:
  • 1–19 set: US $175 / set
  • 20–99 set: US $165 / set
  • 100+ set: US $155 / set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this aluminum fan?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Can the aluminum fan be supplied for my local voltage?

The standard configuration is 220V/380V. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Fujian Huada Electric Co., Ltd., based in China. The company 12 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Fujian Huada Electric Co., Ltd. range on HVACR Nexus.
