This fan is published with the manufacturer’s full specification — 12.6KW. Made by Xi Maike (guangdong) Refrigeration Technology Co., Ltd. (11 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Fan
- Capacity: 12.6KW
- Air Flow: 12000
- Warranty: 5 year
- Place Of Origin: Guangdong, China
- Weight: 118KG
- Single Gross Weight: 0.0 kg
Technical Specifications
| Warranty | 5 year |
|---|---|
| Place Of Origin | Guangdong, China |
| Brand Name | XMK |
| Product Name | air cooler/evaporator |
| Color | White |
| Capacity | 12.6KW |
| Surface | 73.8 |
| Tube Volume | 15.5 |
| Air Flow | 12000 |
| Air Throw | 15m |
| Inlet | 22 |
| Outlet | 35 |
| Weight | 118KG |
| Packaging Details | air cooler/evaporator packed with wooden/case. ND74/250L-ET 10HP 380V/220V Capacity 12.6KW 400mm Fan Air Cooler Evaporator For Cold Room. |
| Port Of Dispatch | Nansha |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
| Supply Ability | 1000 pieces per Month air cooler/evaporator |
Product Details
ND74/250L-ET 10HP 380V/220V Capacity 12.6KW 400mm Fan Air Cooler Evaporator For Cold Room
Product description:
1.Casing: Adopt high-quality steel plate with powder coating RAL 9003,
Hinged structure is adopted for both side plate sand external drip tray, which is convenient and quick to operate.
2.Heat Exchange Coil: copper tubingφ15,spacing50X 50,
Corrugated aluminium fins,fin spacing 4. 2mmand 6.4mm and 9.0mm.
3.It can meet the requirements of R404A, R507A,R448A, R449A, R134a, R22 and other refrigerants.
4.Defrosting:Standard use of electric defrosting stainless heating pipes installed in the middle of coil and inner water plate.
Independent electric heating tube junction box.
Fans: External rotor motor with high wind pressure,working temperature -40~60C.
5.Fans individually connected to junction box
Fan blade 300mm, 350mm,400mm, 500mm, 630mm, standard4-pole motor.
| ND Series Evaporator 6.0mm Fin Data | |||||||||
| Model | Capacity(KW) R404A |
Surface | Tube Volume |
Air Flow |
Air Throw |
Connection Pipe(mm) |
|||
|
0 degree |
-18 degree |
m | Inlet | Outlet | Drain | ||||
| ND7/130L-ES | 1.3 | 1 | 6.6 | 1.6 | 1800 | 5 | 12 | 19 | G1 |
| ND10/135L-ET | 2.1 | 1.7 | 9.8 | 2.4 | 2100 | 6 | 12 | 19 | G1 |
| ND13/230L-ES | 2.6 | 2.1 | 13.1 | 2.9 | 3600 | 7 | 12 | 16 | G1 |
| ND20/235L-ET | 4.2 | 3.3 | 19.7 | 4.3 | 4200 | 8 | 12 | 19 | G1 |
| ND30/240L-ET | 5.3 | 4.2 | 29.5 | 6.3 | 6400 | 10 | 12 | 22 | G1.5 |
| ND40/240L-ET | 6.6 | 5.2 | 39.4 | 8.4 | 6000 | 10 | 16 | 28 | G1.5 |
| ND50/240L-ET | 7.8 | 6.2 | 49.2 | 10.5 | 5400 | 9 | 16 | 28 | G1.5 |
| ND60/250L-ET | 13 | 10.3 | 59 | 12.4 | 13000 | 16 | 22 | 35 | G1.5 |
| ND74/250L-ET | 15.9 | 12.6 | 73.8 | 15.5 | 12000 | 15 | 22 | 35 | G1.5 |
| ND100/350L-ET | 21.6 | 17.1 | 98.4 | 20.4 | 19500 | 18 | 22 | 42 | G2.5 |
| ND120/350L-ET | 24.7 | 19.5 | 118.1 | 24.5 | 18000 | 18 | 22 | 42 | G2.5 |
| ND160/450L-ET | 32.8 | 25.9 | 159.9 | 32.5 | 26000 | 22 | 28 | 54 | G2.5 |
| ND192/450L-ET | 36.5 | 28.8 | 191.9 | 39 | 24000 | 21 | 28 | 54 | G2.5 |
| ND213/455L-ET | 42.6 | 33.7 | 213.2 | 43.4 | 30000 | 25 | 28 | 54 | G2.5 |
| ND256/455L-ET | 46.1 | 36.4 | 255.8 | 52 | 28000 | 24 | 28 | 54 | G2.5 |
| ND266/463L-ET | 51.9 | 41 | 265.7 | 53.9 | 38800 | 30 | 28 | 54 | G2.5 |
| ND320/463L-ET | 57.4 | 45.3 | 318.8 | 64.7 | 36800 | 29 | 28 | 54 | G2.5 |
Click Me To See All Categories.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this fan?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 5 year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Xi Maike (guangdong) Refrigeration Technology Co., Ltd., based in China. The company 11 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Xi Maike (guangdong) Refrigeration Technology Co., Ltd. range on HVACR Nexus.
