Key specification for this air purifier: material Synthetic Fiber, type Air Filter Element. Everything below is reproduced from the factory data sheet. Made by Guangdong Detai air conditioning equipment Co., LTD (4 years on the platform, typical reply ≤2h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Air Purifier
- Material: Synthetic Fiber
- Filtering Material: HEPA filter, Pre filter
- Warranty: 1 Year
- Place Of Origin: Guangdong, China
- Application: Cleanroom
- Feature: Low noise, Long service life
Technical Specifications
| Type | Air Filter Element |
|---|---|
| Construction | Box Filter |
| Material | Synthetic Fiber |
| Warranty | 1 Year |
| Condition | New |
| Place Of Origin | Guangdong, China |
| Weight | 27 |
| Brand Name | DTAF |
| Dimension(L*W*H) | 615x1225x375 |
| Efficiency | 99.99% |
| Product Name | Laminar Flow Hood Modular Clean Room Hepa FFU |
| Application | Cleanroom |
| Media | Air blower |
| Keyword | FFU |
| Usage | Widely Used Dust Filter |
| Filtration Grade | HEPA |
| Frame | Galvalume / aluminum / stainless steel |
| OEM/ODM | Yes |
| Filtering Material | HEPA filter, Pre filter |
| Feature | Low noise, Long service life |
| Selling Units | Single item |
| Single Package Size | 200X150X40 cm |
| Single Gross Weight | 27.000 kg |
Product Details
Products Description
Product Description
FFU is abbreviation of Fan Filter Unit. It is a modular terminal air supply device with its own power and filtering effect. Its main function is to inhale the air from the top of the FFU by the fan and filter it by HEPA, and the filtered clean air is evenly sent out at the air velocity of 0.45m/s+20% on the entire air outlet surface to meet the cleanliness requirements of the clean environment. It is mainly installed on ceiling keels and equipment machines in clean areas and working areas. Widely used in semiconductors, optical electronics, precision instruments, biopharmaceuticals, aerospace, and automobiles, hospitals, food, spraying, printing and other fields.
All sizes and styles can be customized | ||||||||||
Model | ACFFU-1 | ACFFU-2 | ACFFU-3 | ACFFU-4 | ||||||
Size (WxLxHmm) | 575x875x375 | 575x1175x375 | 615x1225x375 | 875x1175x375 | ||||||
Air chamber material | Galvalume / aluminum / stainless steel | |||||||||
Air Flow (m³/h) | 800~900 | 1000~1100 | 1100~1200 | 1600~1700 | ||||||
Air velocity (m/s) | 0.35~0.55 | 0.35~0.55 | 0.35~0.55 | 0.35~0.55 | ||||||
Total pressure (Pa) | 175 | 185 | 195 | 255 | ||||||
Power (W) | 85 | 95 | 115 | 235 | ||||||
Weight (kg) | 27 | 37 | 40 | 42 | ||||||
Noise dB (1m below the HEPA filter) | 55~63 | |||||||||
Vibration (mm/s) | 0.2~0.7 | |||||||||
Power supply | 220V 1PH 50/60Hz (330V 3PH 50/60Hz 110V 1PH 50/60Hz) | |||||||||
Control mode | 3 levels adjustable manually or group control by computer | |||||||||
Options | DOP inject port / DOP sample port / differential pressure drop test port / differential pressure drop alarm device | |||||||||
HEPA filter | Size (WxHxDmm) | 570x870x69 | 570x1170x69 | 610x1220x69 | 870x1170x69 | |||||
Efficiency | 99.99% 0.3μm | |||||||||
Frame | High quality anodized aluminum | |||||||||
Initial pressure drop | 110Pa@0.45m/s±15% | |||||||||
Trait | PU foam endless gasket | |||||||||
Details Images
Installation Instructions
Application
Application places:
1. Dust free room and clean room: it is suitable for places with high requirements on air cleanliness, such as dust free room, clean room, laboratory, etc.
2. Medical and health care places: in hospital operating theatres, wards and other medical and health care places, to provide a
clean air environment.
3. Electronic manufacturing plants: for electronic manufacturing plants, semiconductor production lines and other production
places with high air quality requirements.
4. Laboratories and R&D centres: In scientific research laboratories and R&D centres, AC FFUs can be used to provide clean and
stable experimental environments.
2. Medical and health care places: in hospital operating theatres, wards and other medical and health care places, to provide a
clean air environment.
3. Electronic manufacturing plants: for electronic manufacturing plants, semiconductor production lines and other production
places with high air quality requirements.
4. Laboratories and R&D centres: In scientific research laboratories and R&D centres, AC FFUs can be used to provide clean and
stable experimental environments.
Company Profile
Qingyuan Detai air conditioning equipment Co., LTD
Qingyuan Detai Air Conditioning Equipment Co., Ltd. was established in 1998, the brand is DTAF, is a professional engaged in air filter, air purification equipment and clean room solutions research, development, sales and service enterprises. DTAF is located in Guangzhou, China, with convenient transportation and beautiful environment, the factory covers an area of 18,690 square meters and has more than 70 employees.
Cooperation brand
Why Choose Us
FAQ
Q: Are you trading company or a factory? | ||||||||
A: Our company is a professional factory so that we offer competitive factory price to our clients. | ||||||||
Q: How to pay? | ||||||||
A: Our company accepts various ways of payment, such as T/T , Western Union etc. | ||||||||
Q: How about quality control in your factory? | ||||||||
A: We pay great attention to quality control from beginning to the end. Every piece of goods is tested strictly before packing and delivery. | ||||||||
Q: How can I get some samples? | ||||||||
A: We are honored to offer you samples. But the freight and sample fee should be on your account. | ||||||||
Q: How about your delivery time? | ||||||||
A: Generally, it will take 7 to 10 days after receiving your deposit. But the specific delivery time dependson the items and the quantity of your order. | ||||||||
Q: Can we visit your factory? | ||||||||
A: Yes, welcome to visit our company! If you fly, you can go to Guangzhou Baiyun International Airport first, then take the high-speed train from Guangzhou South Railway Station to Qingyuan Station, and we can pick you up there. | ||||||||
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–99 set: US $119 / set
- 100–999 set: US $115 / set
- 1000+ set: US $109 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air purifier?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
