Air Source Heat Pump, 3.75kW, 000, BTU

The air source heat pump listed here carries heating capacity 7-35kw, power source Electric, documented exactly as the manufacturer publishes it. Made by Guangzhou Mikee New Energy Co., Ltd. (4 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.

Key Features of This Air Source Heat Pump

• Model Number: BYC-007TG1~035TG3
• Power Source: Electric
• Heating Capacity: 7-35kw
• Housing Material: Metal
• Refrigerant: R32
• Warranty: 3 Years

Technical Specifications

Product Details

Product Paramenters

R32 Full DC Inverter Heating & Cooling Swimming Pool Heat Pump

●Full inverter, higher COP, better performance ●R32 refrigerant, environmental friendly ●Titanium heat exchanger, corrosion ressistance ●Intelligent controller

●WIFI function included

MODBUS communication

●Heating, cooling & Auto function included

Refrigerant	R32
Ambient temperature	-15~43℃
Voltage Function	Water Heating & Cooling
OEM&ODM	● Style design  ● LOGO ● Packing boxes ● Casing material: Metal, ABS

Products Description

A Wide Range Of Models To Choose From

There are numerous models of swimming pool heat pumps from Mikee, ranging from 7KW to 30KW. The ideal one for your pool is yours to choose.

Heating, Cooling & Automatic Modes

Encompasses both automatic and heating/cooling modes, allowing for a broad range of temperatures for the target water temperature and the operating environment.

GWP For R32 Is 60% Lower Than for R410a

Mikee takes pride in the introduction of Inver SUNGLASSES Series Inverter Pool Heat Pump, using R32 a revolutionary refrigerant fluid.
① With R32 refrigerate remarkable attributes, R32 sets itself apart from R410a as it effectively reduces greenhouse gas emissions by an impressive 60%.
② Not only that, but it also enables a 10% decrease in gas quantity per kilowatt, making it an energy-efficient choice.
③ R32 refrigerate recyclability and user-friendly nature further add to Inver SUNGLASSES Series Inverter Pool Heat Pump‘s appeal.
④ One of the key advantages of R32 is its absolute zero impact on the ozone layer, highlighting its commitment to protecting the environment.
By opting for R32 Inver SUNGLASSES Series Inverter Pool Heat Pump, you not only contribute to sustainability but also play a role in creating a greener future. Join Mikee in their mission to promote a more sustainable world and embrace R32 as the refrigerant fluid of choice.

Silence Mode

The R32 Inver SUNGLASSES Series Inverter Pool Heat Pump has a sound pressure of 39dB(A) at a distance of one meter.
When the temperature remains constant,the compressor and fan in an inverter operate at extremely low speeds,reducing sound levels to only air movement (about 39 dB(A)).

Everything On One App

The operating modes for the Eco Inverter and Power Inverter are available on the new control panel, which has a 20-meter wired extension. Thanks to the built-in WiFi module, the swimming pool heat pump can be operated remotely via a smart phone.

Model No.	BYC-007TG1	BYC-010TG1	BYC-013TG1	BYC-017TG1
Heating Capacity at Air 26℃, Humidity 80%, Water 26℃ in, 28℃ out
Heating Capacity (kW)	7.7～1.8	10~2.3	13.2~3.1	17.1~3.9
Power Input (kW)	1.13～0.11	1.45~0.15	1.91~0.19	2.51~0.25
COP	15.8～6.8	15.8~6.9	16~6.9	15.9~6.8
Heating Capacity at Air 15℃, Humidity 70%, Water 26℃ in, 28℃ out
Heating Capacity (kW)	5.7～1.3	7.9～1.8	10.1～2.3	10.1～2.3
Power Input (kW)	1.16～0.17	1.58～0.23	2.03～0.30	2.03～0.30
COP	7.6～4.9	7.6～4.9	7.6～4.9	7.6～4.9
Cooling Capacity at Air 35℃, Water 29℃ in, 27℃ out
Cooling Capacity（kW)	4.2～1.1	5.9～1.5	7.2～1.8	9.4～2.3
Power Input（kW)	1.13～0.17	1.57～0.22	1.89～0.26	2.51～0.34
EER	6.6～3.7	6.7～3.7	6.9～3.8	6.9～3.8
Power supply	220～240V / 1/ 50 Hz
Max Power Input（kW)	1.2	1.6	2.1	2.6
Max Current(A)	5.5	7.3	9.6	11.9
Refrigerant	R32	R32	R32	R32
Heat Exchanger	Titanium	Titanium	Titanium	Titanium
Air Flow Direction	Horizontal	Horizontal	Horizontal	Horizontal
Water Flow Volume（m3/h)	2.5	3.5	4.5	5.5
Automatic defrosting	by 4 way valve				by 4 way valve	by 4 way valve	by 4 way valve
Working temp. range (℃)	-15～43	-15～43	-15～43	-15～43
Noise level 1m dB(A)	38~48	39~51	41~52	42~54
Noise level 10m dB(A)	19~28	19~31	21~32	22~34
Net Dimensions (mm)(L*W*H)	821*405*587			850*405*637
Package Dimensions (mm)(L*W*H)	883*435*722			912*435*777
Net Weight(kg)	42	44	53	56
Gross Weight(kg)	53	55	64	67
Water Proof Level	IPX4	IPX4	IPX4	IPX4

Model No.	BYC-021TG1	BYC-030TG1	BYC-030TG3
Heating Capacity at Air 26℃, Humidity 80%, Water 26℃ in, 28℃ out
Heating Capacity (kW)	21~4.9	28.2~6.9	28.4~7.1
Power Input (kW)	3.09~0.31	4.15~0.44	4.18~0.45
COP	15.8~6.8	15.8~6.8	15.8~6.8
Heating Capacity at Air 15℃, Humidity 70%, Water 26℃ in, 28℃ out
Heating Capacity (kW)	15.9～3.6	22.1～5.0	22.1～5.0
Power Input (kW)	3.20～0.47	4.43～0.65	4.44～0.65
COP	7.6～4.9	7.6～4.9	7.6～4.9
Cooling Capacity at Air 35℃, Water 29℃ in, 27℃ out
Cooling Capacity（kW)	11.5～2.9	15.8～3.9	15.9～3.9
Power Input（kW)	3.16～0.43	4.19～0.56	4.18～0.56
EER	6.9～3.7	6.9～3.8	6.9～3.8
Power supply	220～240V / 1/ 50 Hz	380～415V / 3/ 50 Hz
Max Power Input（kW)	3.2	4.4	4.5
Max Current(A)	14.5	20	8.4
Refrigerant	R32	R32	R32
Heat Exchanger	Titanium	Titanium	Titanium
Air Flow Direction	Horizontal	Horizontal	Horizontal
Water Flow Volume（m3/h)	2.5	3.5	4.5
Automatic defrosting	by 4 way valve			by 4 way valve	by 4 way valve
Working temp. range (℃)	-15～43	-15～43	-15～43
Noise level 1m dB(A)	44~55	46~57	46~57
Noise level 10m dB(A)	24~35	26~37	26~37
Net Dimensions (mm)(L*W*H)	850*405*637	1036*448*739
Package Dimensions (mm)(L*W*H)	912*435*777	1098*488*879
Net Weight(kg)	60	88	88
Gross Weight(kg)	71	99	99
Water Proof Level	IPX4	IPX4	IPX4

Company Profile

Guangzhou Mikee New Energy Co., Ltd.

Guangzhou Mikee New Energy Co., Ltd. is a subsidiary of SolarEast Group (SH: 603366), a listed technology enterprise. Our factory is located in Shunde, Guangdong Province, covering an area of 69000 square meters, with a total investment of 75 million dollars. It is one of the best scale air energy production bases in Asia, and undertakes ODM and OEM of air energy and energy storage products. We have a number of pre automated assembly lines for commercial and civil products, with an annual production capacity of more than 100W sets and an investment of 150W dollars to build the industry's top heat pump laboratory. We have core data in the fields of hot water dedicated compressors, aerospace level leakproof enamel liners, 3-minute intelligent defrosting technology, super class energy technology, microchannel fast heating technology, etc.

Our Advantages/Workshop

Commercial machine production line

▶▶ The commercial workshop has 3 production lines, 15 automated commodity inspection stations, which can be packaged and wound online. The maximum test capacity is 200P units, and 300 standard units can be produced in a single shift. ▶▶ The household workshop has two production lines, which can produce fluorine machines and water machines below 3P, 10 automatic vacuum pumping stations and 10 commodity inspection stations respectively. Robots are used for offline palletizing, and 700 standard units can be produced in a single shift.

The sheet metal workshop has 3 laser cutting machines, 3 CNC punching machines, 6 CNC bending machines, 2 laser welding machines, and several equipment such as blanking and leveling, angle forming, spinning and pulling, plate shearing, deep throat punching, riveting, welding and grinding, with strong processing capacity.

Automatic spraying line

The total length of the line is more than 520 meters, and the maximum workpiece can be sprayed 3 * 1.8 meters. The materials include galvanized plate, cold plate, brushed stainless steel plate, aluminum plate. The pre-treatment process includes degreasing and vitrification. QC inspection capabilities include: color detection, film thickness detection, hardness detection, adhesion detection, solvent resistance detection, ultraviolet aging test, impact resistance detection. The workpiece can be picked up and sent.

R&D and testing capability

○ More than 10 million investment

○ Has ultra-low 60p temperature laboratory, enthalpy difference laboratory, data monitoring center, long-term operation laboratory

○ Ke – 30 ℃ environmental conditions

Certifications

Exhibition

FAQ

A) Are you a manufacturer? Yes, we are a company and factory integrating R&D, production, and sales. Besides, our products have been exported to more than 100 countries and regions, such as the United States, Russia, the United Kingdom, and Australia. B)Why should you select our heat pumps over those of other manufacturers? We have more than 19 years of experience in the heat pump field. Besides, we have a professional technical team, the industry's top heat pump laboratory, and automatic production lines. We can meet your diverse order requirements. C) Do you offer OEM/ODM customised services? Yes. We are able to produce European-standard heat pumps under your brand according to your special needs. D) I need to buy in bulk. Can you provide a sample service? Yes, we are able to provide sample services. We have professional engineers who can help you solve after-sales installation problems. E) How can we guarantee product quality? 1) There will be multiple tests during the production process. 2) Products will be strictly inspected before shipment.

Ordering and Pricing

• Minimum order quantity: 1 piece
• Volume pricing:
  • 1–49 piece: US $869 / piece
  • 50–99 piece: US $622 / piece
  • 100+ piece: US $420 / piece
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this air source heat pump?

The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
