Air Source Heat Pump, T3, R410A

The air source heat pump listed here carries power supply 380~415/50/60/3, 12KW, documented exactly as the manufacturer publishes it. Made by Guangdong Europe Mango New Energy Technology Co., Ltd. (6 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.

Key Features of This Air Source Heat Pump

• Model Number: MGK-030IIC
• Power Source: Electric, Solar
• Power Supply: 380~415/50/60/3
• Heating Capacity: 12KW
• Housing Material: Galvanized Sheet
• Material: Galvanized Metal

Technical Specifications

Product Details

Product Description

Parameter

Model

MGKN-030IIC

MGKN-050IIC

MGKN-060IIC

MGKN-070IIC

MGKN-100IIC

MGKN-120IIC

Cooling capicity (A35/W7)

kw

8.27

14.25

17.32

19.28

26.78

31.49

Input power

kw

2.70

4.66

5.68

6.34

8.75

10.39

EER

3.06

3.06

3.05

3.04

3.06

3.03

Voltage

V/Hz/PH

220V-240/50/60/1or380~415/50/60/3

380~415/50/60/3

Rated water temp

7℃

Water flow

m³/h

1.8

3.1

3.7

4.1

5.8

6.8

Water pressure drop

kPa

≤40

≤50

≤65

≤65

≤65

≤65

Refrigeration

R410A

Compressor

Copeland Scroll

Evaporator

Blue Finned heat exchanger

Throttle unit

DunAn

Controller

LCD wire controller

Ambient Temperature

55°C

Water pipe size

–

DN25

DN25

DN25

DN25

DN40

DN40

Noise

dB(A)

≤52

≤55

≤56

≤58

≤62

≤64

Dimension

mm

710*710*900

810*810*1055

810*810*1055

810*810*1055

1450*740*1150

1450*740*1150

Weight (N./W.)

kg

97/102

147/157

152/162

158/168

286/306

328/348

Remarks: Cooling conditions: Air temperature (DB/WB): 35°C/24°C, water temperature (inlet/outlet):12°C/7°C.

Model			MGKN-150IIC	MGKN-250IIC	MGKN-300IIC	MGKN-500IIC	MGKN-600IIC
Cooling capicity (A35/W7)	kw	38.53	68.59	83.31	137.28	168.22
Input power	kw	12.67	22.42	27.23	44.72	54.62
EER		3.04	3.06	3.06	3.07	3.08
Voltage	V/Hz/PH	380~415/50/60/3
Rated water temp			7℃
Water flow	m³/h	8.3	14.7	17.9	29.5	36.2
Water pressure drop	kPa	≤65	≤65	≤65	≤65	≤65
Refrigeration	R410A
Compressor	Copeland Scroll
Evaporator	Blue Finned heat exchanger
Throttle unit	DunAn
Controller	LCD wire controller
Ambient Temperature	55°C
Water pipe size	–	DN40	DN65	DN65	DN80	DN80
Noise	dB(A)	≤65	≤66	≤66	≤68	≤68
Dimension	mm	1507*857*1611	1860*1030*2100	1860*1030*2100	1905*1860*2280	1905*1860*2280
Weight (N./W.)	kg	377/400	596/635	698/742	1076/1145	1112/1198

Product Features

FAQ

Q1> What does mango energy company do ?
A1:Our Company Professional Supply: Heating Cooling DHW DC Inverter Heat Pump 9-34kW Swimming Pool Heat Pump 11-192kW Commercial
Heating Cooling Heat Pump 9-180kW Commercial Hot Water Heat Pump 10-72kW Water / Ground Source Heat Pump 11-200kW Water Tank and
Other Components.

Q2> What is the daily production of Mango energy company ?
A2: Mango energy one day produce heat pump water heater around 200 PCS / day.

Q3> What is Mango heat pump certification ?
A3 : Mango energy have : SGS, CE,CB, IEC60335-2-40, EN14511 certificate from TUV Lab,, got ISO9001. ISO18001, ISO14001 and
CCCcertificate. Get Class A+, A as ErP EN14825 test report .
Q4> What Mango energy do for their agent / distributor /OEM ?
A4 : Mango energy offer sales training , heat pump & solar air conditioner product training,
After sales service training , maintenance machine training , big air chiller ,or heating
Project design case training , inside parts exchange training and test training.

Q5> What Mango energy offer to their business partner ?
A5: Mango energy offer 1%~2% free spare parts according to order quantity .
Offer whole this district market exclusive sales right .
Offer rebate as this district agent sales amount within one year .
Offer best competitive price & repair parts .
Offer 24 hours online service .

Q6> where is Mango energy heat pump using ?
A6: Because Air source heat pump save energy around 70% , ( EVI heat pump and central cooling & heating heat pump ) is Widely used
in home heating, hotels hot water & heating , restaurants, hospitals,schools,bath center, residential central heating and hot
water plants, etc.

Ordering and Pricing

• Minimum order quantity: 1 unit
• Volume pricing:
  • 1–19 unit: US $1180 / unit
  • 20–49 unit: US $1100 / unit
  • 50+ unit: US $1000 / unit
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this air source heat pump?

The standard minimum order quantity is 1 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 5 year warranty. Spare parts and technical support remain available after the warranty period.

Can the air source heat pump be supplied for my local voltage?

The standard configuration is 380~415/50/60/3. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Guangdong Europe Mango New Energy Technology Co., Ltd., based in China. The company 6 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Guangdong Europe Mango New Energy Technology Co., Ltd. range on HVACR Nexus.
