Angles for industrial fan — material Aluminum Alloy, 1450 rpm. The complete factory specification follows. Made by Foshan Chosen Vent Tech Ltd. (16 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Angles For Industrial Fan
- Material: Aluminum Alloy
- Speed: 1450 rpm
- Warranty: 1 YEAR
- Place Of Origin: Guangdong, China
- Product Type: Axial Impeller
- Single Package Size: 45X45X20 cm
Technical Specifications
| Warranty | 1 YEAR |
|---|---|
| Customized Support | OEM, ODM |
| Place Of Origin | Guangdong, China |
| Brand Name | CHOSEN |
| Material | Aluminum Alloy |
| Impeller Dia | 560~800 mm |
| Number Of Fan Blades | 10 |
| Speed | 1450 rpm |
| Product Type | Axial Impeller |
| Selling Units | Single item |
| Single Package Size | 45X45X20 cm |
| Single Gross Weight | 10.7 kg |
Product Details
Advantages
1. 400ton die casting, high density, heavy duty. The wall with uniform thickness and no die surface porosity.
2. New material of Aluminum Alloy without inclusions.
3. Each impeller be inspection by Dynamic Balance.
4. Adjustable angles for fan blades.
5. Test by completed build-up axial fan, the air Performance Parameter is truth and reliable.
6. High static efficiency, Long lasting.
| ALUMINUM AXIAL IMPELLER – AL | |||||||
| Blade Type | Item | Standard | Hub | Shaft Head | Blade quantity | Speed | |
| mm | φ | φ | Material | pcs | rpm | ||
| C Type Blade | AL-100-7C | 250 | φ100 | φ9-φ14 | Aluminum alloy | 7 | 2850 |
| AL-120-7C | 285 | φ120 | φ11-φ19 | Aluminum alloy | 7 | ||
| AL-140-7C | 350-400 | φ140 | φ14-φ24 | Aluminum alloy | 7 | ||
| AL-150-4C | 400-620 | φ150 | φ11-φ28 | Aluminum alloy | 4 | 1450 | |
| AL-150-6C | 6 | ||||||
| AL-150-8C | 8 | ||||||
| AL-160-5C | 400-620 | φ160 | φ11-φ28 | taper lock | 5 | 1450 | |
| AL-160-10C | 400-630 | φ11-φ28 | Aluminum alloy | 10 | |||
| B Type Blade | AL-200-9B | 560-800 | φ200 | φ19-φ28 | Aluminum alloy | 9 | 1450 |
| φ38-φ42 | cast iron | ||||||
| 900-1000 | φ19-φ28 | Aluminum alloy | 960 | ||||
| φ38-φ42 | cast iron | ||||||
| AL-200-10B | 560-800 | φ200 | φ19-φ28 | Aluminum alloy | 10 | 1450 | |
| φ38-φ42 | cast iron | ||||||
| 900-1000 | φ19-φ28 | Aluminum alloy | 960 | ||||
| φ38-φ42 | cast iron | ||||||
| AL-255-14B | 500-1000 | φ255 | φ19-φ28 | Aluminum alloy | 14 | 1450 | |
| φ38-φ42 | cast iron | ||||||
| AL-280-12B | 500-1000 | φ280 | φ24-φ48 | taper lock/ φ42 cast iron | 12 | 1450 | |
| A Type Blade | AL-220-8A | 560-800 | φ220 | φ24-φ48 | cast iron | 8 | 1440 |
| AL-220-9A | 9 | 1450 | |||||
| AL-320-12A | 560-995 | φ320 | φ24-φ48 | cast iron | 12 | 1450 | |
| AL-380-8A | 800-1000 | φ380 | φ38-φ55 | taper lock | 8 | 1450 | |
| AL-380-16A | 16 | 1450 | |||||
| AL-440-14A | 900-1120 | φ440 | φ38-φ55 | taper lock | 14 | 1450 | |
| AL-500-9A | 1000-1170 | φ500 | φ42-φ65 | taper lock | 9 | 1450 | |
| AL-500-18A | 18 | 1450 | |||||
| D Type Blade | AL-320-6D | 560-1120 | φ320 | φ24-φ48 | cast iron | 6 | 1450 |
| 560-1280 | 960 | ||||||
| AL-320-12D | 560-1120 | 12 | 1450 | ||||
| 560-1280 | 960 | ||||||
| AL-380-8D | 800-1250 | φ380 | φ38-φ55 | taper lock | 8 | 960/1450 | |
| AL-380-16D | 16 | 960/1450 | |||||
| AL-440-14D | 1000-1120 | φ440 | φ38-φ55 | taper lock | 14 | 1450 | |
| 1000-1400 | φ38-φ55 | taper lock | 960 | ||||
| φ55-φ75 | cast iron | 960 | |||||
| AL-500-9D | 1000-1450 | φ500 | φ42-φ65 | taper lock | 9 | 960/1450 | |
| AL-500-18D | 18 | 960/1450 | |||||
| H Type Blade | AL-380-8H | 800-1250 | φ380 | φ38-φ55 | taper lock | 8 | 960/1450 |
| AL-380-16H | 800-1250 | 16 | 960/1450 | ||||
| AL-500-9H | 1000-1400 | φ500 | φ42-φ65 | taper lock | 9 | 960/1450 | |
| AL-500-18H | 1000-1400 | 18 | 960/1450 | ||||
| J Type Blade | AL-350-7J1 | 600-1000 | φ350 | φ38-φ55 | taper lock | 7 | 1450 |
| AL-350-14J1 | 14 | ||||||
| AL-500-18J | 1000-1800 | φ500 | φ42-φ65 | taper lock | 18 | 1450/960/720 | |
| Click here for more product parameters. | |||||||
Applications
· Integrated fans
· roof ventilators
· ventilation and air-conditioning systems (HVAC)
· industrial fan applications
CHOSEN VENT TECH LTD. is a manufacturer of ventilation and cooling equipment with more than 10 years experience.
Professional Products:
1. Centrifugal Fan, Axial Fan, HVLS Fan, Fan Impeller, Mist Fan.
2. Non-standard units & small order.
3. Accessories: Forward Impeller, Backward Impeller, Axial Impeller, Atomizer.
4. Meanwhile we specialized in ventilation & cooling solution of industrial building.
Professional Manufacturing:
1. Experienced engineers and R&D team to support the product technology & development.
2. Advanced manufacturing & inspection equipment, we have Laser cutting equipment, CNC equipment, Dynamic balance equipment, Air-flow/pressure/speed testing equipment.
3. Inspection. All products with serious inspection in hundred percent before delivery.
Professional Service:
1. Our products be export to more than 30 countries.
2. On time delivery.
3. The experienced customers service team provides excellent communication for all customers to answer questions and solve problem.
Our Aim:
1.Company's Aim: Honesty, Gratitude.
2.Service's Aim: Professionalism, Scrupulous, Responsibility.
3.Product's Aim: High quality, Reasonable price, for customers' requirements.
Our mission:
1. Provide quality products all over the world.
2. Set up fine managing and brand credit for "MADE IN CHINA"
Ordering and Pricing
- Minimum order quantity: 5 piece
- Volume pricing:
- 5–99 piece: US $63.73 / piece
- 100–299 piece: US $60.54 / piece
- 300+ piece: US $57.51 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this angles for industrial fan?
The standard minimum order quantity is 5 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 YEAR warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Foshan Chosen Vent Tech Ltd., based in China. The company 16 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Foshan Chosen Vent Tech Ltd. range on HVACR Nexus.
