Capturing weld fume at the arc rather than diluting it across the shop — the difference between meeting an exposure limit and merely moving the problem around.

  • 19,551products across this application
  • 2,239verified manufacturers
  • 5equipment groups

WhatCapture at source, or dilute

Two approaches exist and they are not interchangeable. Local exhaust captures fume at the arc, through an on-torch extractor, a movable hood or a downdraught bench, and needs a modest volume at high suction. General ventilation dilutes what escapes across the whole workshop, and needs a very large volume at low pressure. Most compliant installations use both, sized separately.

WhoWho buys it

Fabrication and structural steel shops, shipyards and rail workshops, automotive body repair, training centres, and the occupational hygiene consultants who specify after an exposure survey.

WhyWhy dilution alone rarely passes

Welding fume is respirable metal oxide, and for stainless and coated steels it contains hexavalent chromium and manganese compounds with very low exposure limits. Diluting to below those limits across an entire workshop volume takes an implausible air change rate. Capture at the arc removes the fume before it reaches the welder’s breathing zone, which is what an exposure measurement actually reflects.

HowSizing the two systems separately

For source capture, work from the capture velocity needed at the arc and the distance the hood sits from it — effectiveness falls off with the square of that distance, so hood placement matters more than fan size. For general ventilation, size on the workshop volume and the residual fume that escapes capture. Then check that the fan holds its duty against filter resistance, which rises steeply as cartridges load with fine particulate.

Equipment this application needs

Centrifugal Fans High-vacuum extraction Centrifugal Fans11,344 Source capture needs suction rather than volume — backward-curved and high-pressure impellers. Axial Flow Fans General workshop ventilation Axial Flow Fans6,332 Large volumes at low resistance to dilute what escapes capture. Radial Fans Particulate-laden air Radial Fans576 Straight radial blades pass fine particulate without building deposits that unbalance the impeller. Blowers Compressed & process air Blowers820 Filter cleaning pulses and shielding gas handling around the cell. Industrial Fans Operator cooling Industrial Fans1,055 Welders work in heavy PPE next to a heat source; spot cooling is a real requirement, not a comfort extra.

What to check before you order

Industrial Grade 12,410
Continuous duty in a hot, dusty shop with minimal maintenance access.
High Temperature 2,144
Extract air close to the arc carries significant heat.
Variable Speed 2,411
Matches suction to the number of stations actually welding.
Explosion Proof 2,418
Required where aluminium or magnesium dust is present in the same extract system.
380V 15,604
Three-phase for multi-station extraction plant.

Products for this application

Questions buyers ask

Is general ventilation enough for welding fume?
Rarely. Exposure limits for the metal oxides in weld fume — particularly hexavalent chromium from stainless work — are low enough that diluting across a whole workshop needs an air change rate that is impractical to achieve or heat. Capture at the arc is what brings the welder’s breathing-zone measurement down; general ventilation handles the residue.
Why does hood distance matter so much?
Because capture velocity falls off roughly with the square of the distance from the hood. Moving a hood from 150 mm to 300 mm away can cut the velocity at the arc to a quarter, which no realistic increase in fan size will compensate for. Positioning discipline is a bigger factor in real performance than equipment selection.
What happens to extraction performance as filters load?
Resistance rises and airflow falls, so a system that passed on commissioning can fail an exposure survey months later with no visible change. Select fans that hold volume against rising pressure, monitor filter differential, and treat cartridge replacement as a compliance task rather than maintenance housekeeping.
