This axial flow fan is published with the manufacturer’s full specification — 220V/380V/440V, power source Electric. Made by Shandong Hanqi Industrial Co., Ltd. (5 years on the platform, typical reply ≤3h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Axial Flow Fan
- Model Number: HQ
- Power Source: Electric
- Power(KW): 5-250
- Voltage: 220V/380V/440V
- Material: Cast Iron
- Blade Material: Stainless Steel
Technical Specifications
| Blade Diameter | 600mm |
|---|---|
| Voltage | 220V/380V/440V |
| Speed | 2900rpm |
| Type | tunnel fan |
| Material | Cast Iron |
| Blade Material | Stainless Steel |
| Mounting Type | Duct Fan |
| Bearing Type | Sleeve Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM, OBM |
| Place Of Origin | Shandong, China |
| Brand Name | hanqi |
| Model Number | HQ |
| Power(KW) | 5-250 |
| Rotating Speed(R/Min) | 980-2800 |
| Air Volume (M³/Min) | 90-9500 |
| Pressure(Pa) | 275-9000 |
| Color | Red/white/grey/yellow/blue/customized |
| Package | Wooden case |
| Motor Type | AC Motor |
| Application | Exhaust Ventilation |
| Selling Units | Single item |
Product Details
Fan type | Rpm(r'min) | Pressure(pa) | Air Volume(m³/h) | Motor power(kw) |
3.55 | 1.4 | 1346-2878 | 50.3-73.1 | 0.04-0.12 |
4 | 2.8 | 3843-8207 | 255.7-371.2 | 0.75-2.2 |
4 | 1,400 | 1924-4114 | 64-92.8 | 0.09-0.25 |
4.5 | 1,400 | 2740-5858 | 80.9-117.5 | 0.12-0.37 |
5 | 1,400 | 4141-8412 | 105-153.4 | 0.25-0.75 |
5 | 910 | 2691-5468 | 44.1-64.5 | 0.37 |
5.6 | 1,400 | 5817-11817 | 131.4-192 | 0.37-1.1 |
5.6 | 910 | 3781-7681 | 55.5-81.1 | 0.37 |
6.3 | 1,450 | 8579-17426 | 178.3-260.7 | 0.75-2.2 |
6.3 | 935 | 5532-11234 | 74.2-108.4 | 0.37-0.75 |
7.1 | 1.45 | 12280-24944 | 226.5-331 1 | 1.5-4 |
7.1 | 935 | 7918-16084 | 94.2-137.7 | 0.75-1.1 |
8 | 1,450 | 17567-35682 | 287.6-420.3 | 3-7.5 |
8 | 960 | 11630-23624 | 126.1-184.2 | 0.75-2.2 |
9 | 960 | 16560-33937 | 159.5-233.2 | 1.5-4 |
10 | 960 | 22716-46141 | 197-287.9 | 2.2-7.5 |
11.2 | 960 | 31914-64825 | 247-361.1 | 4 – 11 |
We can customize it to your needs！
* Function: The fan is generally hung on the top or both sides of the room, does not occupy the building area, and does not need to build another air duct, and has the characteristics of high efficiency, low noise, stable operation and easy maintenance.
OEM&ODM
ELITE TEAM
Ordering and Pricing
- Minimum order quantity: 9 piece
- Volume pricing:
- 9–9 piece: US $250 / piece
- 10–28 piece: US $213 / piece
- 29+ piece: US $190 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this axial flow fan?
The standard minimum order quantity is 9 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the axial flow fan be supplied for my local voltage?
The standard configuration is 220V/380V/440V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shandong Hanqi Industrial Co., Ltd., based in China. The company 5 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Shandong Hanqi Industrial Co., Ltd. range on HVACR Nexus.
