Boiler, DAYE, Stainless, Steel

The boiler listed here carries material Stainless Steel, type Gas Burner, documented exactly as the manufacturer publishes it. Made by Changzhou Daye Energy Technology Co., Ltd. (1 year on the platform, typical reply ≤6h). Send your target quantity and destination for a firm quotation with current lead times.

Key Features of This Boiler

• Material: Stainless Steel
• Warranty: 1 Year
• Place Of Origin: Jiangsu, China (Mainland)
• Application: Boiler combustion assistance, welding, cutting, decarbonization
• Type: Gas Burner
• Single Package Size: 1360.0X1060.0X1690.0 cm

Technical Specifications

Product Details

DAYE ENERGY

Application in Boiler Combustion Industry

Principle introduction:

Using water electrolysis to produce hydrogen and oxygen, hydrogen serves as fuel, oxygen supports combustion, and ignites to generate a hydrogen oxygen flame. Without the need for additional oxygen cylinders, it can replace carbon containing gases such as acetylene, coal gas, and liquefied gas, and has the characteristics of safety, environmental protection, energy conservation, and high efficiency. The characteristics of high temperature, high energy, and concentrated firepower enable the welding parts of the transformer to be instantly welded together, with sturdy and beautiful welding points and no black smoke or exhaust gas generated.

Product Features::

1. Safety, gas can be used and produced immediately without storage, with multiple built-in fire prevention devices to eliminate safety hazards caused by backfire 2. Environmental protection, hydrogen oxygen flame comes from water, and after combustion, it becomes water vapor and is reduced to water. There is no black smoke or exhaust gas produced during the combustion process, and there is no harm 3. Efficient, no need to purchase bottled gas, no need for dedicated supervision, no need for dedicated storage areas 4. Energy saving, hydrogen oxygen flame can be generated with only a small amount of water and electricity, saving costs by 35% -70% 5. Low pressure gas supply for hydrogen oxygen welding machine, not a pressure vessel, 6. Flame temperature of 3000 ° C, no thermal radiation, wide applicability 7. Completely replace traditional welding processes (acetylene gas, electric welding, etc.) 8. Daye Energy's hydrogen oxygen energy equipment has multiple national certificates, ISO9001 certification, CE certification, FCC certification, etc.

MODEL PARAMETERS

Model	DY100	DY200	DY300	DY400	DY600	DY1000
AC Voltage(V)	220/110	220/110	220/110	220/110	220/110	220/110
Rated Power(KW)	0.4	0.8	1.2	1.6	2.4	3.5
Max.Working Pressure(Mpa)	0.2	0.2	0.2	0.2	0.2	0.2
Flame temperature	3000°	3000°	3000°	3000°	3000°	3000°
Max.Gas output(L/h)	0-100	0-200	0-300	0-400	0-600	0-1000
Max.Water Consumption(L/h)	0.05	0.11	0.16	0.22	0.32	0.54
Water Feed	manual	manual	manual	manual	manual	manual
Dimension- L*W*H(mm)	380*250*480	450*250*480	580*250*480	680*250*480	880*250*480	660*600*78 0
Gross Weight(kg)	12	17	22	26	45	95

Model	DY2000	DY3500	DY6000	DY7500	DY10000	DY20000
AC Voltage(V)	380,threephase	380,threephase	380,threephase	380,threephase	380,threephase	380,threephase
Rated Power(KW)	7	12	21	26	35	70
Max.Working Pressure(Mpa)	0.2	0.2	0.2	0.2	0.2	0.2
Flame temperature	3000°	3000°	3000°	3000°	3000°	3000°
Max.Gas output(L/h)	0-2000	0-3500	0-6000	0-7500	0-10000	0-20000
Max.Water Consumption(L/h)	1.1	1.9	3.2	4.0	5.4	10.7
Water Feed	auto	auto	auto	auto	auto	auto
Dimension- L*W*H(mm)	1100*670*1030	1130*770*1300	1300*950*1670	1300*950*1880	1500*910*1920	2300*1010*2050
Gross Weight(kg)	180	360	500	650	900	1400

PROCESS COMPARISON

Traditional gas welding	PK	Hydrogen-oxygen welding machine
Gas cylinders and oxygen cylinders are classified as pressure vessels with extremely high risk levels. In the past, some factories have suffered significant losses due to fires caused by gas leaks.	Gas supply principle	Hydroelectrolysis generates hydrogen and oxygen gases, which are used immediately without storage, eliminating all safety hazards.
Flame heating welding	Welding method	Flame heating welding
For flammable and explosive gases, gas cylinders must be upright and securely fixed, protected from compression, impact, and direct sunlight exposure. When replacing gas cylinders, handle with gentle and cautious force. When used in conjunction with other flammable gases such as oxygen, maintain a safety distance of at least 5 meters and implement appropriate protective measures.	Safety	The hydroelectrolysis process generates hydrogen and oxygen gases, which are used immediately without storage. The system automatically activates during operation and shuts down when idle, with a working pressure below 0.1Mpa. There is no explosion risk, and the equipment is equipped with multiple fire prevention devices to ensure 100% safety.
The prices of bottled oxygen and acetylene have been rising year after year, leading to a continuous increase in gas usage costs. Currently, the price of oxygen is approximately 30 yuan per bottle, while acetylene costs 1 80 yuan per bottle.	Energy saving	It consumes only a minimal amount of water and electricity, achieving over 40% energy savings compared to oxyacetylene.
When burning, it produces black smoke exhaust and emits toxic gases such as hydrogen sulfide and phosphine, causing continuous environmental pollution and harming the health of operators.	Environmental protection	The raw material is water, which produces no black smoke emissions during combustion and converts into water vapor for evaporation. This hydrogen energy device is recyclable and regenerable.
All personnel must undergo corresponding safety training prior to commencing duties to minimize the risk of accidents. However, even if manual operations are deemed compliant, outdated hardware supply equipment cannot eliminate potential hazards.	Experience requirement	Smart one-touch operation: press the confirm button to start gas production, and the welding gun automatically pauses when turned off. No prior experience required—learn and use instantly, with guaranteed safety and reliability.

Changzhou Daye Energy Technology Co., Ltd. is a specialized high-tech enterprise that has been dedicated to the
research,development, production, and sales of hydrogen and oxygen production equipment from electrolyzed water for 18 years.
The company's products include: hydrogen and oxygen generators, hydrogen and oxygen machines, car carbon removal machines,
hydrogen and oxygen cutting machines, water welding machines, hydrogen production equipment, etc. The company holds multiple
national patents and independent intellectual property rights. Daye Energy boasts a first-class research and development center
and a specialized production base, along with an experienced technical research team.Through years of accumulation and
improvement, the company has established a complete scientific management and quality inspection system.

The DY series sixth-generation hydrogen and oxygen generator produced by our company adopts high-voltage inverter DC pulse
technology, It is a new generation of industrial-grade, high-efficiency, and energy-saving hydrogen-oxygen generator.breaking
through the technical difficulties of low efficiency and high power consumption in hydrogen and oxygen production through water
electrolysis. Daye Energy Technology originates from the Hydrogen Energy Research Institute of Tsinghua University, and combines
the practical and efficient features of hydrogen-oxygen generators from companies such as Eagle-Research Institute in Canada, Yu
II Browns in Australia, and William Rhodes and Bob Boyce in the United States.The efficiency of electrolyzing mixed gas reaches
over 95%. The product is technologically advanced, with high energy conversion efficiency, using water as the raw material to
achieve low-cost industrialized and large-scale production of hydrogen and oxygen. During the production process, no harmful gases
are generated.

The hydrogen andoxygen equipment is widely used in various industries such as metallurgy, motor industry, metal welding,
refrigeration, steel making, automobile maintenance, aerospace, cutting industry, energy-saving renovation, etc. It is
characterized by safety, energy saving, high efficiency, and environmental protection.

WELDING APPLICATION

Transformer welding

Motor industry

Refrigeration industry

Fused quartz glass sealing

Automotive carbon removal industry

Acrylic polishing

Welding jewelry, bronzes and musical instruments

Cutting heating Steel plate

Transparent layer detection of quartz sand sample

Q1. Can I use my own brand logo or custom appearance design on the hydrogen oxygen welder?
Answer: Yes, we provide full ODM/OEM customization services. Not only can we print your brand LOGO on the welder body and control
panel, but also customize the equipment appearance color matching, operation interface layout, etc., to meet the brand
differentiation display needs.


Q2. Does your company have its own production factory? Is factory visits supported?
Answer: We have a standardized production base in Changzhou, Jiangsu Province, equipped with a hydrogen oxygen core component
production line and a finished product assembly workshop. You are welcome to visit the factory on site at any time.


Q3. What is the delivery time for the hydrogen oxygen welder, and is there any stock in inventory?
Answer: The conventional standard model is in stock, and delivery can be arranged within 3 working days after confirming the
order; the customized model needs to be determined according to the design scheme and production schedule, and the production is
generally completed within 15-25 working days; if you have urgent order requirements, we can prioritize production scheduling, and
the delivery can be as soon as 10 working days.


Q4. What kind of support can your company provide for the transportation and customs clearance links of the hydrogen oxygen welder?
Answer: We can provide a variety of transportation options, such as sea, air, and express, and provide you with a full set of
export customs clearance documents (commercial invoice, packing list, certificate of origin, product certification certificate,
etc.); for trade barriers in some countries, we will also assist you in advance to avoid risks and ensure the smooth customs
clearance of goods.


Q5. What is the warranty period for the hydrogen oxygen welder, and what does the warranty scope include?
Answer: We provide a one-year free warranty service for the whole machine. During the warranty period, non-human parts can be
replaced or repaired free of charge; after the warranty period, we still provide lifelong technical support and cost price supply
of spare parts services to ensure the long-term stable operation of the equipment.


Q6. What support can your company provide if there are technical issues after purchase?
Answer: We have a multi-language technical team that provides remote technical guidance 7×12 hours a day. Through online video,
telephone, email, and other ways, we can provide remote technical guidance to quickly solve problems such as equipment
installation, commissioning, operation, and fault diagnosis; if remote cannot be solved, we can also arrange professional
engineers to provide on-site service (overseas areas need to negotiate travel expenses according to the actual situation).


Q7. Does your company provide product operation training services?
Answer: Yes, we will provide customers with free operation training: we can send detailed text and picture operation manuals,
video tutorials, and also arrange online training to explain the equipment principle, operation process, safety regulations, and
daily maintenance points.


Q8. Do I need to replace consumables during the use of the equipment, and is it convenient to supply consumables?
Answer: The core consumables of the equipment are electrolyte and filter element, and the replacement frequency of such
consumables is low (electrolyte is replaced once every 6-12 months, and the filter element is replaced once every 3-6 months); we
have various consumables in stock all year round, which can be shipped together with the equipment, or mailed separately according
to customer needs, and generally it takes 7-15 working days to arrive after ordering for overseas customers.

Ordering and Pricing

• Minimum order quantity: 1 set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this boiler?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Changzhou Daye Energy Technology Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Changzhou Daye Energy Technology Co., Ltd. range on HVACR Nexus.
