This centrifugal blower is published with the manufacturer’s full specification — 380v/220v/110v, material Stainless Steel. Made by Guangzhou Xinfeng Fan Co., Ltd. (13 years on the platform, typical reply ≤5h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Centrifugal Blower
- Model Number: XF-560
- Voltage: 380v/220v/110v
- Material: Stainless Steel
- Blade Material: Stainless Steel
- Warranty: 3 Years
- Certification: CE/RoHS/ISO9001/CCC
Technical Specifications
| Mounting | Free Standing |
|---|---|
| Voltage | 380v/220v/110v |
| Motor Type | AC Motor |
| Material | Stainless Steel |
| Blade Material | Stainless Steel |
| Warranty | 3 Years |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM |
| Place Of Origin | Guangdong, China |
| Brand Name | Suifeng |
| Model Number | XF-560 |
| Product Name | Suifeng Blower Vortex Roots Industrial Vacuum Backward Centrifugal Fan |
| Total Pressure | 950-850 Pa |
| Hertz | 50Hz/60Hz |
| Water Proof Standard | IP44/IP54/IP55 |
| Insulation Level | B/F/H |
| Motor | frequency conversion/explosion proof |
| Certification | CE/RoHS/ISO9001/CCC |
| Working Temperature | less than 600 ℃ degree Celsius |
| Size | 665*334*801mm |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Mode | Puver | Fan | Alr FloW | Drive | Voltage |
Speed | |||||
XF315 | 250W | 1420RPM | 2700CMH | Direct DTV | 220-240V/50HZ |
XF355 | 550W | 1400RPM | 5200CMH | Direct Drive | 220/240/380/415V-50HZ |
750W | 1720RPM | 6500CMH | Rolt Drive | 220/240/380/415V-50HZ | |
XF400 | 750W | 1400RPM | 6800CMH | Direct Drive | 220/240/380/415V-50HZ |
1.1kw | 1720RPM | 8100CMH | Belt Drive | 220/240/380/415V-50HZ | |
XF450 | 750W | 1200RPM | 9000CMH | Belt Drive | 220/240/380/415V-50HZ |
1.1kw | 1400RPM | 1000CMH | Direct Drive | 220/240/380/415V-50HZ | |
XF500 | 1.1kw | 960RPM | 10000CMH | Belt Drive | 220/240/380/415V-50HZ |
1.5kw | 1200RPM | 12500CMH | Direct Drive | 220/240/380/415V-50HZ | |
XF560 | 1.5kw | 960RFM | 22000CMH | Direct DTV | 220/240/380/415V-50HZ |
2.2kw | 1200RPM | 27000CMH | Belt Drive | 380/415V-50HZ | |
XF630 | 2.2kw | 960RPM | 16000CMH | Direct Drive | 380/415V-50HZ |
1.1kW | 720RPM | 13000CMH | Direct Dnivye | 220/240/380/415V-50HZ | |
1.5kw | 850RPM | 14800CMH | Belt Drive | 220/240/380/415V-50HZ | |
3kw | 1200RPM | 20000CMH | Belt Drive | 380/415V-50HZ | |
XF710 | 4kw | 960RPM | 25000CMH | Direct Drive | 380/415V,50/60HZ |
2.2kw | 720RPM | 18000CMH | Dirpct Driva | 380/415V.50/60HZ | |
5kw | 1150RPM | 29000CMH | Bplt DTIVB | 380/415V.50/60HZ | |
XF800 | 5.5kw | 960RPM | 28000CMH | Direct Dnivye | 380/415V,50/60HZ |
4kW | 720RPM | 21000CMH | Direct Drive | 380/415V,50/60HZ | |
75kw | 1100RPM | 32000CMH | Rplt DTive | 380/415V.50/60HZ | |
XFB-800 | 960 | 16535-25500 | 860-370 | 5.5 | |
1470 | 24975-38515 | 1960-850 | 18.5 |
1.Do you have MOQ?
2.How long is the product's warranty?
3.Can you provide OEM or ODM?
4.Are you a manufacturer or a trader?
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–9 set: US $100 / set
- 10+ set: US $80 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal blower?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this centrifugal blower carry?
It is supplied with CE/RoHS/ISO9001/CCC documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the centrifugal blower be supplied for my local voltage?
The standard configuration is 380v/220v/110v. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Guangzhou Xinfeng Fan Co., Ltd., based in China. The company 13 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Guangzhou Xinfeng Fan Co., Ltd. range on HVACR Nexus.
