Centrifugal fan — 220V/380V, blade material Iron. The complete factory specification follows. Made by Dongguan Sop Mechanical And Electrical Co., Ltd. (17 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Centrifugal Fan
- Model Number: SOP4-72A
- Voltage: 220V/380V
- Blade Material: Iron
- Material: Iron
- Warranty: 1 Year
- Place Of Origin: Jiangxi, China
Technical Specifications
| Mounting | Free Standing |
|---|---|
| Voltage | 220V/380V |
| Blade Material | Iron |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM |
| Place Of Origin | Jiangxi, China |
| Model Number | SOP4-72A |
| Name | Centrifugal Bower |
| Material | Iron |
| Application | for Construction Sites |
| Feature | High Air Volume |
| Usage | Construction Sites |
| Function | Ventilaion |
| Keyword | Industrial Centrifugal Fan |
| Type | Centrifugal Impeller Blower |
| Color | Customized Colors |
| Impeller | Metal Impeller |
| Selling Units | Single item |
Product Details
The gas temperature shall not exceed 80 ℃. This fan has good aerodynamic performance, low vibration, high efficiency, and long service life. There are four types of structures: A, B, C, and D. This fan is widely used for indoor ventilation and air exchange in industrial and mining enterprises, large buildings, hotels and restaurants.
Machine No. | Motor Speed (r/m) | Motor Power (kw-P) | Flow (m³/h) | Total Pressure (Pa) | |
2A | 2900 | 0.55-2 three phase | 570-980 | 620-380 | |
2.5A | 2900 | 0.75-2 single phase | 805-1677 | 792-483 | |
2900 | 1.1-2 single phase | 1025-1966 | 855-585 | ||
2.8A | 2900 | 1.5-2 single phase | 1131-2356 | 994-606 | |
3.2A | 1450 | 1.1-4 three phase | 884-1758 | 324-198 | |
2900 | 2.2-2 single phase | 1688-3517 | 1300-792 | ||
2900 | 2.2-2 three phase | 1688-3517 | 1300-792 | ||
3.6A | 1450 | 1.1-4 three phase | 1332-2634 | 393-247 | |
2900 | 3-2 single phase | 2664-5268 | 1578-989 | ||
2900 | 3-2 three phase | 2664-5268 | 1578-989 | ||
4A | 1450 | 1.1-4 single phase | 2006-3709 | 501-329 | |
1450 | 1.1-4 three phase | 2006-3709 | 501-329 | ||
2900 | 5.5-2 three phase | 4012-7419 | 2014-1320 | ||
4.5A | 1450 | 1.1-4 three phase | 2856-5281 | 634-416 | |
2900 | 7.5-2 three phase | 5712-10562 | 2554-1673 | ||
5A | 1450 | 2.2-4 three phase | 3864-7728 | 790-502 | |
2900 | 15-2 three phase | 7728-15445 | 3187-2019 | ||
5.6A | 1450 | 3-4 three phase | 7062-9885 | 951-759 | |
2900 | 18.5-2 three phase | 12940-13450 | 3375-2765 | ||
6A | 960 | 1.5-6 three phase | 4420-8841 | 498-317 | |
1450 | 4-4 three phase | 6677-13353 | 1139-724 | ||
6.3A | 1450 | 7.5-4 three phase | 11158-15618 | 1538-1218 | |
960 | 5.5-6 three phase | 6973-9761 | 600-475 | ||
7.1A | 960 | 3-6 three phase | 8392-13581 | 689-512 | |
1450 | 11-4 three phase | 12676-20513 | 1573-1168 | ||
8A | 1450 | 18.5-4 three phase | 15826-29344 | 2032-1490 | |
960 | 5.5-6 three phase | 10478-19428 | 887-651 |
Ordering and Pricing
- Minimum order quantity: 1 set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal fan?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the centrifugal fan be supplied for my local voltage?
The standard configuration is 220V/380V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
