This centrifugal fan is published with the manufacturer’s full specification — voltage Other, 220 V, 380 V, power source type Corded Electric. Made by Shandong Hanqi Industrial Co., Ltd. (5 years on the platform, typical reply ≤3h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Centrifugal Fan
- Model Number: HTFC
- Power Source Type: Corded Electric
- Voltage: Other, 220 V, 380 V
- Material: Stainless Steel
- Blade Material: Stainless Steel
- Noise Level: 35–39 dB
Technical Specifications
| Duct Diameter | 14 in |
|---|---|
| Mounting | Free Standing |
| Voltage | Other, 220 V, 380 V |
| Motor Type | AC Motor |
| Speed | 1500 RPM, 3 000 RPM |
| Material | Stainless Steel |
| Blade Material | Stainless Steel |
| Power Source Type | Corded Electric |
| Warranty | 2 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM, OBM |
| Noise Level | 35–39 dB |
| Place Of Origin | Shandong, China |
| Brand Name | HANQI |
| Model Number | HTFC |
| Type | Centrifugal Fan |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Customized production can be made according to your needs
spontaneous, non explosive, volatile, not on the gas harmless, non corrosive to steel. But the transportation of gas not containing viscous substances,dust and hard particles contained no more than 150mg/m³,gas temperature should not exceed 80°C.
Fan type | Rpm(r/min) | Pressure(Pa) | Air Volume(m³/h) | Motor power(Kw) |
2.8A | 2900 | 994-606 | 1131-2356 | 1.5 |
3.2A | 2900 | 1300-792 | 1688-3517 | 2.2 |
3.2A | 1450 | 324-198 | 844-1758 | 3 |
3.6A | 2900 | 1758-989 | 2664-5268 | 1 |
3.6A | 1450 | 393-247 | 1332-2634 | 1.1 |
4A | 2900 | 2014-1320 | 4012-7419 | 6 |
4A | 1450 | 501-329 | 2006-3709 | 1.1 |
4.5A | 2900 | 2554-1673 | 416-634 | 8 |
4.5A | 1450 | 10562-5712 | 2856-5281 | 1.1 |
5A | 2900 | 3187-2019 | 7728-15455 | 15 |
5A | 1450 | 790-502 | 3864-7728 | 2.2 |
6A | 1450 | 1139-724 | 6677-13353 | 4 |
6A | 960 | 498-317 | 4420-8841 | 1.5 |
60 | 1450 | 1139-724 | 6677-13353 | 4 |
60 | 960 | 498-317 | 4420-8841 | 2 |
8D | 1450 | 2032-1490 | 15826-29344 | 19 |
80 | 960 | 887-651 | 10478-19428 | 5.5 |
8D | 730 | 512-376 | 7968-14773 | 3 |
10D | 1450 | 3202-2532 | 40441-56605 | 55 |
10D | 960 | 1395-1104 | 26775-37476 | 18.5 |
10D | 730 | 805-637 | 20360-28497 | 7.5 |
12D | 960 | 2013-1593 | 46267-64759 | 45 |
12D | 730 | 1160-919 | 35182-49244 | 18.5 |
6C | 2240 | 2734-1733 | 10314-20628 | 15 |
6C | 2000 | 2176-1380 | 9205-18418 | 11 |
6C | 1800 | 1760-1116 | 8288-17056 | 7.5 |
6C | 1600 | 1389-881 | 7367-14734 | 5.5 |
6C | 1250 | 846-537 | 5756-11511 | 3 |
6C | 1120 | 679-431 | 5157-10314 | 2.2 |
6C | 1000 | 541-344 | 4144-8288 | 2.2 |
6C | 900 | 438-278 | 4144-8288 | 1.5 |
6C | 800 | 346-220 | 3684-7367 | 1.1 |
8C | 1800 | 3032-3143 | 19646-25240 | 30 |
8C | 1800 | 2302-2920 | 28105-36427 | 37 |
8C | 1600 | 2390-2478 | 17463-22435 | 55 |
8C | 1600 | 2303-1816 | 24982-32380 | 30 |
8C | 1250 | 1507-1106 | 13643-25297 | 11 |
8C | 1120 | 1209-1166 | 12224-15705 | 7.5 |
8C | 1120 | 1124-887 | 17487-22666 | 11 |
8C | 1000 | 963-929 | 10914-14022 | 5.5 |
8C | 1000 | 895-707 | 15614-20237 | 7.5 |
8C | 900 | 779-752 | 9823-12620 | 4 |
8C | 900 | 725-572 | 14052-18213 | 5.5 |
8C | 800 | 615-452 | 8732-16190 | 3 |
8C | 710 | 485-468 | 749-9956 | 2.2 |
8C | 710 | 450-356 | 11085-14368 | 3 |
8C | 630 | 381-280 | 6876-12749 | 2.2 |
10C | 1250 | 2373-1877 | 34863-48797 | 37 |
10C | 1120 | 1902-1505 | 31237-43722 | 30 |
10C | 1000 | 1514-1199 | 27890-39038 | 19 |
10C | 900 | 1225-970 | 25101-35134 | 15 |
10C | 800 | 967-766 | 22312-31230 | 11 |
10C | 710 | 761-603 | 19082-27717 | 7.5 |
10C | 630 | 599-475 | 17571-24594 | 535 |
10C | 560 | 473-375 | 15618-21861 | 4 |
10C | 500 | 377-299 | 13945-19519 | 3 |
12C | 1120 | 2746-2172 | 53978-75552 | 75 |
12C | 1000 | 2185-1969 | 48195-60397 | 45 |
12C | 1000 | 1859-1729 | 63953-67457 | 55 |
12C | 900 | 1767-1399 | 43375-60712 | 37 |
12C | 800 | 1395-1376 | 38556-41973 | 22 |
12C | 800 | 1321-1104 | 45391-53966 | 30 |
12C | 710 | 1097-869 | 34218-47895 | 18.5 |
12C | 630 | 883-684 | 30362-42498 | 15 |
12C | 560 | 682-673 | 26989-29381 | 7.5 |
12C | 560 | 646-540 | 31774-37776 | 1 |
12C | 500 | 543-430 | 24097-33728 | 7.5 |
12C | 450 | 440.434 | 21687-23610 | 4 |
12C | 450 | 417-348 | 25532-30356 | 5.5 |
12C | 400 | 347-275 | 19278-26983 | 3 |
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1+ piece: US $700 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal fan?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the centrifugal fan be supplied for my local voltage?
The standard configuration is Other, 220 V, 380 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
