Manufactured by Shandong Hanqi Industrial, this centrifugal fans is documented here exactly as the factory publishes it. Supplier profile: 5 years on the platform. Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of These Centrifugal Fans
- 安装方式: 管道风扇
- 电压: 220/380/400/450/600v
- 电机类型: 交流电动机
- 材质: 不锈钢
- 刀片材质: 不锈钢
- 电源类型: Corded Electric
Technical Specifications
| 安装方式 | 管道风扇 |
|---|---|
| 电压 | 220/380/400/450/600v |
| 电机类型 | 交流电动机 |
| 材质 | 不锈钢 |
| 刀片材质 | 不锈钢 |
| 电源类型 | Corded Electric |
| 保修 | 1年 |
| 售后服务 | 在线支持 |
| 定制服务 | OEM, ODM, OBM |
| 噪音等级 | 40db及以上 |
| 产地 | Shandong, China |
| 品牌名称 | HANQI |
| 型号 | 4-68/4-72 |
| 产品名称 | 工业离心风机 |
| 应用程序 | 排气通风 |
| 尺寸 | 客户的要求 |
| 电机 | 交流电机 |
| 功能 | 耐高温工作 |
| 姓名 | 交流离心鼓风机 |
| 用法 | 高压吹气 |
| 关键词 | 高压防腐玻璃钢离心风机 |
| 销售单位 | 单个商品 |
| 单个包装尺寸 | 100X100X100 厘米 |
| 单个产品毛重 | 20.000 公斤 |
Product Details
Customized production can be made according to your needs
spontaneous, non explosive, volatile, not on the gas harmless, non corrosive to steel. But the transportation of gas not containing viscous substances,dust and hard particles contained no more than 150mg/m³,gas temperature should not exceed 80°C.
Fan type | Rpm(r/min) | Pressure(Pa) | Air Volume(m³/h) | Motor power(Kw) |
2.8A | 2900 | 994-606 | 1131-2356 | 1.5 |
3.2A | 2900 | 1300-792 | 1688-3517 | 2.2 |
3.2A | 1450 | 324-198 | 844-1758 | 3 |
3.6A | 2900 | 1758-989 | 2664-5268 | 1 |
3.6A | 1450 | 393-247 | 1332-2634 | 1.1 |
4A | 2900 | 2014-1320 | 4012-7419 | 6 |
4A | 1450 | 501-329 | 2006-3709 | 1.1 |
4.5A | 2900 | 2554-1673 | 416-634 | 8 |
4.5A | 1450 | 10562-5712 | 2856-5281 | 1.1 |
5A | 2900 | 3187-2019 | 7728-15455 | 15 |
5A | 1450 | 790-502 | 3864-7728 | 2.2 |
6A | 1450 | 1139-724 | 6677-13353 | 4 |
6A | 960 | 498-317 | 4420-8841 | 1.5 |
60 | 1450 | 1139-724 | 6677-13353 | 4 |
60 | 960 | 498-317 | 4420-8841 | 2 |
8D | 1450 | 2032-1490 | 15826-29344 | 19 |
80 | 960 | 887-651 | 10478-19428 | 5.5 |
8D | 730 | 512-376 | 7968-14773 | 3 |
10D | 1450 | 3202-2532 | 40441-56605 | 55 |
10D | 960 | 1395-1104 | 26775-37476 | 18.5 |
10D | 730 | 805-637 | 20360-28497 | 7.5 |
12D | 960 | 2013-1593 | 46267-64759 | 45 |
12D | 730 | 1160-919 | 35182-49244 | 18.5 |
6C | 2240 | 2734-1733 | 10314-20628 | 15 |
6C | 2000 | 2176-1380 | 9205-18418 | 11 |
6C | 1800 | 1760-1116 | 8288-17056 | 7.5 |
6C | 1600 | 1389-881 | 7367-14734 | 5.5 |
6C | 1250 | 846-537 | 5756-11511 | 3 |
6C | 1120 | 679-431 | 5157-10314 | 2.2 |
6C | 1000 | 541-344 | 4144-8288 | 2.2 |
6C | 900 | 438-278 | 4144-8288 | 1.5 |
6C | 800 | 346-220 | 3684-7367 | 1.1 |
8C | 1800 | 3032-3143 | 19646-25240 | 30 |
8C | 1800 | 2302-2920 | 28105-36427 | 37 |
8C | 1600 | 2390-2478 | 17463-22435 | 55 |
8C | 1600 | 2303-1816 | 24982-32380 | 30 |
8C | 1250 | 1507-1106 | 13643-25297 | 11 |
8C | 1120 | 1209-1166 | 12224-15705 | 7.5 |
8C | 1120 | 1124-887 | 17487-22666 | 11 |
8C | 1000 | 963-929 | 10914-14022 | 5.5 |
8C | 1000 | 895-707 | 15614-20237 | 7.5 |
8C | 900 | 779-752 | 9823-12620 | 4 |
8C | 900 | 725-572 | 14052-18213 | 5.5 |
8C | 800 | 615-452 | 8732-16190 | 3 |
8C | 710 | 485-468 | 749-9956 | 2.2 |
8C | 710 | 450-356 | 11085-14368 | 3 |
8C | 630 | 381-280 | 6876-12749 | 2.2 |
10C | 1250 | 2373-1877 | 34863-48797 | 37 |
10C | 1120 | 1902-1505 | 31237-43722 | 30 |
10C | 1000 | 1514-1199 | 27890-39038 | 19 |
10C | 900 | 1225-970 | 25101-35134 | 15 |
10C | 800 | 967-766 | 22312-31230 | 11 |
10C | 710 | 761-603 | 19082-27717 | 7.5 |
10C | 630 | 599-475 | 17571-24594 | 535 |
10C | 560 | 473-375 | 15618-21861 | 4 |
10C | 500 | 377-299 | 13945-19519 | 3 |
12C | 1120 | 2746-2172 | 53978-75552 | 75 |
12C | 1000 | 2185-1969 | 48195-60397 | 45 |
12C | 1000 | 1859-1729 | 63953-67457 | 55 |
12C | 900 | 1767-1399 | 43375-60712 | 37 |
12C | 800 | 1395-1376 | 38556-41973 | 22 |
12C | 800 | 1321-1104 | 45391-53966 | 30 |
12C | 710 | 1097-869 | 34218-47895 | 18.5 |
12C | 630 | 883-684 | 30362-42498 | 15 |
12C | 560 | 682-673 | 26989-29381 | 7.5 |
12C | 560 | 646-540 | 31774-37776 | 1 |
12C | 500 | 543-430 | 24097-33728 | 7.5 |
12C | 450 | 440.434 | 21687-23610 | 4 |
12C | 450 | 417-348 | 25532-30356 | 5.5 |
12C | 400 | 347-275 | 19278-26983 | 3 |
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–19 piece: US $500 / piece
- 20+ piece: US $300 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal fans?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shandong Hanqi Industrial Co., Ltd., based in China. The company 5 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Shandong Hanqi Industrial Co., Ltd. range on HVACR Nexus.
