Cooled screw water chiller — voltage 220, 130KW. The complete factory specification follows. Made by Tongxing Air Conditioning Technology Co., Ltd. (11 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Cooled Screw Water Chiller
- Cooling Power Input: 24.4KW
- Voltage: 220
- Cooling Capacity: 130KW
- Heating Capacity: 75KW
- Material: Copper
- Warranty: 2 Years
Technical Specifications
| Heat Exchanger Type | Plate Heat Exchanger |
|---|---|
| Material | Copper |
| Voltage | 220 |
| Core Components | Engine, Pump |
| Warranty | 2 Years |
| Machinery Test Report | Not Available |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Competitive Price |
| Place Of Origin | Henan, China |
| Weight (Kg) | 1500 |
| Brand Name | TX |
| Liquid Flow Rate | none |
| Maximum Pressure Rating | none |
| Type | COMPRESSOR |
| Item | Modular Air Cooled Water Chiller Series |
| Cooling Capacity | 130KW |
| Model No | LR130TXZZ |
| Cooling Power Input | 24.4KW |
| Compressor Qty/Type | 2/Scroll type |
| Heating Capacity | 75KW |
| COP | 2.7 |
| Top Fans | 13000m³/h ± 5%(60pa) |
| Heating COP | 3.05 |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Features:
energy saving.
Model No | LR065TXZZ |
Related cooling capacity(kw) | 65 |
EER | 2.7 |
Related heating capacity(kw) | 65 |
COP | 3.05 |
Operation noise dB(A) | 68 |
Rated cooling power input(kw) | 24.4 |
Rated cooling operation current(A) | 44 |
Rated heating power input(kw) | 21.3 |
Rated heating operation current | 38.5 |
Max operation current(A) | 65 |
Power supply | 220V,1N-50/60Hz |
Model Type | LRDW130TXZZ | LRDW065TXZZ | LRDW050TXZZ | ||
Low temperature cooling & heating | |||||
Refrigerant | R410A | ||||
Power supply | 380-410V/3N/50/60Hz | ||||
Compressor | scroll type | rotor type | |||
Compressor qty | 2 | 4 | |||
Fin | V shaped efficient heat exchanger | ||||
Water side heat exchanger | efficient shell-tube heat exchanger | ||||
Restrictor | Electronic expansion valve | ||||
-12℃ heating capacity(KW) | 100 | 50 | 40 | ||
-12℃ Cop | 2.5 | ||||
-12℃ heating power imput（KW) | 40 | 20 | 16 | ||
7℃ heating capacity(kW) | 150 | 75 | 60 | ||
7℃ heating COP | 3.55 | ||||
7℃ heating power input (kW) | 42.2 | 21.1 | 16.9 | ||
35℃ cooling capacity(kw) | 130 | 65 | 50 | ||
35℃ cooling COP | 3.25 | ||||
35℃ cooling power input(kW) | 40 | 20 | 15.4 | ||
Max frequency( A) | 110 | 55 | 42 | ||
water flow volume (m³/h ) | 22 | 11 | 10 | ||
connection pipe | DN65 | ||||
water side heat exchanger bearing pressure(MPa) | 1Mpa | ||||
water side pressure drop（Kpa） | 30 | ||||
Operation sound level dB(A) | 74 | 70 | 68 | ||
Net weight(Kg) | 1300 | 760 | 660 | ||
We are based in Henan, China, start from 2004,sell to Africa(20.00%),Southeast Asia(15.00%),North America(13.00%),South Asia(10.00%),South America(8.00%),Eastern Asia(6.00%),Domestic Market(6.00%),Western Europe(5.00%),Eastern Europe(5.00%),Mid East(5.00%),Southern Europe(2.00%),Central America(2.00%),Northern Europe(2.00%),Oceania(1.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Central Air Conditioning, Fire Ventilation, Fan Coil Unit, Accessories, Heat Pump, Air Conditioner
4. why should you buy from us not from other suppliers?
VRF Chillers technology,installation,core value:honesty, speciality, innovation been central industry since 1980s,export since 2004.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,DDP,Express Delivery；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–9 set: US $4200 / set
- 10+ set: US $4000 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this cooled screw water chiller?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the cooled screw water chiller be supplied for my local voltage?
The standard configuration is 220. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
