Dalian Changyong Technology lists this cross flow fans with its own published specification, unedited. Supplier profile: 7 years on the platform, factory-assessed. Send your target quantity and destination for a firm quotation with current lead times.
Key Features of These Cross Flow Fans
- 电压: 220 V, 380 V, 110 V
- 冷却方式: 横流式
- 功率 (W): 300 W, 400瓦, 100W, 800瓦, 600瓦, 1000 瓦, 900W, 700瓦, 200瓦, 500瓦
- 材质: 金属
- 核心组件: 泵
- 机械测试报告: 可提供
Technical Specifications
| 电压 | 220 V, 380 V, 110 V |
|---|---|
| 冷却方式 | 横流式 |
| 功率 (W) | 300 W, 400瓦, 100W, 800瓦, 600瓦, 1000 瓦, 900W, 700瓦, 200瓦, 500瓦 |
| 材质 | 金属 |
| 核心组件 | 泵 |
| 机械测试报告 | 可提供 |
| 保修 | 1年 |
| 出厂视频检验 | 可提供 |
| 控制方法 | 触摸 |
| 核心卖点 | 环保, 自动, 操作简便 |
| 产地 | China |
| 重量（千克） | 5360 |
| 尺寸 (长*宽*高) | 4570*2870*2580 |
| 产品名称 | 逆流封闭式冷却塔 |
| 应用 | 工业流体冷却 |
| 销售单位 | 单个商品 |
| 单个包装尺寸 | XX 厘米 |
Product Details
The high-temperature superheated gaseous refrigerant discharged from the compressor enters the condenser coil, The spray water is pumped by a circulating water pump to the spray system at the top of the condenser coil, where it is evenly sprayed onto the coil surface to form a water film. The refrigerant gas inside the coil exchanges heat with the spray water and air outside the coil. An axial fan forces air through the condenser coil and spray water, causing the refrigerant inside the coil to gradually condense from a gaseous state into a liquid state, releasing heat.
The spray water outside the coils absorbs heat and evaporates, with part of the spray water turning into water vapor to carry away heat. Water droplets in the rising hot air are intercepted and fall by the deflector plates. Water in the PVC heat exchange layer is cooled by the passing air, its temperature decreases, and it falls into the water pan. It is then pumped back to the spray water system and sprayed onto the coil surface, completing the cooling cycle.
Heat exchanger coils
The heat exchanger coils are formed by automatic bending of high-frequency welded tubes, with elliptical tubes arranged in an alternating pattern to enhance air turbulence and improve heat transfer efficiency. The coils are inclined along the refrigerant flow direction to facilitate oil drainage from the tubes and refrigerant liquid discharge, thereby reducing coil pressure drop. The heat exchanger coils undergo three 2.5 MPa pressure tests to ensure no leaks. The coil assemblies are acid-washed and then undergo overall hot-dip galvanization to enhance corrosion resistance.
Axial fan
Specialized axial flow fan with high-strength nylon impeller (or aluminum alloy impeller) for high flow rate and low noise. Streamlined inlet duct with removable protective grille on the outlet side. Entire unit undergoes hot-dip galvanization for excellent corrosion resistance. Direct-coupled motor drive with outdoor-specific motor for low noise and excellent waterproof performance.
Water pump
Specialized circulating water pump with high flow rate, low head, and high efficiency. The high-flow pump ensures a continuous water flow over the surface of the heat exchanger coils, thereby reducing the likelihood of scale buildup without the need to increase power. The pump body and motor are designed with a rear-pull mechanism, facilitating installation and maintenance. The pump shaft is made of stainless steel to reduce wear on the shaft seal and prevent leakage.
Reduce air recirculation
Significantly increase the height ratio of the equipment to effectively reduce the backflow of hot, humid air into its fresh air inlet. Improve the heat exchange efficiency of the equipment. At the same time, increase the height of the air inlet to allow the spray water to come into contact with the air for a longer period of time during its descent, resulting in more thorough heat exchange. This effectively lowers the water temperature in the tank, and the lower water temperature makes it easier for scale-forming substances to remain in the water rather than precipitating onto the coils.
Corrosion-resistant box body
The enclosure housing is made of hot-dip galvanized 55% aluminum-zinc sheet (AZ150) or hot-dip galvanized aluminum-magnesium sheet (ZM275). The enclosure joints feature a double-flange folded edge structure design, sealed with butyl synthetic sealant strips. This enhances strength and overall sealing performance. All cut edges of the panels are coated with epoxy zinc-rich paint containing 95% zinc to enhance the corrosion resistance of the panels.
*We provide online technical support and online on-site after-sales service, and unless otherwise agreed before quotation, free parts ONLY include metal frame fixed to the bottom of the cooler which is easy for the buyer to unload the cooler from the container.
#Evaporative condensing unit integrated machine #Electric heater #Electronic descaling device #Multi-circuit coil #Sound-absorbing blanket #Stainless steel box body and stainless steel coil #Fan or pump variable frequency control #Inclined water tray design
Dalian Changyong Technology Co., Ltd. is located on the beatiful seaside city – Dalian, China, engaging in designing and manufacturing various heat exchangers, spiral quick freezers, tunnel quick freezers, steamers, etc..
In 2016, Dalian Changyong Technology Co., Ltd. was separately pointed as the exclusive agent in China by Korean company Yong Sung Refrigeration Co., Ltd. and Modine Manufacturing Company.
In 2019, Dalian Changyong Technology Co., Ltd. and Yong Sung Refrigeration Co., Ltd. jointly build up a joint venture, Dalian Yongsung Refrigeration Co., Ltd., to explore and dedicate refrigeration and food processing market in China.
Dalian Yongsung Refrigeration Co., Ltd. combines all Yong Sung latest technologies and the whole product line
incl. quick freezing equipment and boiling equipment, achieved ISO9001 certification, CE certification, and holds 10 invention patents and 3 utility model and appearance patents. The marketing share of the quick freezer in Korea is 70%, the products are exported to over 16 foreign countries.
incl. quick freezing equipment and boiling equipment, achieved ISO9001 certification, CE certification, and holds 10 invention patents and 3 utility model and appearance patents. The marketing share of the quick freezer in Korea is 70%, the products are exported to over 16 foreign countries.
With state of art technologies from Korea and experience of thousands of cases all over the world, Dalian Changyong Technology Co., Ltd. commit to providing OEM services of heat exchangers for special applications in special industries and efficient and energy saving quick freezing equipment with good sanitary conditions to meet the needs of worldwide frozen food field.
