The durable crossflow tower listed here carries 220 V, 380 V, 110 V, material PVC, documented exactly as the manufacturer publishes it. Made by Wuxi Jizhou Technology Co., Ltd. (2 years on the platform, typical reply ≤2h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Durable Crossflow Tower
- Power(W): 300 W(0.40hp), 400 W(0.54hp), 100 W(0.13hp), 800 W(1.07hp), 600 W(0.80hp), 1000 W(1.34hp), 900 W(1.21hp)
- Voltage: 220 V, 380 V, 110 V
- Material: PVC
- Noise Level: 35–39 dB
- Warranty: 1 Year
- Place Of Origin: Jiangsu, China
Technical Specifications
| Voltage | 220 V, 380 V, 110 V |
|---|---|
| Cooling Type | Counter Flow |
| Power(W) | 300 W(0.40hp), 400 W(0.54hp), 100 W(0.13hp), 800 W(1.07hp), 600 W(0.80hp), 1000 W(1.34hp), 900 W(1.21hp) |
| Material | PVC |
| Machinery Test Report | Provided |
| Warranty | 1 Year |
| Video Outgoing-Inspection | Provided |
| Control Method | Touch |
| Noise Level | 35–39 dB |
| Key Selling Points | Easy To Operate, Competitive Price, Long Service Life, Energy Saving, Multifunctional |
| Place Of Origin | Jiangsu, China |
| Weight (Kg) | 10 |
| Brand Name | Arkora |
| Dimension(L*W*H) | Customized as required |
| Product Name | Cooling Tower Fill Pack |
| Application | Industrial Cooling Tower |
| Type | Inclined Corrugated Packing |
| Feature | Durable |
| Plate Pitch | 12mm/15mm/19mm |
| Wave Pitch | 33.3mm |
| Size | Customized as required |
| MOQ | 1000 Pieces |
| Selling Units | Multiple of 100 items |
| Volume Per Batch | 0 cm³ |
| Gross Weight Per Batch | 0.0 kg |
Product Details
Product Name | Specification Model | Fin Pitch | Cycle | Product Size |
Air Inlet Grille | FM-GS-63 | 25mm | 45.5mm | L (customized as needed) *W(63mm)*H (customized as needed) |
Air Inlet Grille | FM-GS-81.3 | 20mm | 55mm | L (customized as needed) *W(81.3mm)*H (customized as needed) |
Filler | FM-TL-500 | 19mm | ~ | L(800/900/1000/1200)*W(500) |
Filler | FM-TL-1020 | 19mm | 206mm | L(206*N)*W (1020mm) |
760 Filler | FM-TL-760 | 16mm | 206mm | L(206*N)*W (760mm) |
1220 Filler | FM-TL-1220 | 16/19mm | 206mm | L(206*N)*W (1220mm) |
915 Filler | FM-TL-915 | 16/19mm | 206mm | L(206*N)*W (915mm) |
1520 Filler | FM-TL-1520 | 16/19mm | 206mm | L(206*N)*W (1520mm) |
1525 Filler | FM-TL-1525 | 19mm | 407mm | L(407*N)*W (1525mm) |
1795 Filler | FM-TL-1795 | 16/19mm | 203.4mm | L(203.4*N)*W (1795mm) |
Crossflow Tower Filler | FM-TL-1340 | 19mm | 407mm | L(206*N)*W (1340mm) |
Evaporative Cooling Filler | FM-TL-1300 | 19mm | 410mm | L(410*N)*W (1300mm) |
Right Angle Filler | FM-TL-620/820/1020/1220 | 19mm | 250mm | L(250*N)*W (620/820/1020/1220mm) |
Point Contact Filler | FM-TL-500 | 25mm | 50mm | L(50*N)*W (500mm) |
Slope Filler | FM-TL-610 | 12mm | 33.3mm | L (customized as needed) *W (610/305mm) *H (customized as needed) |
Slope Filler | FM-TL-610 | 15mm | 33.3mm | L (customized as needed) * (610/305mm) *H (customized as needed) |
Slope Filler | FM-TL-610 | 19mm | 33.3mm | L (customized as needed) *W (610/305mm) *H (customized as needed) |
145 Water Collector | FM-ML-145 | 30mm | 82mm | L (customized as needed) *W (145mm) *H (customized as needed) |
90 Water Collector | FM-YMG-90 | 22.8mm | 150mm | L (customized as needed) *W (90mm) *H (customized as needed) |
140 Water Collector | FM-YMG-140 | 21.78mm | 150mm | L (customized as needed) *W (140mm) *H (customized as needed) |
Property Item | Value |
Density | 1.44g/cm³ |
Heating Longitudinal Reversion | 0.90% |
Tensile Strength – Longitudinal | 46.8MPa |
Tensile Strength – Transverse | 42.1MPa |
Elongation at Break – Longitudinal | 153% |
Elongation at Break – Transverse | 59% |
Tear Strength – Longitudinal | 151kN/m |
Tear Strength – Transverse | 165kN/m |
Low-Temperature Folding Resistance | -25℃ |
Oxygen Index | 35.40% |
Ordering and Pricing
- Minimum order quantity: 100 bag
- Volume pricing:
- 100+ bag: US $0.5 / bag
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this durable crossflow tower?
The standard minimum order quantity is 100 bag. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the durable crossflow tower be supplied for my local voltage?
The standard configuration is 220 V, 380 V, 110 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
