This efficiency air handler unit is published with the manufacturer’s full specification — voltage 208-230V 50-60Hz, capacity 24000-60000. Made by Moyu Technology Co., Ltd. Zhuhai (5 years on the platform, typical reply ≤3h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Efficiency Air Handler Unit
- Power Source: Electrical
- Voltage: 208-230V 50-60Hz
- Capacity (Btu): 24000-60000
- Material: Metal
- Refrigerant: R454B
- Warranty: 5 year
Technical Specifications
| Type | Air Handler |
|---|---|
| Application | Commercial, Hotel, Garage, Household, Outdoor, Restaurant |
| Cooling/Heating | Cooling/Heating |
| Capacity (Btu) | 24000-60000 |
| Refrigerant | R454B |
| Eer | 16-18 |
| Power Source | Electrical |
| Feature | Adjustable Humidistat, Eco-Friendly, Fast Cooling, High Efficiency |
| Warranty | 5 year |
| After-Sales Service Provided | Free Spare Parts, Overseas Call Centers |
| App-Controlled | Yes |
| Material | Metal |
| Operating Language | English |
| Packaging Types | Corrugated Box |
| Private Mold | Yes |
| Place Of Origin | Guangdong, China |
| Brand | Bestcold |
| Certification | ETL/AHRI/UL |
| Voltage | 208-230V 50-60Hz |
| Product Name | CARRIER SEER 18 AIR HANDLER |
| Compressor | Mitsubishi |
| Air Volume | 2800M3/h |
| Installation | Floor Standing Mounted |
| Function | Cooling Heating |
| Noise | 57dB |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
| Model | 24K | 36K | 48K | 60K | ||
| Electrical Data | Voltage-Phase-Hz | V-Ph-Hz | 208/230V-1Ph-60Hz | |||
| Minimum Circuit Ampacity | A | 15 | 20 | 25 | 30 | |
| Max. Overcurrent Protection | A | 20 | 25 | 35 | 40 | |
| Min / Max Volts | V | 187 / 253 | 187 / 253 | 187 / 253 | 187 / 253 | |
| Refer to Room Area | square feet | 365~660 | 536~990 | 709~1320 | 835~1650 | |
| Compressor | Model | TTM240D43UFTB | TTM240D43UFTB | TTQ440D1UMUA | TTQ440D1UMUA | |
| Brand | GMCC | GMCC | GMCC | GMCC | ||
| Type | Rotary | Rotary | Rotary | Rotary | ||
| Hz | 18-100 | 18-100 | 18-100 | 18-100 | ||
| Capacity | W/h | 6700 | 6700 | 13000 | 13000 | |
| Input | W | 1805 | 1805 | 3650 | 3650 | |
| Rated current(RLA) | A | 10 | 12.8 | 15.8 | 20 | |
| Refrigerant oil | ml | 920 | 920 | 1300cc | 1300cc | |
| LRA | 52 | 52 | 58.1 | 58.1 | ||
| Outdoor motor | Model | S.TB-DQ-DRN-310-200-10 | S.TB-DQ-DRN-310-200-10 | S.TB-DQ-DRN-310-200-10 | S.TB-DQ-DRN-310-200-10 | |
| Brand | board-ocean | board-ocean | board-ocean | board-ocean | ||
| Type | DC | DC | DC | DC | ||
| Rated HP | W | 1/4 | 1/4 | 1/4 | 1/4 | |
| Speed | rpm | 1100 | 1100 | 1100 | 1100 | |
| FLA | A | 1.8 | 1.8 | 1.8 | 1.8 | |
| Outdoor Fan | material | Metal | ||||
| Type | Axial flow | |||||
| Diameter | mm | φ595×115×φ12.7 | φ595×115×φ12.7 | φ595×115×φ12.7 | φ595×115×φ12.7 | |
| Outdoor coil | Number of row | 2 | 2 | 2 | 2 | |
| Number of U-tubes | 28 | 38 | ||||
| Tube outside dia | mm (in.) | 7 (9/32) | 7 (9/32) | 7 (9/32) | 7 (9/32) | |
| Fin spacing / Thickness / Type | mm / mm | 1.4 / 0.095 / Hydrophilic aluminium | ||||
| Length (outside/inside row)*Width*Height | mm | (2136/2076)*26.76*588 | (2136/2073)*26.74*798 | |||
| Tube pitch(a) × row pitch(b) | mm | 13.37 × 21 | 13.37 × 21 | 13.37 × 21 | 13.37 × 21 | |
| Outdoor Sound power | dB(A) | 76 | 79 | 76 | 79 | |
| Oudoor unit | Dimension (W×H×D) | mm | 750*635*750 | 750×835×750 | ||
| inch | 29-1/8×25×29-1/8 | 29-1/8×32-7/8×29-1/8 | ||||
| Packing (W×H×D) | mm | 760×660×760 | 760×875×760 | |||
| in. | 30×26×30 | 30/16×34-4/9×3 | ||||
| Net / Gross weight | kg | 62/66 | 62/66 | 85/ 89 | 85/ 89 | |
| lbs | 137/146 | 137/146 | 187 / 196 | 187 / 196 | ||
| Refrigerant system | Liquid side / Gas side | in. | 3/8 / 3/4 | 3/8 / 3/4 | 3/8 / 7/8 | 3/8 / 7/8 |
| Factory charge | oz | R454B/116.4 | R454B/116.4 | R454B/155.2 | R454B/155.2 | |
| Metering device | EEV | EEV | EEV | EEV | ||
| Maximum Line Length | ft | 100 | 100 | 100 | 100 | |
| Maximum Elevation Difference | ft | 50 | 50 | 50 | 50 | |
| Operating temperatures | Cooling | ℉ | 5-125 | 5-125 | 5-125 | 5-125 |
| Heating | ℉ | -4-86 | -4-86 | -4-86 | -4-86 | |
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–19 set: US $1199 / set
- 20–49 set: US $1149 / set
- 50–99 set: US $1114 / set
- 100+ set: US $1091 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this efficiency air handler unit?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 5 year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this efficiency air handler unit carry?
It is supplied with ETL/AHRI/UL documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the efficiency air handler unit be supplied for my local voltage?
The standard configuration is 208-230V 50-60Hz. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Moyu Technology Co., Ltd. Zhuhai, based in China. The company 5 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Moyu Technology Co., Ltd. Zhuhai range on HVACR Nexus.
