This enclosed cooling tower is listed with the manufacturer’s full published specification — voltage 380V-50Hz 3Phase, cooling capacity 196,200kcal/h, material FRP. It is produced by Shenzhen Kaydeli Refrigerator Equipment Co., Ltd., a verified supplier of 8 years. Pricing shown is indicative at standard quantities; send your target volume and destination market for a firm quotation with current lead times.
Key Features of This Enclosed Cooling Tower
- Voltage: 380V-50Hz 3Phase
- Cooling Capacity: 196,200kcal/h
- Material: FRP
- Noise Level: 57.5dB
- Warranty: 1 Year
- Place Of Origin: China
Technical Specifications
| Voltage | 380V-50Hz 3Phase |
|---|---|
| Cooling Type | Counter Flow |
| Material | FRP |
| Core Components | Gear, Pump |
| Machinery Test Report | Not Available |
| Warranty | 1 Year |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Eco-Friendly |
| Place Of Origin | China |
| Weight (Kg) | 210 |
| Brand Name | Kaydeli |
| Dimension(L*W*H) | 1830(Diameter)*1940(height)MM |
| Name | water cooling tower |
| Cooling Tower Type | Counter flow circular cooling tower |
| Circulating Cooling Water Flow | 39.24m3/h |
| Marketing Type | Ordinary Product |
| Water Quality Requirements | PH=6-8 |
| Net Weight | 210kg |
| Operating Weight | 1050kg |
| Cooling Capacity | 196,200kcal/h |
| Noise Level | 57.5dB |
| Inlet/Outlet Temperature | 37℃/32℃ |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
KWT-50 Specification
Tech. Number.: GLT006A–20/01/11 Project:
| Project | Content | Data | Notes |
| Basic Data | Cooling tower type | Counter flow circular cooling tower | Ton |
| Cooling tower Model | KWT–50 | Standard | |
| Circulating cooling water flow | 39.24m3/h |
| |
| In /Out temperature | 37℃/32℃ |
| |
| Ambient Dry/Wet ball Temp. | 31.5℃/28℃ |
| |
| Refrigerating capacity | 196,200kcal/h |
| |
| Noise value | 63.5dB(A) | Away tower 16M | |
| Power supply | 380V/3P/50Hz |
| |
| Water quality | PH value=6-8 |
| |
| Design Data | Air-water ratio | 0.57kg/kg |
|
| Flying water loss | ≤0.02% |
| |
| Evaporating water loss | ≤0.833% |
| |
| Net weight | 210kg |
| |
| Application weight | 1050kg |
| |
| Fan Data | Fan type | Axial flow |
|
| Air volume | 24,000m3/h |
| |
| Fan speed | 960r/min |
| |
| Fan leaf diameter(F) | 930mm |
| |
| Fan leaf number | 4 Pieces/Set |
| |
| Rotor type | Direct rotor |
| |
| Motor speed | 960r/min |
| |
| Motor power | 1.50 kW |
| |
| Motor start method | Direct start |
| |
| Main size | Tower diameter(F) | 1,830mm |
|
| Tower height(H) | 2,020mm |
| |
| In/out tube size(DN) | 80mm/80mm |
| |
| Overflow/drain pipe size(DN) | 25mm/25mm |
| |
| Automatic hydration size(DN) | 15mm |
| |
| Material | Motor | Hermetic waterproof type |
|
| Fan | A.B.S |
| |
| Shell | Glass steel F.R.P | High-quality | |
| Basin | |||
| Sprinkler system | P.V.C |
| |
| Film | P.V.C | Flame retardant | |
| Float valve | A.B.S |
| |
| Inlet system | P.V.C |
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–2 set: US $750 / set
- 3–4 set: US $730 / set
- 5+ set: US $700 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this enclosed cooling tower?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the enclosed cooling tower be supplied for my local voltage?
The standard configuration is 380V-50Hz 3Phase. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shenzhen Kaydeli Refrigerator Equipment Co., Ltd., based in China. The company 8 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Shenzhen Kaydeli Refrigerator Equipment Co., Ltd. range on HVACR Nexus.
