Key specification for this fan: power source Electric, type Fan Coil Unit. Everything below is reproduced from the factory data sheet. Made by Guangdong Folansi Energy Saving Equipment Co., Ltd. (8 years on the platform, typical reply ≤3h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Fan
- Model Number: FLP-40CM
- Power Source: Electric
- Warranty: 2 Years
- Certification: CE,EN14511/4,ENISO4871,CCC
- Place Of Origin: China
- Application: commercial use and Domestic use
Technical Specifications
| Type | Fan Coil Unit |
|---|---|
| Application | commercial use and Domestic use |
| Power Source | Electric |
| Warranty | 2 Years |
| After-Sales Service Provided | Free Spare Parts |
| Place Of Origin | China |
| Brand Name | FOLANSI |
| Model Number | FLP-40CM |
| Function | Heating+COOLING |
| Certification | CE,EN14511/4,ENISO4871,CCC |
| Packaging Details | plywood or carton box |
| Port Of Dispatch | huangpu guangzhou , nansha guangzhou , shenzhen , or other |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
| Supply Ability | 200 units per Day |
Product Details
| Model | FLP-40CM | |
| Note | Two tube type. DC MOTOR.remote control,0-10v light touch screen temperature controller | |
| Power supply | 220V,50Hz,1Ph | |
| Air volume(High speed) | m3/h | 400 |
| Air volume(Medium speed) | m3/h | 300 |
| Air volume(Low speed) | m3/h | 230 |
| Cooling capacity(High speed) | W | 2400 |
| Btu/h | 8200 | |
| Cooling capacity(Mid) | W | 1920 |
| Cooling capacity(Low) | W | 1560 |
| Heating capacity(1)High speed | W | 3850 |
| Btu/h | 13150 | |
| Heating capacity(1)Mid | 3080 | |
| Heating capacity(1)Low | 2000 | |
| Heating capacity(2) | W | 4950 |
| Btu/h | 16900 | |
| Heating capacity(3) | W | 2950 |
| Btu/h | 10050 | |
| Noise | dB(A) | 40 |
| Power input | W | 20 |
| Waterflow volume | m3/h | 0.41 |
| Pressure dropping | kPa | 8 |
| Water tube connection(inlet) | R1/2" | |
| Water tube connection(outlet) | R1/2" | |
| Coil | Type | high efficient copper pipe to wear Hydrophilic aluminum coil |
| Maximum working pressure | Mpa | 1.6 |
| Condensation pipe(diameter) | mm | 21 CENT |
| Net dimension(L*W*H) | mm | 1100*130*681 |
Testing condition:
2-tube system
Cooling
Entering air temperature: Dry bulb 27ºC, Wet bulb 19.5ºC
Entering/out water temperature: 7ºC/ 12℃
Heating(1)
Entering air temperature: 20ºC
Entering water temperature: 60ºC, Same water flow rate as for the cooling
Heating(2)
Entering air temperature: 20ºC
Entering water temperature: 70ºC, Same water flow rate as for the cooling
Heating(3)
Entering air temperature: 20ºC
Entering water temperature: 50ºC, Same water flow rate as for the cooling
Ordering and Pricing
- Minimum order quantity: 1 unit
- Volume pricing:
- 1–4 unit: US $254 / unit
- 5+ unit: US $244 / unit
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this fan?
The standard minimum order quantity is 1 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this fan carry?
It is supplied with CE,EN14511/4,ENISO4871,CCC documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Guangdong Folansi Energy Saving Equipment Co., Ltd., based in China. The company 8 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Guangdong Folansi Energy Saving Equipment Co., Ltd. range on HVACR Nexus.
