The fan coil unit listed here carries airflow 2380m³/h, type Fan Coil Unit, documented exactly as the manufacturer publishes it. Made by Shandong Volks Air Conditioner Group Co., Ltd. (5 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Fan Coil Unit
- Operating Voltage: 230 VAC
- Airflow: 2380m³/h
- Warranty: 2 Years
- Place Of Origin: Shandong, China
- Type: Fan Coil Unit
- Mounting Type: Ceiling Mount
Technical Specifications
| Type | Fan Coil Unit |
|---|---|
| Airflow | 2380m³/h |
| Operating Voltage | 230 VAC |
| Mounting Type | Ceiling Mount |
| Key Selling Points | Competitive Price |
| Warranty | 2 Years |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | Motor, Pump |
| Place Of Origin | Shandong, China |
| Weight (Kg) | 35 KG |
| Brand Name | Singa |
| Dimension(L*W*H) | 2060*470*235mm |
| Showroom Location | Uzbekistan |
| Marketing Type | New Product 2020 |
| Packaging Details | Standard film packaged(wooden box packaged is optional) |
| Port Of Dispatch | Qingdao/Tianjin |
| Selling Units | Single item |
| Single Package Size | 120X50X25 cm |
| Single Gross Weight | 35.0 kg |
| Supply Ability | 5000 units per Month |
Product Details
Product Description
Features of fan coil unit More security, more reliable, and more service life Each fan-coil heat exchanger will be undergone pressure leak detection. The inlet and outlet are of forged brass structure, which is reliable and durable. All materials are well fireproof. The motors are with overheating and power failure protection devices. With free- maintenance Ultra-low noise rolling bearings, the service life can reach up to 35,000 hours. The shaft of the motor is specially treated without rust. The casing is made of high-quality cold-rolled steel plate, sprayed plastic or hot-dip galvanized steel plate, which is mechanically bitten into the shape, which is strong and anti-corrosive.
High performance, high efficiency The coil are equipped with seamless red copper tube string with high-efficiency corrugated aluminum fin structure, which is integrated by mechanical expansion. The combination is tight enough to make sure a higher heat transfer efficiency , a more sufficient heating efficiency , and a dust free surface . Advanced technology with lower noise The fan impeller has no welding points as a whole, and the wheel frame ring is tightly integrated and never deformed. The double-inlet forward-leaning airfoil centrifugal galvanized steel wind wheel has undergone strict dynamic and static balance tests. The air is transmitted in a streamlined manner to reduce vortexes. The generation of swirling air reduces the noise generated during air friction, and the unit runs more smoothly and quietly. Beautiful appearance, easy maintenance The unit is with humanized design for easily maintain and repair. The unit filter can also be cleaned at any time.
Model Name | FP-34 | FP-51 | FP-68 | FP-85 | FP-102 | FP-136 | FP-170 | FP-204 | ||||||||
Power Supply | 1 phase, 220-240V, 50 | |||||||||||||||
Air Flow(M3/H) | H | 340 | 510 | 680 | 850 | 1020 | 1360 | 1700 | 2040 | |||||||
M | 255 | 383 | 510 | 638 | 765 | 1020 | 1275 | 1530 | ||||||||
L | 170 | 255 | 340 | 425 | 510 | 680 | 850 | 1020 | ||||||||
Cooling(W) | H | 1800 | 2700 | 3600 | 4500 | 5400 | 7200 | 9000 | 10800 | |||||||
M | 1440 | 2160 | 2880 | 3600 | 4320 | 5760 | 7200 | 8640 | ||||||||
L | 1170 | 1755 | 2340 | 2925 | 3510 | 4680 | 5850 | 7020 | ||||||||
Heating(W) | H | 2700 | 4050 | 5400 | 6750 | 8100 | 10800 | 13500 | 16200 | |||||||
M | 2160 | 3240 | 4320 | 5400 | 6480 | 8640 | 10800 | 12960 | ||||||||
L | 1755 | 2633 | 3510 | 4388 | 5265 | 7020 | 8775 | 10530 | ||||||||
Power Input(W) | 12Pa | 37 | 52 | 62 | 76 | 96 | 134 | 152 | 189 | |||||||
30Pa | 44 | 59 | 72 | 87 | 108 | 156 | 174 | 212 | ||||||||
50Pa | 49 | 66 | 84 | 100 | 118 | 174 | 212 | 189 | ||||||||
Noise dB(A) | 12Pa | 37 | 39 | 41 | 43 | 45 | 46 | 48 | 50 | |||||||
30Pa | 40 | 42 | 44 | 46 | 47 | 48 | 50 | 52 | ||||||||
50Pa | 42 | 44 | 46 | 47 | 49 | 50 | 52 | 54 | ||||||||
Fan | Type | Forward multi – wing centrifugal double suction fan | ||||||||||||||
Qty | 1 | 2 | 2 | 2 | 2 | 3 | 4 | 4 | ||||||||
Motor | Type | Permanent capacitive three-speed motor | ||||||||||||||
Qty | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 | ||||||||
Heat Exchanger | Copper tube and aluminum fin | |||||||||||||||
Water Flow() | m3/h | 0.39 | 0.55 | 0.7 | 0.82 | 0.91 | 1.34 | 1.59 | 1.8 | |||||||
Pressure Drop | kPa | 12 | 16 | 20 | 23 | 26 | 28 | 32 | 38 | |||||||
Pipe Size | DN20 Internal thread | |||||||||||||||
Drain pipe | 3/4’’ External thread | |||||||||||||||
Net Weight | ||||||||||||||||
without plemun | 14 | 15 | 17 | 19 | 20 | 27 | 32 | 35 | ||||||||
with plemun | 17 | 19 | 20 | 22 | 25 | 31 | 37 | 42 | ||||||||
Details Images
Company Profile
Shandong Volks Air Conditioning Group co.,ltd., established in 2011, as a professional central air conditioning manufacturer in China, we are engaged in the research, development, sale and after sale service of modular chiller and heat pump, water/air cooled screw chiller, water source heat pump, packaged rooftop unit, duct split unit, fan coil unit, air handling unit, etc. All kinds of products have passed the inspection of the National Air Conditioning Testing Center; We also established our owner major labs: national standard central air conditioning laboratory, and heat pump dryer laboratory. Our factory is located in Dezhou city, Shandong province, it is more near Beijing with about 75 minutes by high speed train. We have more than 100,000m3 workshop, and total more than 260 employees till now. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. In addition, we have obtained CRAA, ISO9001, ISO14001 and ISO45001 system, AAA credit rating certificates. Selling well in all cities and provinces around China, and also exported to oversea market with many countries. We also welcome OEM and ODM orders.
Certifications
Packing & Delivery
FAQ
Q1. What is the advantage about your company? A1. Our company has professional team and professional production line. Q2. Why should I choose your products? A2. Our products are high quality and low price. Q3. Any other good service your company can provide? A3. Yes,we can provide good after-sale and fast delivery
Ordering and Pricing
- Minimum order quantity: 10 unit
- Volume pricing:
- 10–99 unit: US $200 / unit
- 100–999 unit: US $190 / unit
- 1000+ unit: US $180 / unit
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this fan coil unit?
The standard minimum order quantity is 10 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the fan coil unit be supplied for my local voltage?
The standard configuration is 230 VAC. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
