Key specification for this gear motor: 12V 24V 48V, 40W. Everything below is reproduced from the factory data sheet. Made by Suzhou Jinteng Precision Drive Co., Ltd. (1 year on the platform, typical reply ≤1h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Gear Motor
- Model Number: 4D40-24GU-18S+4GN5RT
- Rated Power: 15W-200W
- Power: 40W
- Voltage: 12V 24V 48V
- Material: Aluminum Alloy
- Speed Rpm: 3000 RPM
Technical Specifications
| Commutation | Brushless |
|---|---|
| Rated Power | 15W-200W |
| Speed Rpm | 3000 RPM |
| Speed(RPM) | 1800 RPM |
| IP Rating | IP54 |
| Efficiency | IE 2 |
| Type | Brushless Motor |
| Construction | Permanent Magnet |
| Frame | 80 mm(3.15in) |
| Motor Mounting Type | Flange Mount |
| Protect Feature | Waterproof |
| Usage | Home Appliance, Smart Home, Fan |
| Warranty | 1 year |
| Continuous Current(A) | 2.4A |
| Model Number | 4D40-24GU-18S+4GN5RT |
| Torque | 0.51N.m(0.38lb.ft) |
| Place Of Origin | Jiangsu, China |
| Brand Name | JTG MOTOR |
| Product Name | Right Angle DC Gearmotor |
| Power | 40W |
| Voltage | 12V 24V 48V |
| Gear Ratio | 1:3,5,7.5,10,15,20,25,30,40,50,60,75,100,120,150,200 |
| Flange Size | 80*80mm |
| Output Shaft Dia. | 15mm |
| Output Torque | 0.3-10N.m |
| Rated Speed | 1800RPM, 3000RPM |
| Material | Aluminum Alloy |
| Application | AGV, Home Appliance, Medical Devices, Automation Equipment, |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–49 piece: US $58.5 / piece
- 50–99 piece: US $54.3 / piece
- 100–499 piece: US $51 / piece
- 500+ piece: US $47.92 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this gear motor?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 year warranty. Spare parts and technical support remain available after the warranty period.
Can the gear motor be supplied for my local voltage?
The standard configuration is 12V 24V 48V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Suzhou Jinteng Precision Drive Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, Trading Company. Browse the full Suzhou Jinteng Precision Drive Co., Ltd. range on HVACR Nexus.
