The high performance copeland evaporator listed here carries 220v/380v, cooling capacity LOW temperature, documented exactly as the manufacturer publishes it. Made by Taizhou Nanfeng Cold-Chain Co., Ltd. (18 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This High Performance Copeland Evaporator
- Model Number: NF420DC-ML
- Voltage: 220v/380v
- Cooling Capacity: LOW temperature
- Refrigerant: R404a
- Warranty: 1 Year
- Certification: ce
Technical Specifications
| Cooling Capacity | LOW temperature |
|---|---|
| Temperature | / |
| Voltage | 220v/380v |
| Compressor Type | Rotary |
| Refrigerant | R404a |
| Compressor Brand | Copeland |
| Core Components | Motor |
| Warranty | 1 Year |
| Key Selling Points | High-Accuracy, Easy to Operate, Competitive Price, High Productivity, Long Service Life, Energy Saving |
| Video Outgoing-Inspection | Provided |
| Place Of Origin | Jiangsu, China |
| Weight (Kg) | 100 |
| Model Number | NF420DC-ML |
| Dimension(L*W*H) | 120cm x 60cm x 60cm |
| Product Name | Evaporator Unit Freezer Chiller Condenser Refrigerator |
| After-Sales Service Provided | Overseas third-party support available |
| Certification | ce |
| Compressor | DC inverter rotary compressor |
| Fan Motor | DC motor |
| Application | Chilling and freezing |
| Selling Units | Single item |
| Single Package Size | 160X60X60 cm |
| Single Gross Weight | 100.000 kg |
Product Details
NF420DC-ML/R404a | ||||||||||||||||||
Frequency | 15Hz | 50Hz | 90Hz | |||||||||||||||
Displacement | 2.27m³/h | 7.56m³/h | 13.61m³/h | |||||||||||||||
Evap.Temp.Te(℃) | Qo kW | Pe kW | COP | Qo kW | Pe kW | COP | Qo kW | Pe kW | COP | |||||||||
Ambient Temperature Ta=5℃ | ||||||||||||||||||
-35 | 0.70 | 0.55 | 1.27 | 2.43 | 1.22 | 1.99 | 4.37 | 2.26 | 1.93 | |||||||||
-30 | 0.87 | 0.58 | 1.50 | 3.03 | 1.29 | 2.35 | 5.43 | 2.48 | 2.19 | |||||||||
-25 | 1.07 | 0.61 | 1.75 | 3.70 | 1.35 | 2.74 | 6.57 | 2.71 | 2.42 | |||||||||
-20 | 1.31 | 0.63 | 2.08 | 4.50 | 1.41 | 3.19 | 7.86 | 2.95 | 2.66 | |||||||||
-15 | 1.63 | 0.64 | 2.55 | 5.47 | 1.46 | 3.75 | 9.36 | 3.21 | 2.92 | |||||||||
-10 | 2.00 | 0.65 | 3.08 | 6.54 | 1.50 | 4.36 | 10.99 | 3.48 | 3.16 | |||||||||
Ambient Temperature Ta=15℃ | ||||||||||||||||||
-35 | 0.66 | 0.59 | 1.12 | 2.17 | 1.30 | 1.67 | 3.95 | 2.43 | 1.63 | |||||||||
-30 | 0.77 | 0.61 | 1.26 | 2.80 | 1.40 | 2.00 | 4.96 | 2.69 | 1.84 | |||||||||
-25 | 0.91 | 0.64 | 1.42 | 3.45 | 1.50 | 2.30 | 6.02 | 2.95 | 2.04 | |||||||||
-20 | 1.11 | 0.66 | 1.68 | 4.18 | 1.59 | 2.63 | 7.20 | 3.22 | 2.24 | |||||||||
-15 | 1.41 | 0.68 | 2.07 | 5.02 | 1.66 | 3.02 | 8.53 | 3.51 | 2.43 | |||||||||
-10 | 1.79 | 0.70 | 2.56 | 5.95 | 1.73 | 3.44 | 9.95 | 3.80 | 2.62 | |||||||||
Ambient Temperature Ta=25℃ | ||||||||||||||||||
-35 | 0.60 | 0.62 | 0.97 | 1.93 | 1.45 | 1.33 | 3.58 | 2.70 | 1.33 | |||||||||
-30 | 0.67 | 0.65 | 1.03 | 2.52 | 1.56 | 1.62 | 4.52 | 2.99 | 1.51 | |||||||||
-25 | 0.77 | 0.68 | 1.13 | 3.14 | 1.67 | 1.88 | 5.50 | 3.28 | 1.68 | |||||||||
-20 | 0.94 | 0.71 | 1.32 | 3.83 | 1.78 | 2.15 | 6.56 | 3.58 | 1.83 | |||||||||
-15 | 1.22 | 0.74 | 1.65 | 4.60 | 1.88 | 2.45 | 7.72 | 3.89 | 1.98 | |||||||||
-10 | 1.57 | 0.76 | 2.07 | 5.42 | 1.98 | 2.74 | 8.95 | 4.20 | 2.13 | |||||||||
Ambient Temperature Ta=32℃ | ||||||||||||||||||
-35 | 0.54 | 0.64 | 0.84 | 1.79 | 1.64 | 1.09 | 3.36 | 3.00 | 1.12 | |||||||||
-30 | 0.61 | 0.68 | 0.90 | 2.32 | 1.73 | 1.34 | 4.25 | 3.30 | 1.29 | |||||||||
-25 | 0.70 | 0.71 | 0.99 | 2.89 | 1.83 | 1.58 | 5.16 | 3.61 | 1.43 | |||||||||
-20 | 0.86 | 0.75 | 1.15 | 3.54 | 1.94 | 1.82 | 6.14 | 3.92 | 1.57 | |||||||||
-15 | 1.11 | 0.79 | 1.41 | 4.29 | 2.06 | 2.08 | 7.20 | 4.24 | 1.70 | |||||||||
-10 | 1.42 | 0.82 | 1.73 | 5.09 | 2.19 | 2.32 | 8.30 | 4.56 | 1.82 | |||||||||
Ambient Temperature Ta=43℃ | ||||||||||||||||||
-35 | 0.41 | 0.67 | 0.61 | 1.59 | 2.04 | 0.78 | 3.05 | 3.61 | 0.84 | |||||||||
-30 | 0.51 | 0.72 | 0.71 | 1.99 | 2.06 | 0.97 | 3.84 | 3.93 | 0.98 | |||||||||
-25 | 0.62 | 0.78 | 0.79 | 2.45 | 2.11 | 1.16 | 4.64 | 4.25 | 1.09 | |||||||||
-20 | 0.77 | 0.83 | 0.93 | 3.04 | 2.20 | 1.38 | 5.49 | 4.57 | 1.20 | |||||||||
-15 | 0.96 | 0.88 | 1.09 | 3.79 | 2.35 | 1.61 | 6.39 | 4.89 | 1.31 | |||||||||
-10 | 1.18 | 0.93 | 1.27 | 4.63 | 2.54 | 1.82 | 7.33 | 5.22 | 1.40 | |||||||||
* Duty at +20℃ suction temperature. | ||||||||||||||||||
item | value |
Applicable Industries | Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Restaurant, Home Use, Retail, Food Shop, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company, Plastic Industry, Other industries, Beverage Factory, Supermarkets, Construction works?, Metalworking Factory, Marine |
Condition | New |
Place of Origin | China |
Jiangsu | |
Model Number | NF420DC-ML |
Voltage | 220v/380v |
Power | 90hz |
Dimension(L*W*H) | 120cm x 60cm x 60cm |
Weight | 100kg |
Year | 2023 |
Warranty | 1 Year |
Key Selling Points | High-accuracy, Easy to Operate, Competitive Price, High Productivity, Long Service Life, Energy saving |
Compressor brand | Copeland |
Cooling Capacity | LOW temperature |
Video outgoing-inspection | Provided |
Warranty of core components | 1 Year |
Core Components | Motor |
Refrigerant | R404a |
Product name | High Performance Evaporator Unit Freezer Chiller Condenser Refrigerator |
After-sales Service Provided | Overseas third-party support available |
Certification | ce |
Compressor type | DC inverter compressor condensing unit for supermarket display cabinet |
Compressor | DC inverter rotary compressor |
Fan motor | DC motor |
Application | Chilling and freezing |
We are based in Jiangsu, China, start from 1999,sell to Western Europe(45.00%),Oceania(20.00%),Domestic Market(20.00%),Eastern Asia(10.00%),Northern Europe(5.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Air Cooler, Fan Motor Condensing Unit, Full DC Inverter Condensing Unit, Solar-powered Container-fridge, Open Type Condensing Unit
4. why should you buy from us not from other suppliers?
We use good brand components and we do a good quality. We never supply bad quality products. We have many years experience in this area. Our products all export to Europe ,Austrilia .ect. Our quality accord with the lastest EU standards
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T;
Language Spoken:English,Chinese
Ordering and Pricing
- Minimum order quantity: 10 set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this high performance copeland evaporator?
The standard minimum order quantity is 10 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this high performance copeland evaporator carry?
It is supplied with ce documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the high performance copeland evaporator be supplied for my local voltage?
The standard configuration is 220v/380v. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Taizhou Nanfeng Cold-Chain Co., Ltd., based in China. The company 18 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Taizhou Nanfeng Cold-Chain Co., Ltd. range on HVACR Nexus.
