Key specification for this high quality oil motor: rated voltage 110VAC-600VAC(50/60Hz), model number CBB65. Everything below is reproduced from the factory data sheet. Made by Smiler Electronic Industry Co., Ltd. (6 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This High Quality Oil Motor
- Model Number: CBB65
- Rated Voltage(VR): 110VAC-600VAC(50/60Hz)
- AC Test Voltage Between Terminals: 2Un/5s
- Voltage Test Terminal To Case: 2000VAC, 2Un+1000VAC
- Product Certification: CQC, UL, CUL, VDE
- Place Of Origin: Guangdong, China
Technical Specifications
| Brand Name | SMILER |
|---|---|
| Model Number | CBB65 |
| Packaging Type | Customized |
| Capacitance | Contact us |
| Place Of Origin | Guangdong, China |
| Description | Compressor start capacitor CBB65 |
| Specification | CBB65 |
| Application | Air Conditioner,Fan Motor Start and compressor |
| Package / Case | Aluminium or plastic shell |
| Series | CBB65 |
| Features | Metallized polypropylene film |
| Size / Dimension | Customized |
| Rated Voltage(VR) | 110VAC-600VAC(50/60Hz) |
| Capacitance Tolerance | ±5%(J),±10%(k) |
| Dissipation Factor Change | ≤0.0025(Hz) |
| AC Test Voltage Between Terminals | 2Un/5s |
| Voltage Test Terminal To Case | 2000VAC, 2Un+1000VAC |
| Climatic Category | 40/70/21, 40/85/21 |
| Operation Life Time | B(10000h), C(3000h) |
| Safe Class | S2 |
| Product Certification | CQC, UL, CUL, VDE |
| Selling Units | Single item |
| Single Package Size | 50X40X50 cm |
| Single Gross Weight | 0.300 kg |
Product Details
The general color is black, white and blue etc.
At the same time we accept the customization.
4. Which certificate do you have?
From the company, we own near 15 honour certificates from the government and our customers. The main certificate is the high -tech
enterprises which pass the audit of the government.
At the same time, we own near 20 patent certificates of the production and products.
From the products,We own near 20 certificates which such as CQC, TUV, UL VDE and so on.
5. What are the main parameters of the capacitor?
There main parameter with Capacity and voltage.
6. The unit of capacitor capacity is F (Farad).
The conversion formula of F (Farad) is:
1F(Farad)=1000000μF(Micro method)
1μF (micro method)=1000000pF (picofarad)
The amount of F is very large, generally μF and pF are used as the unit of capacitance.
7. What does CBB mean?
CBB is China's abbreviation for metallized polypropylene film capacitors.
8. The words PO and P2 in capacitor for what meaning?
P0 in the capacitor means non-explosion-proof, and P2 means explosion-proof. The explosion-proof principle of safety
filmcapacitors. The metalized electrode adopts a micro-fuse network structure (as shown in Figure 1). When the capacitor fails,
themicro-fuse is disconnected and the power supply is automatically cut off, thereby preventing the expansion of the fault
andachieving the purpose of self-safety protection.
Ordering and Pricing
- Minimum order quantity: 100 piece
- Volume pricing:
- 100–499 piece: US $0.9 / piece
- 500–999 piece: US $0.65 / piece
- 1000+ piece: US $0.35 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this high quality oil motor?
The standard minimum order quantity is 100 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
Which certifications does this high quality oil motor carry?
It is supplied with CQC, UL, CUL, VDE documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the high quality oil motor be supplied for my local voltage?
The standard configuration is 110VAC-600VAC(50/60Hz). Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Smiler Electronic Industry Co., Ltd., based in China. The company 6 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Smiler Electronic Industry Co., Ltd. range on HVACR Nexus.
