Ice Machine, 3T, 380v 50hz 3phrase, Stainless Steel 304

Ice machine — 380v 50hz 3phrase, material Stainless Steel 304. The complete factory specification follows. Made by Luohe Orange Mechanical Equipment Co., Ltd. (14 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.

Key Features of This Ice Machine

• Power: other
• Voltage: 380v 50hz 3phrase
• Ice Storage Capacity: 50kg, 80KG, 100kg, 200 kg, 300 kg
• Material: Stainless Steel 304
• Warranty: 1 Year
• Place Of Origin: China

Technical Specifications

Product Details

High Productivity Energy saving stainless steel 1t 2t 3t 5t 8T 10T 15T 20T 30 Ton flake ice machine For Fish Seafood Market

Ice Flake Machine Introduction:

The ice flake machine is a leader in fast and large-scale refrigeration projects, and is widely used in supermarket food
preservation, fishery protection, food processing, concrete cooling, etc.

Flake Ice Machine 1 2 3T 5 10 Ton 15 20 30 40 Tons Commercial Industrial Flake Ice Making Machine Factory Supply Ice Maker For Food & Meat processing & Fishing & Seafood Ice Maker

Title goes here.

1) Fishing -Sea water flake ice machine can make ice directly from the sea water, ice can be used in fast cooling of fish and other sea products.

2) Sea food process -keeps the sea food fresh.

3) Bakery -prevent the flour from self raising by adding flake ice.

4) Food processing – cool the meat and water air, also supply moisture for the products at the meantime.

5) Vegetables distribution and fresh-keeping.

6) Flake ice is the most ideal temperature-reducing carrier.

7) Concrete Cooling -Flake ice is widely used in the large projects.

Model Number	BMF-03T, BMF-05T, BMF-1T, BMF-2T, BMF-3T, BMF-4T, BMF-5T, BMF-6T, BMF-8T, BMF-10T, BMF-12T, BMF-15T, BMF-20T, BMF-30T, BMF-40T
Capacity	300kg/day, 500kg/day, 1 ton/day, 2 tons/day, 3 tons/day, 4 tons/day 5 tons/day, 6 tons/day, 8 tons/day, 10 tons/day, 12 tons/day, 15 tons/day, 40 tons/day, 50 tons/day, 100 tons/day
Applicable Industries	Food & Beverage Factory, Restaurant, Food Shop, Energy & Mining, Food & Beverage Shops
After Warranty Service	Video technical support, Online support
Ice Shape	Snow Flake Ice
ower supply	3P/1P + 380V/220V/110V + 50hz/60hz
Power	18.49~53.42kw
Dimension(L*W*H)	1850*1700*1555~3900*2150*1920mm
Weight	672KG ~ 2250KG
Core Components	Pressure vessel, Motor, Bearing, Gear, Engine, PLC
After-sales Service Provided	Engineers available to service machinery overseas
Refrigerant	R404A
compressor	Bitzer from Germany, Refcomp from Italy, Danfoss from Danmark
cooling type	water cooling
ice thickness	1.8~2.5mm
Warranty	12 months

Special design of flake ice machine:

1. Refrigerating unit — Compressor are imported from America, Germany, Japan.

2. PLC programmable control system — The whole system is controlled automatically well without hand operation.

3. Evaporator– made of SUS304/316 material and adopts automatic fluorine welding technology.

4. Ice blade–Spiral ice blade, small resistance, low loss, no noise and making ice in uniform.

◆ Product Parameter ◆

Model	Output	Refrigerate Capacity	Total Power	Rated Current	Compressor Power	Refrigerant	Cooling Way	Unit Size L*W*H (mm)
BMF03	0.3T	2.1KW	1.9KW	4.3A	1.5KW	R22/R404A	Water	950*800* *680
BMF05	0.5T	3.5KW	2.45KW	5.6A	2.1KW	R22/R404A	Water	950*800* 810
BMF08	0.8T	5KW	3.5KW	7A	2.9KW	R22/R404A	Water	1320*970*850
BMF10	1T	6.35KW	4.33KW	8.66A	3.6KW	R22/R404A	Air/ Water	1320*970*900
BMF20	2T	12.9KW	8.66KW	17.3A	5.88KW	R22/R404A	Air/ Water	1500*1100*1050
BMF30	3T	21.5KW	13KW	26A	9.7KW	R22/R404A	Air/ Water	1745*1360*1250

Details Images

Main Features:

1. The ice flake machine adopts modular design, which is easy to assemble and maintain; the parts are processed by CNC machine tools with high precision and avoid welding defects.

2. The ice flake machine Using high-precision bearings imported from Japan, the mechanism runs smoothly and has long service life.
3. The ice flake machine, One key to start the ice storage mode. After the ice cubes fall into the ice storage, the ice rake automatically runs according to the signal instructions provided by the sensor, and automatically stops when the ice storage reaches the maximum.
4. The ice flake machine, One-button start of the ice release mode, the ice blocking door opens automatically, the ice rake runs automatically according to the signal instruction provided by the sensor, and automatically stops after the ice output is completed, and the ice blocking door returns to its position.
5. Smart electric control screen, simple and easy to use.
6.Monitoring equipment is installed in the cold storage, which can check the working conditions of the equipment in real
time,which is convenient for maintenance and management and safe production.

Related Products

※ Company Profile

Luohe Orange Mechanical Equipment Co.,Ltd (Orange) is a professional mechanical equipment manufacturer which is located in Henan Province, China. The company is specialized in production, processing and sales of food machinery, agriculture machinery and other machineries. The main production scopes that we cover are: snack food processing machines, candy processing machines, fruit and vegetables processing machines, packaging machines, water well drilling machines, and various peeling machines.

The company covers 35,000 m2and the fixed asset of the company is RMB 10 million Yuan. There are over 100 employees, more than 30 technicians, and over 100 sets of various manufacturing equipment. The equipment are included: large scale forcing press machine, digital lathe, digital wire-electrode cutting equipment, various kinds of processing machines and equipment, etc. The company owns national patents and proprietary technology with Have independent research and development capabilities.

※ Certificate

※ Take a photo with customers

Egypt after-sales

Guinea After Sales

India after sale

 1.  24-hour communication service

 2.  Fast logistics provides you with smooth delivery service; if you are not familiar with customs clearance, we can provide you with door-to-door delivery (DDU&DDP).

 3.  One-year warranty, lifetime technical support and free staff training

 4.  New design or product recommendation

 5.  Participate in international expositions and negotiate face-to-face with customers

 6.  If you come to China, please provide a formal invitation

 7.  Front desk service, help you book the hotel

 8.  Support local after-sales service

※ F A Q

Q1：What's your company after-sales service?

A1: Our machine will be checked three times before shipment to ensure that the machine itself has no problems. If the machine has some problems under incorrect operation: 1. improper operation problem, we will solve all the usage problems by video call. 2. machine parts problem, we will send you accessories to ensure the normal use of the machine. 3.In addition, our engineers go abroad every year to help customers solve problems they cannot solve. Give customers the best quality machine, the best service, Is the standard of our company . Q2：Any warranty ？

A2：One year warranty. Frankly speaking, The quality of our machines is very stable. The machine will be tested three times before leaving the factory to ensure that the machine is in the best condition when it arrives at your address. Some minor problems of the machine are usually caused by incorrect operation by novices, so we provide a full set of English instruction videos and common problem solving videos, To help users better understand it. On the other hand, we put a set of spare parts in the toolbox of the machine in advance. During your use, if you need any spare parts, we can send it to you via UPS, and it only takes 5-7 days to arrive at your door. During use, if you have any questions, we can make a video call at any time.

Q3: How to transport without customs clearance experience ？ A3：We have reliable forwarder agent which can ship items to you by sea/air/Express to your home. We will help you choose the most suitable shipping service. Q4：Does your company provide training？ A4 : Yes, we provide a series of instructional videos and after-sales service videos, supporting Chinese, English, French, Spanish, and Arabic. Q5：Differences from other brands in China ？ A5 : We are not only selling machines, we pay more attention to after-sales service. We have always believed that the customer's reputation is the best advertisement. We hope to really help our customers use machines and bring growth to their business. You can view our customers' feedback, facts speak louder than words.

Ordering and Pricing

• Minimum order quantity: 1 set
• Volume pricing:
  • 1+ set: US $3500 / set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this ice machine?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Can the ice machine be supplied for my local voltage?

The standard configuration is 380v 50hz 3phrase. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
