This infrared panel is listed with the manufacturer’s full published specification — voltage 220-240V/50Hz-60Hz, power 360W, material Metal. It is produced by Cixi Jemell Electrical Appliance Co., Ltd., a verified supplier of 10 years. Pricing shown is indicative at standard quantities; send your target volume and destination market for a firm quotation with current lead times.
Key Features of This Infrared Panel
- Power: 360W
- Power Source: Electric
- Voltage: 220-240V/50Hz-60Hz
- Material: Metal
- Warranty: 1 Year
- Place Of Origin: Zhejiang, China
Technical Specifications
| Heater Type | Infrared Heater |
|---|---|
| Power | 360W |
| Area Heated | 8㎡(86.11ft2) |
| Function | Adjustable Thermostat, Overheat Protection, Remote Controlled, Waterproof |
| Application | Hotel, Office, Commercial, Household |
| Energy Efficiency Rating | Class A |
| Installation | Freestanding, Wall-mounted |
| Control | Smart Control |
| Heating Element | Carbon Fiber |
| Warranty | 1 Year |
| Material | Metal |
| App-Controlled | Yes |
| Display | With Temperature Display |
| After-Sales Service Provided | Free Spare Parts |
| Feature | Energy Saving |
| Power Source | Electric |
| Packaging Types | Corrugated Box, Color Box |
| Operating Language | English, German, French, Dutch, Spanish |
| Place Of Origin | Zhejiang, China |
| Brand Name | ODM&OEM |
| Voltage | 220-240V/50Hz-60Hz |
| Heating Elements | Carbon Crystal |
| Feature1 | Two built-in Over-heating protection |
| Feature2 | With touch control buttons at side of the heater. |
| Feature3 | Timer and temperature setting. |
| Control Mode | Remote Control+WIFI |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Carbon Crystal far infrared panel heater | ||||||||
Model No. | Power | Product Meas (cm) | N.W(kg) | |||||
JCH-30MW | 300W | 60*50*4 | 3.8 | |||||
JCH-36MW | 360W | 60*60*4 | 4.5 | |||||
JCH-40MW | 400W | 80*50*4 | 4.9 | |||||
JCH-45MW | 450W | 50*90*4 | 5.4 | |||||
JCH-48MW | 480W | 80*60*4 | 5.8 | |||||
JCH-60MW | 600W | 60*100*4 | 7 | |||||
JCH-72MW | 720W | 60*120*4 | 8.4 | |||||
Material | Metal | ||||||
Color | White | ||||||
Heating Elements | Carbon crystal | ||||||
Feature | * 220-240V~, 50-60Hz, Class I; * Carbon crystal infrared panel heater; * Two built-in Over-heating protection * Metal outer shell * Carbon crystal heating element * With touch control buttons at side of the heater. * Timer and temperature setting. * With remote control * WiFi control * Wall mounting and free standing | ||||||
Design | OEM and ODM service | ||||||
Application | Hotel,Commercial,Household | ||||||
Packing | Color Box+Carton | ||||||
MOQ | 500pcs. | ||||||
Delivery time | 30-45 days after order and artwork confirmed | ||||||
Ordering and Pricing
- Minimum order quantity: 1000 piece
- Volume pricing:
- 1000–1599 piece: US $42 / piece
- 1600+ piece: US $38 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this infrared panel?
The standard minimum order quantity is 1000 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the infrared panel be supplied for my local voltage?
The standard configuration is 220-240V/50Hz-60Hz. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Cixi Jemell Electrical Appliance Co., Ltd., based in China. The company 10 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Cixi Jemell Electrical Appliance Co., Ltd. range on HVACR Nexus.
