Inverter Evi Heat Pump, R290, 220V, 3-16KW

Inverter evi heat pump — 220V/1PH/50HZ, heating capacity 3-16KW. The complete factory specification follows. Made by Aircal Heat Pump Ltd. (10 years on the platform, typical reply ≤5h). Send your target quantity and destination for a firm quotation with current lead times.

Key Features of This Inverter Evi Heat Pump

• Model Number: Master heat
• Power Source: Electric, Gas
• Power Supply: 220V/1PH/50HZ
• Heating Capacity: 3-16KW
• Housing Material: Stainless Steel
• Refrigerant: R290

Technical Specifications

Product Details

Details Images

R290 high cop dc inverter monoblock heat pump water cooling&heating heater

DC Inverter Heat Pumps utilize advanced heat pump technology to achieve high efficiency With the application of DC inverter technology, these series of units can adjust the output capacity automatically and control the room temperature accurately. The intelligent control system means everyone in the family can control the unit.

Due to the monobloc design, the units are cost effective, space saving and quiet to run outside. All of these features work together to give you a more comfortable home.

Specification for Multifunctional DC Inverter heat pump (R290)
Model：			AMH 6DC	AMH 9DC	AMH 12DC	AMH 16DC	AMH 16DCT
Lowest operational point		℃	-25℃	-25℃	-25℃	-25℃	-25℃
Highest operational point		℃	45℃	45℃	45℃	45℃	45℃
Heating  Capacity Range		KW	2-7	3-10	4-13	5-17	5-17
Heating (A7/6℃,W30/35℃)	Heating Capacity	KW	6.4	9.15	12.2	16	16
	Power Input	KW	1.33	2.03	2.72	3.41	3.41
	Current	A	5.78	8.83	11.83	14.83	5.18
	COP	W/W	4.81	4.50	4.48	4.69	4.69
Heating                     (A-25℃,W40/45℃)	Heating Capacity	KW	3.30	4.72	6.28	8.16	8.16
	Power Input	KW	1.7	2.65	3.56	4.34	4.34
	COP	W/W	1.94	1.78	1.76	1.88	1.88
Heating (A7/6℃,W47/55℃)	Heating Capacity	KW	5.5	8.12	10.65	13.6	13.6
	Power Input	KW	1.75	2.26	3.51	4.41	4.41
	COP	W/W	3.23	3.05	3.03	3.08	3.08
Cooling (A35/24℃,W23/18℃)	Cooling Capacity	KW	6.25	9	11	15.8	15.8
	Power Input	KW	1.46	2.25	2.98	3.86	3.86
	Current	A	6.35	9.35	12.96	21.39	5.86
	EER	W/W	4.28	4.19	3.69	4.09	4.09
Cooling (A35/24℃,W12/7℃)	Cooling Capacity	KW	5.2	6.8	9.4	13.2	13.2
	Power Input	KW	1.74	2.28	3.16	4.22	4.22
	Current	A	7.57	9.91	13.74	18.35	6.41
	EER	W/W	2.99	2.98	2.97	3.13	3.13
Rated water flow		m3/h	7.57	9.91	13.74	18.35	6.41
Rated voltage /Frequency		V/Hz	2.99	2.98	2.97	3.13	3.13
Maximum input power		kW	1.05	1.51	2.06	2.73	2.73
Maximum input current		A	230/50	230/50	230/50	230/50	280/50
High pressure value cut-off pressure		MPa	2.76	3.45	3.95	6.21	6.21
Low pressure valve cut-off pressure		MPa	12	15	17	27	9.4
Power supply			220-240V~ /50Hz

Products Description

Smart Heat Pumps

SG ready and PV ready, the cost of use is reduced, and it meets the requirements of local policies.Power consumption of the system
can be automatically adjusted according to the peak and valley power to reduce the power consumption to the greatest extent. PV
ready, connect to solar power at home to realize solar power supply and reduce usage costs.

WI-FI Control Heat Pumps

With a Wi-Fi and 4G/5G connection, you can take full control of your heat pump on your smartphone via an app.

The app can be found in the App stores.

A+++ Energy Level

Aircal R290 Heat Series has gained A+++ EU energy label. Highly efficiency

Low Noise

Full inverter compressor and DC brushless fans enable the units to run quietly.

Meanwhile, new noise reduction measures are adopted to control the sound of the units at a satisfactory level.

Certifications

Certifications

Provide CE certificate and ERP report issued by professional institutions.

Customize customer-specific certificates and reports.

Company Profile

pack

FAQ



Why choose air to source heat pump? 1.It can get 4-5 times more heat than the traditional water heater. Therefore,the heating efficiency is higher. 2.Heating with air heat source is safer than electric heating. 3.Even when it is snowing in winter, you can enjoy the 24-hour hot water service provided by the air energy water heater at any time. 4.The heat pump product has no fuel emissions,can be controled by Wifi.

Ordering and Pricing

• Minimum order quantity: 3 piece
• Volume pricing:
  • 3–39 piece: US $1796 / piece
  • 40–79 piece: US $1626 / piece
  • 80+ piece: US $1543 / piece
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this inverter evi heat pump?

The standard minimum order quantity is 3 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Can the inverter evi heat pump be supplied for my local voltage?

The standard configuration is 220V/1PH/50HZ. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Aircal Heat Pump Ltd., based in China. The company 10 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Aircal Heat Pump Ltd. range on HVACR Nexus.
