This mixed flow fan is published with the manufacturer’s full specification — 380V, 5.5Kw. Made by Zhejiang Hongke Electromechanical Co., Ltd. (6 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Mixed Flow Fan
- Power: 5.5Kw
- Voltage: 380V
- Rated Voltage: 380V
- Blade Material: metal
- Material: Metal Frame
- Speed: 2900rmp
Technical Specifications
| Voltage | 380V |
|---|---|
| Blade Material | metal |
| Customized Support | OEM, ODM |
| Mounting Type | Free Standing |
| Warranty | 1 Year |
| After-Sales Service Provided | Video Technical Support |
| Place Of Origin | Zhejiang, China |
| Power | 5.5Kw |
| Brand Name | Hongke |
| Product Name | mixed flow fan |
| Application | Industrial Equipment |
| Usage | Industry Greenhouse |
| Keyword | Exhaust Fan Ventilation |
| Motor | 100% Copper Motor |
| Function | Ventilaion |
| Material | Metal Frame |
| Rated Voltage | 380V |
| Speed | 2900rmp |
| Applicable Industries | hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other |
| Type | Other |
| Packaging Details | carton |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Product Overview
The pressure is higher than the axial flow fan of the same unit number, and the air volume is larger than the centrifugal fan of the same unit number. It has the advantages of high efficiency, compact structure, low noise, small size, convenient installation, etc., and is widely used in the ventilation and ventilation of hotels, restaurants, shopping malls, office buildings, gymnasiums and other advanced civil buildings, pipeline pressurized air supply and ventilation places of industrial and mining enterprises. The dual-speed fan can adjust the required air volume and air pressure through variable speed according to the requirements of operating conditions.
Machinery number | Rotating speed （r/min） | Power （kw） | Motor model | Air volume （m3/h） | Total pressure （Pa） | Noise （dBA） | Weight （kg） |
2.5 | 4 | Y112M-2 | 7228 | 654 | 78 | ||
6801 | 715 | ||||||
6221 | 883 | ||||||
5688 | 1107 | ||||||
5242 | 1248 | ||||||
0.37 | Y712-4 | 4512 | 128 | 71 | 52 | ||
4302 | 143 | ||||||
3636 | 175 | ||||||
3053 | 212 | ||||||
2765 | 285 | ||||||
960 | 0.25 | Y712-6 | 2642 | 86 | 64 | 52 | |
2486 | 107 | ||||||
2237 | 129 | ||||||
1985 | 145 | ||||||
1743 | 156 | ||||||
2900 | 2.2 | Y90L-2 | 4562 | 512 | 73 | 67 | |
4410 | 562 | ||||||
4018 | 691 | ||||||
3605 | 816 | ||||||
3212 | 883 | ||||||
1450 | 0.25 | Y711-4 | 2312 | 121 | 66 | 45 | |
2009 | 184 | ||||||
1803 | 216 | ||||||
1606 | 236 | ||||||
0.12 | Y632-6 | 1436 | 93 | 60 | 40 | ||
1320 | 112 | ||||||
1164 | 127 | ||||||
1000 | 139 | ||||||
3 | Y100L-2 | 5745 | 564 | 74 | 85 | ||
5317 | 623 | ||||||
4927 | 741 | ||||||
4542 | 876 | ||||||
4127 | 966 | ||||||
1450 | 0.25 | Y711-4 | 3320 | 125 | 68 | 48 | |
3082 | 141 | ||||||
2876 | 174 | ||||||
2447 | 216 | ||||||
2130 | 257 | ||||||
960 | 0.18 | Y711-4 | 1938 | 67 | 82 | 48 | |
1743 | 89 | ||||||
1592 | 103 | ||||||
1380 | 127 | ||||||
1234 | 146 |
Machinery number | Rotating speed （r/min） | Power （kw） | Motor model | Air volume （m3/h） | Total pressure （Pa） | Noise （dBA） | Weight （kg） |
4 | 2900 | 4 | Y112M-2 | 7228 | 654 | 78 | 100 |
6801 | 715 | ||||||
6221 | 883 | ||||||
5688 | 1107 | ||||||
5242 | 1248 | ||||||
1450 | 0.37 | Y712-4 | 4512 | 128 | 71 | 52 | |
4302 | 143 | ||||||
3636 | 175 | ||||||
3053 | 212 | ||||||
2765 | 285 | ||||||
960 | 0.25 | Y712-6 | 2642 | 86 | 64 | 52 | |
2486 | 107 | ||||||
2237 | 129 | ||||||
1985 | 145 | ||||||
1743 | 156 | ||||||
4.5 | 2900 | 5.5 | Y132S1-2 | 9169 | 672 | 80 | 125 |
8731 | 753 | ||||||
8159 | 928 | ||||||
7561 | 1187 | ||||||
7124 | 1298 | ||||||
1450 | 0.55 | Y801-4 | 4728 | 182 | 73 | 70 | |
4552 | 207 | ||||||
4040 | 216 | ||||||
3392 | 265 | ||||||
3160 | 306 | ||||||
960 | 0.25 | Y712-6 | 3592 | 88 | 66 | 65 | |
3264 | 107 | ||||||
2892 | 132 | ||||||
2576 | 148 | ||||||
2240 | 162 | ||||||
5 | 2900 | 5.5 | Y132S1-2 | 13110 | 801 | 83 | 135 |
12410 | 859 | ||||||
11865 | 1048 | ||||||
11342 | 1212 | ||||||
9876 | 1316 | ||||||
1450 | 1.1 | Y90S-4 | 8652 | 196 | 77 | 80 | |
7433 | 220 | ||||||
6664 | 278 | ||||||
5252 | 326 | ||||||
4896 | 382 | ||||||
960 | 0.37 | Y801-6 | 5624 | 96 | 68 | 75 | |
4984 | 124 | ||||||
4322 | 136 | ||||||
3778 | 158 | ||||||
3215 | 182 |
We are based in Zhejiang, China, start from 2010,sell to Domestic Market(70.00%),North America(10.00%),Southeast
Asia(10.00%),Eastern Europe(2.00%),Western Europe(2.00%),Southern Europe(2.00%),South America(00.00%),Africa(00.00%),Mid
East(00.00%),Eastern Asia(00.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Blower fan,Centrifugal fan,Axial fan,Industrial fan,Pipe fan
4. why should you buy from us not from other suppliers?
Zhejiang Hongke Electric, founded in 2010, is a professional manufacturer of fans and supporting products. Committed to providing
small and medium-sized enterprises with plant ventilation and equipment cooling solutions,
5. what services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese
Ordering and Pricing
- Minimum order quantity: 10 box
- Volume pricing:
- 10–199 box: US $302.45 / box
- 200–499 box: US $296.7 / box
- 500–999 box: US $288.65 / box
- 1000+ box: US $272.55 / box
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this mixed flow fan?
The standard minimum order quantity is 10 box. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the mixed flow fan be supplied for my local voltage?
The standard configuration is 380V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
