Recirculating Low Temperature Chiller, TOPTION, LX-1000

This recirculating low temperature chiller is published with the manufacturer’s full specification — voltage AC380V 50HZ, cooling capacity 0℃–7.5kW, -10℃–6.3kW, -20℃—3.5kW. Made by Xi’an Toption Instrument Co., Ltd. (10 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.

Key Features of This Recirculating Low Temperature Chiller

• Power: 1200 W
• Voltage: AC380V 50HZ
• Cooling Capacity: 0℃–7.5kW, -10℃–6.3kW, -20℃—3.5kW
• Capacity Of Liquid Storage: 30L
• Warranty: 1 Year
• Place Of Origin: Shaanxi, China

Technical Specifications

Product Details

Product description

Model

LX-0250

LX-0400

LX-0700

LX-1000

LX-1450

LX-2000

Temperature range

-15 to 30℃

-25 to 30℃

Cooling capacity

0℃

1.5Kw

2.4Kw

4Kw

7.5Kw

10Kw

16.5Kw

-10℃

1Kw

1.5Kw

2.7Kw

6.3Kw

8Kw

12Kw

-20℃

0.55Kw

0.8Kw

1.5Kw

3.5Kw

5Kw

7.3Kw

Circulation pump

Max 20L/min 1.5bar

Max 35L/min 1.5bar

Max 75L/min 1.5bar

Liquid storage

15L

17L

25L

30L

40L

60L

Refrigarants

R-404A

Connection size

DN15

DN20

DN25

Product size

air-cooled

400*600*1150mm

500*680*1350mm

650*700*1850mm

750*750*1800mm

Weight

115kg

145kg

180kg

225kg

290kg

340kg

1.Saving resources;closed cycle pipeline design highly prevent circulating water pollution and extend the lifetime of circulation liquid. 2.Multi-safety protection,more reliable operation. 3.Brand compressor,cascade refrigeration cooling technologies. 4.Human design,more convenient and flexible. 5.Efficient two-condensate system. 6.Computer-cascade temperature controller,temperature figures display,adjustable unit is 0.1℃,temperature range is 125℃~-20℃,PT100 temperature sensor. 7.Use of cold technology,can guarantee the stability of temperature at low temperature. 8.Can set the temperature difference of compressor on/off. 9.Monitoring the ambient temperature,prevent temperature to be higher in the running system. 10.A variety of fault alarm (over-temperature alarm, sensor alarm, high pressure alarm, compressor overheat alarm, liquid level alarm). 11.Power on delay protection,three-level cascade system protectors. 12.All parts are safety grounding. 13.Adopt full closed circulation design,no water vapor at low temperature and ensure the purity of cooling medium,in case of ice crystals,provide a long lifetime of heat transfer liquid. 14.High-performance circulating pump, can guarantee 24 hours continuously running a day. 15.Use plate cool-heat-exchanger,heat transfer efficiency is provided.

Related Products

Packaging and feedback

Certificate And Exhibition

Our Advantages

Company Profile

FAQ

1. How can I choose the suitable one? Dear customer, please tell us your detailed requirements by mail or online, we will recommend the suitable one as your request. 2.What can you buy from us? Molecular Ditillation/Crystallization Purify/Rotary Evaporator/Dewaxing Filtration/Ethanol Centrifuge Extractor/Wiped Film Evaporator/Glass reactor /Spray dryer/Agitated Nutsche Filter Dryer/Wiped fIm distillation/Freeze dryer 3. How can I pay? Dear customer, we accept many payment term, such as T/T, Western Union… 4. When I receive it after pay? Dear customer, normal models can be delivered with 7-9 days, please contact us to check transport time to your address. 5. How to deliver? Dear customer, we can send by Express, by Sea and by Air. 6. Is will be broken during transport? Dear customer, please do not worry, we do standard export package. 7. What should I do if I do not know how to use? Dear customer, please do not worry, manual user will be sent together, you can also contact us with more technological support. 8. Can you provide OEM or ODM service? Yes, we not only can provide a standard model. but also have a strong developing team to support OEM and ODM service. We can provide all kinds of customized services according to your request.

Ordering and Pricing

• Minimum order quantity: 1 set
• Volume pricing:
  • 1–4 set: US $5500 / set
  • 5–9 set: US $5300 / set
  • 10+ set: US $5000 / set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this recirculating low temperature chiller?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Can the recirculating low temperature chiller be supplied for my local voltage?

The standard configuration is AC380V 50HZ. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Xi’an Toption Instrument Co., Ltd., based in China. The company 10 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Xi’an Toption Instrument Co., Ltd. range on HVACR Nexus.
