Key specification for this rotary evaporator: 380V, capacity 20L ~6000L. Everything below is reproduced from the factory data sheet. Made by Careddi Technology Co., Ltd. (17 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Rotary Evaporator
- Power Source: Electric
- Power(W): 5kw
- Voltage: 380V
- Capacity: 20L ~6000L
- Material: High Borosilicate Glass
- Rotating Speed: 5-110
Technical Specifications
| Processing | Vacuum Distillation |
|---|---|
| Power Source | Electric |
| Core Components | PLC, Gearbox, Gear, Pump |
| Voltage | 380V |
| Warranty | 3 Years |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | High Productivity |
| Power(W) | 5kw |
| Place Of Origin | Jiangsu, China |
| Brand Name | Careddi |
| Dimension(L*W*H) | 110x70x200 |
| Product Name | Rotary Vacuum Evaporator |
| Usage | CBD Oil Separation |
| Material | High Borosilicate Glass |
| Vacuum Degree | 0.098Mpa |
| Main Uses | Hemp Oil Concentration |
| Sealing | PTFE Sealing |
| Capacity | 20L ~6000L |
| Final Product | Pure Cbd Oil |
| Rotating Speed | 5-110 |
| Evaporating Flask | 50L |
| Selling Units | Single item |
Product Details
Industrial Vacuum Rotary Evaporator
PTFE bottom discharge valve, no pollution of grease
Main parts made by using #304 stainless steel material
Japanese Tech of AC induction motor, variable speed, no brush, no spark
Features
1.This machine adopts advanced frequency conversion technology and electronic speed regulation, which can ensure the stable operation of the motor. So this machine has high evaporation rate, high recovery.
2. The bath pot can reduce the damage in the lifting process. During the evaporation of low boilling point, collecting bottle can be immersed in bath, which can reduce the secondary evaporation.
3. The collecting bottle connected by mouth ball milling connection, easy loading and unloading, and it has high sealing.
4. High temperaturedurable seal, dynamic seal system has corrosion resistance and long life time, good air tightness under high temperature.
5. Using Japanese technology-AC inducction motor, stepless speed regulation, no brush, no spark, can work long time effectively.
6. Rotay evaporator chassis, bath, main rod, shaft are mde of high quality stainless steel, beautiful apprearance and corrosion resistance.
7. Intelligent temperature control, water and oil bath, more widely application. The temperature fluctuation is relatively small, only 0.2 C error. Evaporation is more stalbe, not easy to wash away the material.
8. The series of modular design, strong expanibility, easy installation, convenient maintenance.
Technical Parameters | ||||||||||
Model | PR-2 | PR-5 | PR-10 | PR-20 | PR-50 | |||||
Evaporation Flask (L) | 2L | 5L | 10L | 20L | 50L | |||||
Collection bottle(L) | 1L | 2L OR 3L | 5L | 10L+5L | 10L+10L | |||||
Bath heating power (KW) | 1.5 | 2 | 3 | 5 | 5 | |||||
Vacuum pressure (Mpa) | 0.096 | 0.096 | 0.096 | 0.096 | 0.096 | |||||
Rotation speed (RPM) | 10-180 | 10-90 | 5-110 | 5-110 | 5-110 | |||||
Evaporation rate (H2O)(L/H) | 1.2 | 2 | 3.5 | 5 | 8 | |||||
Motor power(W) | 40 | 90 | 120 | 120 | 180 | |||||
Power phase | 2 phase | 2 phase | 3 phase | 3 phase | 3 phase | |||||
SIZE(LXWXH) (Cm) | 55x35x75 | 55x35x110 | 100x50x180 | 110x70x200 | 120x80x220 | |||||
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–1 set: US $7500 / set
- 2–2 set: US $7300 / set
- 3+ set: US $7000 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this rotary evaporator?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the rotary evaporator be supplied for my local voltage?
The standard configuration is 380V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Careddi Technology Co., Ltd., based in China. The company 17 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Careddi Technology Co., Ltd. range on HVACR Nexus.
