Key specification for this shaded pole motor: type Brushless Motor, model number 4A-WXT-986/YYB-4WJLXM3C1-2D. Everything below is reproduced from the factory data sheet. Made by Hainan Yimingde Mechanical & Electrical Equipment Co., Ltd. (1 year on the platform, typical reply ≤1h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Shaded Pole Motor
- Model Number: 4A-WXT-986/YYB-4WJLXM3C1-2D
- Rated Power: 22
- AC Voltage: 220V
- Housing Material: Metal Encapsulated
- Rated Speed: 1350RPM
- Warranty: 3Years
Technical Specifications
| Phase | Single-Phase |
|---|---|
| AC Voltage | 220V |
| Rated Power | 22 |
| Rated Speed | 1350RPM |
| Type | Brushless Motor |
| Frame | 80 mm |
| Motor Mounting Type | Foot Mount |
| Protect Feature | Drip-proof |
| Efficiency | IE3 |
| Warranty | 3Years |
| Model Number | 4A-WXT-986/YYB-4WJLXM3C1-2D |
| Brand Name | Yimingde |
| Place Of Origin | Hainan, China |
| Frequency | / |
| Housing Material | Metal Encapsulated |
| Customization | Support Customization |
| Bearing | Ball Bearing |
| Optional Shaft Type | Single/ Double Shaft Extension |
| Hertz | 50Hz |
| Application Scenario | Home Appliance |
| Advantages | Durable/ Low Noise/ Cost-effective/ Plug-and-Play/ Low Cost |
| Assembly Type | 3-Point Riveted Assembly |
| Operation Mode | Continuous Operation |
| Winding Technology | External Winding |
| Selling Units | Single item |
| Single Package Size | 10.54X10.54X28 cm |
| Single Gross Weight | 0.96 kg |
Ordering and Pricing
- Minimum order quantity: 2 piece
- Volume pricing:
- 2–49 piece: US $6.92 / piece
- 50–499 piece: US $6.72 / piece
- 500–4999 piece: US $6.44 / piece
- 5000+ piece: US $6.23 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this shaded pole motor?
The standard minimum order quantity is 2 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3Years warranty. Spare parts and technical support remain available after the warranty period.
Can the shaded pole motor be supplied for my local voltage?
The standard configuration is 220V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Hainan Yimingde Mechanical & Electrical Equipment Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, Trading Company. Browse the full Hainan Yimingde Mechanical & Electrical Equipment Co., Ltd. range on HVACR Nexus.
