This shell and tube is published with the manufacturer’s full specification — 220v/380v/customized, material Stainless Steel/Titanium. Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Shell And Tube
- Voltage: 220v/380v/customized
- Material: Stainless Steel/Titanium
- Tube Material: Titanium and 316 Stainless Steel
- Warranty: 2 Years
- Place Of Origin: Guangdong, China
- Application: Heat Transfer
Technical Specifications
| Heat Exchanger Type | Plate Heat Exchanger |
|---|---|
| Material | Stainless Steel/Titanium |
| Voltage | 220v/380v/customized |
| Core Components | Motor, Pump |
| Warranty | 2 Years |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | High Safety Level |
| Working Temperature Range | -20 to 130 C |
| Place Of Origin | Guangdong, China |
| Weight (Kg) | 10 |
| Brand Name | Precise Heater |
| Liquid Flow Rate | 2.5m/s |
| Maximum Pressure Rating | 10Mpa(1450.38psi) |
| Dimension(L*W*H) | Custimized Made |
| After-Sales Service Provided | Overseas third-party support available |
| Tube Material | Titanium and 316 Stainless Steel |
| Application | Heat Transfer |
| Medium | Saltwater-Chemical Solutions-Steam Air |
| Connection Type | Custermized |
| Marketing Type | Hot Product 2019 |
| Selling Units | Single item |
| Single Package Size | 40X50X80 cm |
| Single Gross Weight | 20.0 kg |
Product Details
Shell and Tube Heat Exchangers
| Exchanger area Sq.ft(sq.m) | Overall length In./(mm) | DIA In./mm | Inlet/ Outlet | Model number | SHIP WGT Lbs./(Kg) |
| 5.5 (.50) | 12 (305) | 6 (150) | 3/4’’ | IS5.5-6-12 | 20 (9) |
| 11 (1.00) | 20 (508) | 6 (150) | 1’’ | IS11-6-20 | 24 (11) |
| 16.5 (1.50) | 28 (711) | 8 (203) | 1’’ | IS16.5-8-28 | 30 (13.5) |
| 22 (2.00) | 35 (890) | 9 (230) | 1.5’’ | IS22-9-35 | 36 (16.5) |
| 27.5 (2.50) | 39 (1000) | 10 (255)
| 2’’ | IS27.5-10-39 | 44 (20) |
| 33 (3.00) | 47 (1200) | 12 (305)
| 2’’ | IS33-12-47 | 52 (23.5) |
| 38.5 (3.50) | 53 (1350) | 14 (355)
| 2’’ | IS38.5-14-53 | 59 (27) |
| 44 (4.00) | 59 (1500) | 16 (406) | 2’’ | IS44-16-59 | 68 (31) |
| 49.5 (4.50) | 64 (1625) | 18 (460) | 2’’ | IS49.5-18-64 | 77 (35) |
| 55 (5.00) | 69 (1752) | 20 (508) | 2’’ | IS55-20-69 | 86 (39) |
RODUCT DESCRIPTION
Provides extremely high thermal transfer for package size.
FEATURES
Patented fabrication process ensures consistent, high quality production.
No gaskets to fail. TIG welding is used on the sheet edge (which separates Circuit A from Circuit B).
Offers easy installation and servicing. Manifolding is simplified for larger applications. Heat loss is low, requiring little or no insulation.
SPECIFICATIONS
Maximum single circuit capacity 300 fluid ounces (8.5 liters).
Temperature range: -60°F (-50°C) to 480°F (250°C)
Pressure rating:Axial Circuit A: 230 PSI (1586 kPa or 16 bar), Spiral Circuit B: 360 PSI (2482 kPa or 25 bar)
Ten sizes from 5.5 ft2 (.50 m2) to 55 ft2 (5.0 m2). Compact cylinders from 6” (150mm) x 12” (305mm) to 20” (508mm) x 69” (1750mm).
OPTIONS AVAILABLE (CONSULT FACTORY)
Standard unit is 316 Stainless Steel. Titanium available as an option.
Ordering and Pricing
- Minimum order quantity: 1 unit
- Volume pricing:
- 1–4 unit: US $900 / unit
- 5+ unit: US $850 / unit
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
