This solution lightweight piezo fan is published with the manufacturer’s full specification — material PZT, type Piezoelectric Ceramics. Made by Chengdu Huitong West Electronic Co., Ltd. (3 years on the platform, typical reply ≤10h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Solution Lightweight Piezo Fan
- Model Number: Piezo fan
- Input Voltage: DC9V~36V
- Output Voltage: 90V~180V
- Material: PZT
- Place Of Origin: Sichuan, China
- Type: Piezoelectric Ceramics
Technical Specifications
| Type | Piezoelectric Ceramics |
|---|---|
| Material | PZT |
| Place Of Origin | Sichuan, China |
| Brand Name | HTW |
| Model Number | Piezo fan |
| Input Voltage | DC9V~36V |
| Operating Temperature Range | -40℃/~85℃ |
| Insulation Resistance | ≥100MΩ |
| Customization | Supported |
| Output Voltage | 90V~180V |
| Output Frequency | Hz |
| Operation Life | MTTF>100000h |
| Selling Units | Single item |
| Single Package Size | 25X20X18 cm |
| Single Gross Weight | 1.000 kg |
Product Details
| Piezoelectric Fan — Single Blade Configuration Specification | |||||||||||
| Model | Width (mm) | Length (mm) | Power supply (Vin) | Driving power (Vour) | Current (mA) | Max power (W) | Frequency (HZ) | Max wind speed (S) | Wind volume | Max Wind Pressure (Pa) | Max Amplitude (L) |
| HTPF-4 | 4 | 50~56 | 9~32 | 50~140 | 0.7 | 0.08 | 86~118 | 1.4~1.8 | S × L | 6 | >24 |
| HTPF-5 | 5 | 50~56 | 9~32 | 50~140 | 0.7 | 0.08 | 86~118 | 1.6~2.0 | S × L | 6.5 | >24 |
| HTPF-7 | 7 | 50~56 | 9~32 | 50~140 | 0.9 | 0.08 | 86~118 | 1.8~2.4 | S × L | 6.8 | >24 |
| HTPF-8 | 8 | 50~56 | 9~32 | 50~140 | 0.9 | 0.08 | 86~118 | 2.0~2.8 | S × L | 6.9 | >24 |
| HTPF-9 | 9 | 50~56 | 9~32 | 50~140 | 0.9 | 0.08 | 86~118 | 2.8~3.2 | S × L | 7.4 | >24 |
| HTPF-10 | 10 | 50~56 | 9~32 | 50~140 | 1.0 | 0.09 | 86~118 | 3.5~4.0 | S × L | 9 | >24 |
| HTPF-11 | 11 | 50~56 | 9~32 | 50~140 | 1.1 | 0.09 | 86~118 | 3.2~4.2 | S × L | 9.5 | >24 |
| HTPF-12 | 12 | 50~56 | 9~32 | 50~140 | 1.1 | 0.09 | 86~110 | 3.8~4.8 | S × L | 10 | >24 |
| HTPF-15 | 15 | 50~56 | 9~32 | 50~140 | 1.5 | 0.15 | 86~118 | 4.6~6.2 | S × L | 15 | >24 |
| HTPF-18 | 18 | 50~56 | 9~32 | 50~140 | 1.8 | 0.2 | 86~118 | 5.0~6.9 | S × L | 20 | >24 |
| HTPF-20 | 20 | 50~56 | 9~32 | 50~140 | 2.0 | 0.24 | 86~118 | 5.6~7.6 | S × L | 25 | >24 |
| HTPF-22 | 22 | 50~56 | 9~32 | 50~140 | 2.3 | 0.28 | 86~118 | 6.0~8.2 | S × L | 30 | >24 |
| HTPF-24 | 24 | 50~56 | 9~32 | 50~140 | 2.4 | 0.3 | 86~118 | 6.5~8.8 | S × L | 35 | >24 |
| HTPF-26 | 26 | 50~56 | 9~32 | 50~140 | 2.6 | 0.33 | 86~108 | 6.8~9.2 | S × L | 38 | >24 |
| HTPF-28 | 28 | 50~56 | 9~32 | 50~140 | 2.8 | 0.36 | 86~118 | 7.2~9.5 | S × L | 39 | >24 |
| HTPF-30 | 30 | 50~56 | 9~32 | 50~140 | 3.0 | 0.4 | 86~118 | 8.4~10 | S × L | 43 | >24 |
| Remark: The models listed above are standard configurations. For additional specifications or special requirements, please contact our sales representative.Customization is available. Lead time for samples and mass production is 30 days. | |||||||||||
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–99 piece: US $25 / piece
- 100+ piece: US $12 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this solution lightweight piezo fan?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
Can the solution lightweight piezo fan be supplied for my local voltage?
The standard configuration is DC9V~36V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
