The split air conditioner listed here carries power supply 110-120V/ 208-230V/ 220-240v, capacity 8001-10000, documented exactly as the manufacturer publishes it. Made by Foshan Sylon Electrical Appliance Co., Ltd. (11 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Split Air Conditioner
- Model Number: SYLON-X1
- Power Type: AC
- Power Source: Electric
- Power (W): 1100-2000W
- Power Supply: 110-120V/ 208-230V/ 220-240v
- Capacity (Btu): 8001-10000
Technical Specifications
| Application | Hotel, Commercial, Household |
|---|---|
| Capacity (Btu) | 8001-10000 |
| Cooling/Heating | Cooling/Heating |
| Energy Efficiency Rating | Class A |
| Fixed Frequency/Variable Frequency | Variable Frequency |
| Recommended Room Size（Square Feet） | ≥200 |
| Eer | 2-4 |
| Warranty | 1 Year |
| After-Sales Service Provided | Free Spare Parts |
| Power Type | AC |
| App-Controlled | Yes |
| Remote Control | Yes |
| Timer | Yes |
| Operating Language | English, German, French, Dutch, Spanish |
| Private Mold | Yes |
| Power Source | Electric |
| Logo/Graphic Design | Silk Screen Printing, Laser Printing, Inkjet Printing, Hot Stamping, UV Printing, Heat-Transfer Printing, 3D Printing |
| Place Of Origin | Guangdong, China |
| Brand Name | SYLON |
| Cop | 2-6 |
| Maximum Airflow Rate | 1081m³/h |
| Power (W) | 1100-2000W |
| Model Number | SYLON-X1 |
| Product Name | Air Conditioning |
| Keyword | Wall Mounted Ac |
| Refrigerant | R410A/R32 |
| Function | Cooling Wall Mounted Air Conditioner |
| Power Supply | 110-120V/ 208-230V/ 220-240v |
| Cooling Capacity | 9000-36000 Btu/h |
| Brand | OEM Customer Brand |
| Air Flow Volume | 1081 |
| Compressor | Famous Brand Rotary Compressor |
| Control | Remote + Wifi Optional |
| Use | Room |
| Condition | New |
| Type | Split Wall Mounted Air Conditioners |
| Selling Units | Single item |
| Single Package Size | 105X39X31 cm |
| Single Gross Weight | 51.000 kg |
Product Details
Product description
Technical parameter
| Model | SSDH-24DH | SSDH-12DH | SSDH-9DH | SSDH-18DH | ||
| Power supply | Ph-V-Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | |
| Cooling | Capacity | Btu/h | 5763 | 3068 | 2900 | 3409 |
| Input | W | 1908 | 1197 | 1123 | 1291 | |
| Rated current | A | 8.9 | 5.48 | 5.15 | 5.94 | |
| EER | W/W | 3.02 | 2.56 | 2.6 | 2.64 | |
| Max. input power | W | 2480 | 798 | 560 | 838 | |
| Max. current | A | 11.57 | 3.65 | 5 | 3.96 | |
| Heating | Capacity | Btu/h | 6633 | 3061 | 3200 | 3885 |
| Input | W | 2069 | 936 | 1100 | 1145 | |
| Rated current | A | 9.7 | 4.29 | 5 | 5.28 | |
| EER | W/W | 3.21 | 3.27 | 3.03 | 3.39 | |
| Max. input power | W | 2689 | 624 | 960 | 763 | |
| Max. current | A | 12.61 | 2.86 | 6 | 3.52 | |
| Compressor | Model | KSN140D33UFZ3 | KSK75D43UEZA | KSK75D43UEZA | KSK89D33UEZD3 | |
| Type | Rotary | Rotary | Rotary | Rotary | ||
| Brand | GMCC | GMCC | GMCC | GMCC | ||
| Indoor coil | a.Number of rows | 716-12-ⅡK7-1.4(QS) | 530-10-ⅡK7-1.3(QS) | 530-10-ⅡK7-1.3(QS) | 605-12-ⅡK7-1.3(QS) | |
| Indoor air flow (Hi/Mi/Lo) | m3/h | 1081 | 481 | 469 | 593 | |
| Indoor noise level | dB(A) | 48 | 48 | 48 | 48 | |
| Indoor Fan motor | Type | cross flow | cross flow | cross flow | cross flow | |
| output | W | 30 | 13 | 13 | 18 | |
| Indoor Fan Speed | Cooling | rpm | 1150 | 1150 | 1150 | 1150 |
| Heating | rpm | 1050 | 1050 | 1050 | 1050 | |
| Dry | rpm | 950 | 950 | 950 | 950 | |
| Sleep | rpm | 850 | 850 | 850 | 850 | |
| Indoor unit | Dimension(W*H*D) | mm | 950*315*222 | 750*260*196 | 750*260*196 | 840*290*202 |
| Packing (W*H*D) | mm | 1048*390*305 | 825*335*255 | 825*335*255 | 920*345*255 | |
| Net/Gross weight | Kg | 14/16 | 8/9 | 8/9 | 10.5/12.5 | |
| Outdoor fan motor | Type | axial fan | axial fan | axial fan | axial fan | |
| Speed | r/min | 860 | 860 | 860 | 860 | |
| output | W | 50 | 25 | 25 | 25 | |
| Outdoor coil | a.Number of rows | 800-680-20-ⅡB7.94-1.4(QS) | 500-8-ⅠK7.94-1.4-8(QS) | 427-9-ⅠK7.94-1.4(QS) | 500-10-ⅠK7.94-1.4(QS) | |
| Outdoor noise level | dB(A) | 50 | 50 | 50 | 50 | |
| Outdoor unit | Dimension(W*H*D) | mm | 830*550*295 | 730*550*280 | 630*500*236 | 730*280*550 |
| Packing (W*H*D) | mm | 905*373*599 | 845*371*590 | 750*332*528 | 845*371*590 | |
| Net/Gross weight | Kg | 32/35 | 22/24 | 20.3/22.4 | 28/32 | |
| Refrigerant type/Refrigerant charge | g | R32/1000g | R32/450g | R32/460g | R32/630g | |
| Refrigerant piping | Liquid side/ Gas side | mm(inch) | 12-6 | 9-6 | 9-6 | 12-6 |
| Max. refrigerant pipe length | m | 15 | 15 | 15 | 15 | |
| Max. difference in level | m | 5 | 5 | 5 | 5 | |
| power cord/Connecting line | Electric wire | Core number x Size x Length | 16A 1.5mm2×3 1.5m | 16A 1.5mm2×3 1.5m | 16A 1.5mm2×3 1.5m | 13A 1.5mm2×3 1.5m |
| I&O connection cable | Core number x Size x Length | 4×1.5mm2x (3.8m) | 4×1.5mm2x (3.8m) | 4×1.5mm2x (3.8m) | 4×1.5mm2x (3.8m) | |
| Operation temperature range | ℃ | 16~31 | 16~31 | 16~31 | 16~31 | |
| Room temperature | Indoor(cooling/ heating) | ℃ | 43 | 43 | 43 | 43 |
| Outdoor(cooling/heating) | ℃ | -7 | -7 | -7 | -7 | |
| Application area (Cooling Standard) | m² | 20~37 | 16~26 | 10~15 | 15~30 | |
Company factory profile
exhibition
certificate
Business partner
Customer feedback
shipment
FAQ
1.Can you provide OEM service?
Yes, we always provide our customer with a upgraded OEM quality control solution, also we are able to help marketing your brand better by better product package and displays.
2.What is your delivery time?
For the standard unit, about 35-40days.
3.What is your product guarantee?
Our products have strict quality control, lifespan for proper use can be 5-10 years.
Also we provide 1% free spare parts for your maintenance and aftersales services.
4.Have quantity requirement for light commercial products?
MOQ required full 40HQ container at least 20sets per model which can mixing two or three models.
5.Do you have technical support?
We have professional technical team to answer technical question at 24×7, also have detailed user manual contain in the goods package.
6.Would you help me to manage the transportation to my country?
Yes, our professional logistic team will help you to arrange cost effective shipping service to get you fast shipment with less cost.
7.How can I trust your company?
We are one of the best professional HVAC solution suppliers in China with more than 10years experience, also we are authorized agent for some reputed brands such as Dunham-Bush(a USA brand with 126 years) and TICA Climate (a Carrier holding company), you can verify us by any means, if needed we can also provide business references around your region as credibility testimonial materials.
Ordering and Pricing
- Minimum order quantity: 100 set
- Volume pricing:
- 100–299 set: US $288 / set
- 300–499 set: US $258 / set
- 500–999 set: US $238 / set
- 1000+ set: US $198 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this split air conditioner?
The standard minimum order quantity is 100 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the split air conditioner be supplied for my local voltage?
The standard configuration is 110-120V/ 208-230V/ 220-240v. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Foshan Sylon Electrical Appliance Co., Ltd., based in China. The company 11 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Foshan Sylon Electrical Appliance Co., Ltd. range on HVACR Nexus.
