The steam boiler listed here carries 220V / 380V / 415-440V for option, 1450rpm, 2200rpm, 2900rpm, documented exactly as the manufacturer publishes it. Made by Foshan Chosen Vent Tech Ltd. (16 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Steam Boiler
- Model Number: BSW315
- Voltage: 220V / 380V / 415-440V for option
- Material: Stainless Steel, Aluminum Alloy, Steel , Plastic
- Blade Material: Powder coating / Aluminum Alloy / Stainless steel
- Material Of Fan Housing: Mild steel with powder coating / #304 S.S., #316 S.S., #316L S.S.
- Speed: 1450rpm, 2200rpm, 2900rpm
Technical Specifications
| Mounting | Duct Fan |
|---|---|
| Voltage | 220V / 380V / 415-440V for option |
| Speed | 1450rpm, 2200rpm, 2900rpm |
| Material | Stainless Steel, Aluminum Alloy, Steel , Plastic |
| Blade Material | Powder coating / Aluminum Alloy / Stainless steel |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM |
| Place Of Origin | Guangdong, China |
| Brand Name | CHOSEN |
| Model Number | BSW315 |
| Pressure | 1611-105 Pa |
| Diameter Of Impeller | 315 mm |
| Material Of Fan Housing | Mild steel with powder coating / #304 S.S., #316 S.S., #316L S.S. |
| Impeller Type | Backward centrifugal fan |
| Selling Units | Single item |
| Single Package Size | 101X88X93 cm |
| Single Gross Weight | 139.0 kg |
Product Details
Advantages
· The Fan with Compact structure.
· The impeller will do by dynamic balancing tests. It greatly improves the stability of the impeller operation, and reduces the vibration and noise.
· The Fan with advantages of small volume, light weight, angle adjustable and convenient for installation and maintenance.
· Transportation gas temperature at -20℃ ~ 300℃.
· The fan performance be test by airway or AMCA both available, the fan performance data is truth and reliable.
· Fan Material is optional according to your need.
· Customzation is acceptable.
| Backward Centrifugal Fan – SWSI – BSW | ||||
| Model | Speed | Air flow | Total Pressure | Power |
| rpm | m³/h | Pa | kw | |
| BSW280 | 2900 | 1177-3709 | 1133-317 | 1.5 |
| BSW315 | 2900 | 1734-5463 | 1611-451 | 2.2 |
| 2200 | 1271-4006 | 825-231 | 1.1 | |
| 1450 | 838-2640 | 376-105 | 1.1 | |
| BSW355 | 2900 | 2399-7559 | 1821-509 | 3 |
| 2400 | 1985-6256 | 1247-349 | 2.2 | |
| 1900 | 1572-4952 | 782-219 | 1.1 | |
| 1450 | 1199-3779 | 455-127 | 1.1 | |
| BSW400 | 2900 | 3432-10813 | 2312-647 | 5.5 |
| 2400 | 2840-8949 | 1583-443 | 4 | |
| 1900 | 2248-7084 | 992-278 | 2.2 | |
| 1450 | 1716-5407 | 578-162 | 1.1 | |
| BSW450 | 2900 | 4886-15396 | 2870-818 | 7.5 |
| 2400 | 4044-12742 | 1966-561 | 5.5 | |
| 1900 | 3201-10087 | 1232-351 | 3 | |
| 1450 | 2443-7698 | 718-205 | 1.1 | |
| BSW500 | 2900 | 6702-21119 | 3721-1061 | 15 |
| 2400 | 5547-17478 | 2548-727 | 11 | |
| 1900 | 4391-13837 | 1597-455 | 5.5 | |
| 1450 | 3351-10560 | 930-265 | 2.2 | |
| BSW560 | 2240 | 7273-22918 | 2785-794 | 15 |
| 1450 | 4708-14836 | 1167-333 | 3 | |
| 1250 | 4059-12789 | 867-247 | 2.2 | |
| 960 | 3117-9822 | 511-146 | 1.5 | |
| BSW630 | 2240 | 10356-32632 | 3524-1005 | 18.5 |
| 2000 | 9247-29136 | 2810-801 | 15 | |
| 1800 | 8322-26222 | 2276-649 | 11 | |
| 1600 | 7397-23309 | 1712-488 | 7.5 | |
| 1400 | 6704-21123 | 1477-421 | 7.5 | |
| 1250 | 5779-18210 | 1097-313 | 3 | |
| 1120 | 5178-16316 | 881-251 | 2.2 | |
| 960 | 4438-13985 | 647-185 | 1.5 | |
| BSW710 | 1950 | 12904-40661 | 3392-967 | 22 |
| 1800 | 11912-37534 | 3028-863 | 18.5 | |
| 1600 | 10588-33363 | 2393-682 | 11 | |
| 1440 | 9596-30235 | 1929-550 | 7.5 | |
| 1250 | 8272-26065 | 1394-397 | 7.5 | |
| 1120 | 7412-23354 | 1119-319 | 5.5 | |
| 1000 | 6618-20852 | 892-254 | 4 | |
| 960 | 6353-20018 | 783-223 | 3 | |
| BSW800 | 1800 | 17040-53693 | 3495-996 | 30 |
| 1600 | 15147-47727 | 2899-827 | 22 | |
| 1440 | 13632-42954 | 2349-670 | 18.5 | |
| 1250 | 11833-37287 | 1753-500 | 11 | |
| 1120 | 10603-33409 | 1353-386 | 7.5 | |
| 960 | 9088-28636 | 1044-298 | 7.5 | |
| 800 | 7573-23863 | 718-205 | 3 | |
| 710 | 6721-9626 | 571-554 | 2.2 | |
| 11551-21179 | 545-163 | 3 | ||
| Click here to view more models. | ||||
Applications
· For building ventilation system, air-conditioning(HVAC), purification equipment and High-temperture system.
· For equipments or system of filtration & drying, fume hood & spray booth, paiting room, food processing , kitchen room and so on.
CHOSEN VENT TECH LTD. is a manufacturer of ventilation and cooling equipment with more than 10 years experience.
Professional Products:
1. Centrifugal Fan, Axial Fan, HVLS Fan, Fan Impeller, Mist Fan.
2. Non-standard units & small order.
3. Accessories: Forward Impeller, Backward Impeller, Axial Impeller, Atomizer.
4. Meanwhile we specialized in ventilation & cooling solution of industrial building.
Professional Manufacturing:
1. Experienced engineers and R&D team to support the product technology & development.
2. Advanced manufacturing & inspection equipment, we have Laser cutting equipment, CNC equipment, Dynamic balance equipment, Air-flow/pressure/speed testing equipment.
3. Inspection. All products with serious inspection in hundred percent before delivery.
Professional Service:
1. Our products be export to more than 30 countries.
2. On time delivery.
3. The experienced customers service team provides excellent communication for all customers to answer questions and solve problem.
Our Aim:
1.Company's Aim: Honesty, Gratitude.
2.Service's Aim: Professionalism, Scrupulous, Responsibility.
3.Product's Aim: High quality, Reasonable price, for customers' requirements.
Our mission:
1. Provide quality products all over the world.
2. Set up fine managing and brand credit for "MADE IN CHINA"
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–20 piece: US $456 / piece
- 21–50 piece: US $418 / piece
- 51+ piece: US $380 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this steam boiler?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the steam boiler be supplied for my local voltage?
The standard configuration is 220V / 380V / 415-440V for option. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
