This turning electric motor is published with the manufacturer’s full specification — type Synchronous Motor, 115.38RPM. Made by Suzhou Sok Micro Motor Manufacturing Co., Ltd. (11 years on the platform, typical reply ≤6h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Turning Electric Motor
- Model Number: 90TDY115S4-2
- Input Power: 80W
- AC Voltage: 220V
- Speed: 115.38RPM
- Place Of Origin: Jiangsu, China
- Protect Feature: Drip-proof
Technical Specifications
| Phase | Three-Phase |
|---|---|
| AC Voltage | 220V |
| Type | Synchronous Motor |
| Protect Feature | Drip-proof |
| Efficiency | Other |
| Model Number | 90TDY115S4-2 |
| Brand Name | SOK MOTOR-slow turning electric motor |
| Place Of Origin | Jiangsu, China |
| Frequency | 50Hz |
| Slow Turning Electric Motor | 220V 90mm three phaseslow ac turning electric motor |
| Speed | 115.38RPM |
| Input Current | 0.40A |
| Input Power | 80W |
| Max. Torque | 3300mN.m |
| Rated Torque | 3000mN.m |
| Starting Torque | 1600mN.m |
| Insulation Class | B |
| Weight | 3.2kg |
| Packaging Details | Ctn size: 400*380*330mm 8 pcs/ctn, N.W.: 25.6kgs, G.W.:26.8kgs Delivery : within 30 days after payment Apply to slow turning electric motor |
| Port Of Dispatch | Shanghai |
| Selling Units | Single item |
| Single Package Size | 17X18X19 cm |
| Single Gross Weight | 3.0 kg |
| Supply Ability | 15000 pieces per Month Apply to slow turning electric motor |
Product Details
Other motor technologies(induction,DC,servo and step motors)either need gear reducers,or electronic drives to match the speed of SOK synchronous motors. The cost of just the gear reduction or the cost of the electronic drive will usually exceed the total cost of the SOK synchronous motor.
For even slower speeds planetary gear reducers are offered. SOK synchronous motors produce very slow speed with only modest gear reductions.
Typical application of slow turning electric motor
Auto-testing equipments
Medical equipments
Timing belt drives
X-ray scanning
Textile machines
Electrical valve actuator
Cryogenic pump
Heat exchanger
Remote control of switches rheostat
Printing,packaging machines
Antenna rotors
Auto-welding machines
1.Temperature:-25℃～ +40℃；
2.Relative humidity:≤95%；
3.Atmospheric pressure :74.8KPa（2500m);
4.Vibration:10～55Hz,double amplitude1.5mm;
5.Impact: 150m/s2
Electric motor parameter of slow turning electric motor
Note: The typical specifications below are just for your reference. Motors’ voltage ,frequency, speed , torque, shaft extension, outline dimension and insulation class can be customized. Please feel free to contact us if you can’t find the motor you required. We are always here being ready to help.
Dimension of slow turning electric motor
Wiring diagram of slow turning electric motor
55mm High quality electric Ac Motor
91.8% Response Rate
55mm TYJ Series 220V PM Synchronous Electrical Gearmotor
91.8% Response Rate
135mm Single phase acasynchrous motor for barrier gate
91.8% Response Rate
Ordering and Pricing
- Minimum order quantity: 50 piece
- Volume pricing:
- 50–149 piece: US $34.3 / piece
- 150+ piece: US $32.5 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this turning electric motor?
The standard minimum order quantity is 50 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
Can the turning electric motor be supplied for my local voltage?
The standard configuration is 220V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Suzhou Sok Micro Motor Manufacturing Co., Ltd., based in China. The company 11 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Suzhou Sok Micro Motor Manufacturing Co., Ltd. range on HVACR Nexus.
