The ventilation duct fan listed here carries 12 V, blade material Plastic, documented exactly as the manufacturer publishes it. Made by Shenzhen Topfan Technology Development Co., Ltd. (17 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Ventilation Duct Fan
- Model Number: MX10025GBH2
- Voltage: 12 V
- Blade Material: Plastic
- Material: Plastic Blade Plastic Frame
- Warranty: 1 Year
- Certification: CE Rohs
Technical Specifications
| Voltage | 12 V |
|---|---|
| Blade Material | Plastic |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM |
| Place Of Origin | China |
| Brand Name | MX |
| Model Number | MX10025GBH2 |
| Product Name | DC centrifugal fan |
| Application | General Machinery |
| Protection Class | IP58 IP68 |
| Certification | CE Rohs |
| LOW NOISE | HIGH EFFECIENCY |
| Material | Plastic Blade Plastic Frame |
| Type | Centrifugal Fan |
| Applicable Industries | hotels, Garment Shops, Machinery Repair Shops, Food & Beverage Factory, Home Use, Construction works , Energy & Mining, Advertising Company |
| Core Components | motor |
| Selling Units | Single item |
| Single Package Size | 10X10X2.5 cm |
| Single Gross Weight | 0.2 kg |
Product Details
Model | Bearing Type | Rated Volt | Operating Volt | Rated Current | Input Power | Speed | Max. Airflow | Max. Static Pressure | Noise Level | ||||||||
Part No. | S B Y | VDC | VDC | AMP | Watt | RPM | CFM | Pa | dB-A | ||||||||
MX10025GBH2 | B | 24 | 13.8-26.8 | 0.44 | 10.56 | 6400 | 62.5 | 560 | 60 | ||||||||
MX10025GBH4 | B | 48 | 36.8-60.5 | 0.22 | 10.56 | 6400 | 62.5 | 560 | 60 | ||||||||
More Models | Other RPM/CFM/Voltage/Current…please contact us see the specification for more details. | ||||||||||||||||
Product Name | DC Axial Fan |
Brand | MX topfan/OEM/ODM |
Frame and Impeller | Plastic(94V-0)，PBT |
Bearing Type | Sleeve bearing&Ball Bearing |
Function Range | PWM FG RD IP58 IP68 |
Leadwire | Red Wire Positive(+)，Black Wire Negative(-) |
Rated Voltage | 5V 12V 24V 48V … |
Operating Tempetature | -30℃ to +80℃ |
Product Applications | Household Appliances/Machine/Aeronautical/Power equipment, etc |
Topfan Technology (HK) Co.,Ltd
Lily Lee(Oversea sales)
Mobile/Skype/ whatsapp/Wechat：+86 18565860638
Tel：86-755-26070926
Fax：86-755-26070927
QQ：2865671531
E-mail: lilylee@topfanchina.cn 2865671531@qq.com
Address: 23A2, Suhao building, Nanxin road, Nanshan District, ShenZhen, China.
Ordering and Pricing
- Minimum order quantity: 100 piece
- Volume pricing:
- 100–998 piece: US $4 / piece
- 999–4998 piece: US $3.81 / piece
- 4999–4999 piece: US $3.55 / piece
- 5000+ piece: US $3.5 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this ventilation duct fan?
The standard minimum order quantity is 100 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this ventilation duct fan carry?
It is supplied with CE Rohs documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the ventilation duct fan be supplied for my local voltage?
The standard configuration is 12 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shenzhen Topfan Technology Development Co., Ltd., based in China. The company 17 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Shenzhen Topfan Technology Development Co., Ltd. range on HVACR Nexus.
