This wall mounted fan is published with the manufacturer’s full specification — capacity 21,000–30,099 BTU/h, power source Electrical. Made by Guangdong Europe Mango New Energy Technology Co., Ltd. (6 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Wall Mounted Fan
- Model Number: Wall Mounted Fan Coil 2P
- Power Source: Electrical
- Power (W): 40000
- Capacity (Btu): 21,000–30,099 BTU/h
- Cooling Capacity: 2-4kW
- Heating Capacity: 4-6kW
Technical Specifications
| Type | Split Wall Mounted Air Conditioners |
|---|---|
| Application | Commercial, Household, Hotel, Garage |
| Cooling/Heating | Cooling/Heating |
| Capacity (Btu) | 21,000–30,099 BTU/h |
| Energy Efficiency Rating | Class A |
| Eer | 3.9 |
| Power Source | Electrical |
| Feature | High Efficiency |
| Warranty | 5 year |
| After-Sales Service Provided | Free Spare Parts |
| App-Controlled | Yes |
| Fan Speed | 5 Speeds |
| Material | Plastic |
| Operating Language | English, German, French, Dutch, Spanish |
| Packaging Types | Corrugated Box |
| Place Of Origin | Guangdong, China |
| Brand | Mango |
| Power (W) | 40000 |
| Model Number | Wall Mounted Fan Coil 2P |
| Cooling Capacity | 2-4kW |
| Heating Capacity | 4-6kW |
| Function | CoolingHeating |
| Noise(DBA) | <38 |
| Selling Units | Single item |
| Single Package Size | 95X30X350 cm |
| Single Gross Weight | 10.0 kg |
Product Details
Model | Power Input | Cooling Capacity | Heating Capacity | Air Flow | Water Flow | Noise | ||
2P | 18W | 2-4kW | 4-6kW | 620m³/H | 0.75m³/H | 18-33dba | ||
3P | 45W | 5.5kW | 7.5kW | 1100m³/H | 0.94m³/H | 20-38dba | ||
Model | Motor | AL Fins | Copper Tube | Shell Material | Fan | Control | ||
2P | Welling DC Motor | Hydrophilic 22FPI 0.105mm Thick | 7*0.26mm 28tubes | HIPS Material No color change | 95mm cross fan ABS+AS+GF | 1.Sense and show room and water temp. 2.Fault self-test 3.High temp protect | ||
3P | Hydrophilic 18FPI 0.105mm Thick | 7*0.32mm 36tubes | 108mm cross fan ABS+AS+GF | |||||
Model | Coil Size | Net Size | Packing Size | Gross Weight | ||||
2P | C Type 675mm | 850*265*210mm | 910*335*280mm | 10KG | ||||
3P | C Type 855mm | 1100*330*250mm | 1180*400*320mm | 15KG | ||||
A1:Our Company Professional Supply: Heating Cooling DHW DC Inverter Heat Pump 9-34kW Swimming Pool Heat Pump 11-192kW Commercial
Heating Cooling Heat Pump 9-180kW Commercial Hot Water Heat Pump 10-72kW Water / Ground Source Heat Pump 11-200kW Water Tank and
Other Components.
Q2> What is the daily production of Mango energy company ?
A2: Mango energy one day produce heat pump water heater around 200 PCS / day.
Q3> What is Mango heat pump certification ?
A3 : Mango energy have : SGS, CE,CB, IEC60335-2-40, EN14511 certificate from TUV Lab,, got ISO9001. ISO18001, ISO14001 and
CCCcertificate. Get Class A+, A as ErP EN14825 test report .
Q4> What Mango energy do for their agent / distributor /OEM ?
A4 : Mango energy offer sales training , heat pump & solar air conditioner product training,
After sales service training , maintenance machine training , big air chiller ,or heating
Project design case training , inside parts exchange training and test training.
Q5> What Mango energy offer to their business partner ?
A5: Mango energy offer 1%~2% free spare parts according to order quantity .
Offer whole this district market exclusive sales right .
Offer rebate as this district agent sales amount within one year .
Offer best competitive price & repair parts .
Offer 24 hours online service .
Q6> where is Mango energy heat pump using ?
A6: Because Air source heat pump save energy around 70% , ( EVI heat pump and central cooling & heating heat pump ) is Widely used
in home heating, hotels hot water & heating , restaurants, hospitals,schools,bath center, residential central heating and hot
water plants, etc.
Ordering and Pricing
- Minimum order quantity: 1 unit
- Volume pricing:
- 1–9 unit: US $138 / unit
- 10–19 unit: US $130 / unit
- 20+ unit: US $124 / unit
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this wall mounted fan?
The standard minimum order quantity is 1 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 5 year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Guangdong Europe Mango New Energy Technology Co., Ltd., based in China. The company 6 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Guangdong Europe Mango New Energy Technology Co., Ltd. range on HVACR Nexus.
