The water cooled chiller listed here carries voltage 3N-380V/415V 50HZ, 9kw, documented exactly as the manufacturer publishes it. Made by Bobai Machinery (shanghai) Co., Ltd. (10 years on the platform, typical reply ≤3h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Water Cooled Chiller
- Model Number: BCA-10
- Power: 9kw
- Power Supply: 3N-380V/425V 50HZ
- Voltage: 3N-380V/415V 50HZ
- Warranty: 1 Year
- Certification: CE
Technical Specifications
| Voltage | 3N-380V/415V 50HZ |
|---|---|
| Power | 9kw |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | High-Accuracy |
| Core Components | Pump |
| Model Number | BCA-10 |
| Place Of Origin | Shanghai, China |
| Weight (Kg) | 350 |
| Brand Name | BOBAI |
| Dimension(L*W*H) | 1600mm*810mm*1261.5mm |
| Working Temperature Range | 5℃-35℃ |
| Certification | CE |
| After-Sales Service Provided | Video technical support |
| Product Model | BCA-10/20 |
| Power Supply | 3N-380V/425V 50HZ |
| Product Tank | Air |
| Max Temperature Control Range | 5℃~35℃ |
| Product Function2 | RS485 remote communication |
| Product Function3 | Movable type of box body |
| Product Function5 | Industrial level main power switch |
| Selling Units | Single item |
| Single Package Size | 160X81X126.1 cm |
| Single Gross Weight | 160.0 kg |
Product Details
BOBAI Energy Saving Adsorpt Plastic Industrial Small Box Type Water Cooled Chiller
BOBAI Machinery(shanghai)Co,.ltd. set up on Shanghai since the year 2011.We have had over 10 years experience in the business of temperatue control.Our product range is comprised of different ener-gy-efficient temperature-control systems,heat transfer units and water-to water chillers. we provides an extensive portfolio of high-quality temperature control systems based on oil or water as a transfer medium.Cooling units integrated cooling circuit for plastics and die cast processors are chilled by air or water.Heat transfer units can operate with temperature of up to 350 degree .our product mainly used in injection molding,light guide plate,Connector,Chemical Industry,Die-casting,Rubber tire,Extrusion,Ban burying,Calender,Shoes material,Printing and dyeing,stoving etc.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1+ piece: US $3699 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this water cooled chiller?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this water cooled chiller carry?
It is supplied with CE documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the water cooled chiller be supplied for my local voltage?
The standard configuration is 3N-380V/415V 50HZ. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Bobai Machinery (shanghai) Co., Ltd., based in China. The company 10 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Bobai Machinery (shanghai) Co., Ltd. range on HVACR Nexus.
