Water cooled condenser — material Stainless Steel, heat exchanger type Tube Heat Exchanger. The complete factory specification follows. Made by Hangzhou Sino-Cold Sci-Tech Co., Ltd. (1 year on the platform, typical reply ≤2h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Water Cooled Condenser
- Heat Exchange Capacity(Kw): 43.4
- Material: Stainless Steel
- Warranty: 1 Year
- Place Of Origin: Zhejiang, China
- Heat Exchanger Type: Tube Heat Exchanger
- Water Pipe Size: 2-1/2”
Technical Specifications
| Heat Exchanger Type | Tube Heat Exchanger |
|---|---|
| Material | Stainless Steel |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Place Of Origin | Zhejiang, China |
| Weight (Kg) | 100 |
| Brand Name | Enfriar |
| Water Pipe Size | 2-1/2” |
| Water Flow | 11 |
| Packing | Wooden Case |
| Heat Exchange Capacity(Kw) | 43.4 |
| Inlet Pipe | 28 |
| Outlet Pipe | 22 |
| Product Name | Water Cooled Condenser |
| Applicable Industries | Restaurant |
| Showroom Location | South Africa |
| Selling Units | Single item |
| Single Package Size | 93.0X20.0X63.0 cm |
| Single Gross Weight | 68.000 kg |
Product Details
Product Description
The JHSC-20HPB is an industrial-grade shell and tube water-cooled condenser designed for high-efficiency heat exchange in commercial refrigeration and air conditioning systems. It is primarily utilized in water-cooling condensing units for applications like cold rooms, food processing, and chemical factories.
Key Specifications & Performance
This model is engineered to handle high-pressure refrigerant condensation with high thermal efficiency.
Key Specifications & Performance
This model is engineered to handle high-pressure refrigerant condensation with high thermal efficiency.
* Cooling Capacity: Rated at approximately 43.4 kW (or 41.6 kW depending on specific testing standards).
* Physical Dimensions: Typically measures roughly 1280 mm in length.
* Refrigerant Compatibility: Supports a broad range of refrigerants, including R22, R404A, R134a, R507A, R407C, and R410A.
* Refrigerant Compatibility: Supports a broad range of refrigerants, including R22, R404A, R134a, R507A, R407C, and R410A.
* Materials: Constructed with a heavy-duty carbon steel or stainless steel shell enclosing a bundle of internally smooth or
finned copper tubes for enhanced heat transfer.
finned copper tubes for enhanced heat transfer.
* Pressure Rating: Built to withstand refrigerant pressures typically up to 2.5–3.0 MPa.
Key Features
* Maintenance: Features removable water heads or end caps, allowing for mechanical tube brushing and easy scale removal to maintain system performance.
Key Features
* Maintenance: Features removable water heads or end caps, allowing for mechanical tube brushing and easy scale removal to maintain system performance.
* Environmental Adaptability: Available with optional copper-nickel tubes or epoxy coatings for harsh water conditions or
seawater applications (Seaside/Marine models).
seawater applications (Seaside/Marine models).
* Efficiency: Optional internally grooved tubes increase the surface area to accelerate condensation and reduce energy
consumption.
consumption.
Authentic presentation
Specification
item | value |
place of origin | China |
Zhejiang | |
warranty | 1 Year |
video outgoing-inspection | Provided |
machinery test report | Provided |
brand name | Enfriar |
water pipe size | 2-1/2'' |
water flow | 11 |
Packing | Wooden Case |
Heat Exchange Capacity(kw) | 43.4 |
Inlet pipe | 28 |
Outlet pipe | 22 |
Product name | Water Cooled Condenser |
Applicable Industries | Restaurant |
Showroom Location | South Africa |
Company Profile
Hangzhou Sino Cold Sci-tech Co.,Ltd is an one stop solution provider for cold room, specializing in manufacturing and sales of refrigeration equipment and related machinery. Our team has more than ten years of experience in the machinery manufacturing industry. The company’s main products include semi-hermetic piston compressors, scroll compressors, condensing units, condensers, evaporators, industrial humidifier, dehumidifier, ice machine and other related industrial processing machinery. Our products are widely used in freezing and cold storage, fresh food distribution and logistics storage, pharmaceutical industry, food industry, construction and other fields. Our factory has semi-hermetic piston compressor, scroll compressor, screw compressor production lines and condensing unit assembly production lines.Our factory has ISO9001 Certification, we have CQC, CE, Our competitive advantage is to design and produce customized machines to meet different markets’ special demands for all around the world.
"Development by reputation and survival by quality" is the business philosophy that our company has always adhered to. The companyactively creates unique value for customers, and strives to become the world's excellent refrigeration products and service provider. Choose Sino cold, you will get reliable quality and competition price. We are looking forward to building better future
with you, welcome to join us!
"Development by reputation and survival by quality" is the business philosophy that our company has always adhered to. The companyactively creates unique value for customers, and strives to become the world's excellent refrigeration products and service provider. Choose Sino cold, you will get reliable quality and competition price. We are looking forward to building better future
with you, welcome to join us!
Customer Photos
Exhibition
Manufacturing Technique
FAQ
Q: How about the warranty for your products?
A: All of our products have one year warranty. During the guarantee period, if there are any problem with our instrument, we will help you to solve it by sending pictures, videos or free spare parts until things get fixed. Out of guarantee, we will also help you solve the problem,but not including send free spare parts to your country.
Q: Can you do OEM?
A: Yes, we can do OEM/ODM as you required.
Q: Can you offer the technical support, online or site training or other
A:We will offer technical support like operating manual, operating videos to support or provided training material of the detailed products you are interested in.
A:We will offer technical support like operating manual, operating videos to support or provided training material of the detailed products you are interested in.
Q: May I have a free sample? I need test your quality first.
A: We are regret to tell you that we could not offer free sample to our customers, which is our company rule. But if you agree, you can pay sample costs firstly, and we will refund you when you place builk order. we can quote special price to better support you for trail order.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–4 set: US $570 / set
- 5+ set: US $530 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this water cooled condenser?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
