This water cooled industrial chiller is published with the manufacturer’s full specification — 380V/50Hz, 22kW, 36kW, 44kW. Made by Changzhou Xinan Refrigeration Equipment Co., Ltd. (1 year on the platform, typical reply ≤4h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Water Cooled Industrial Chiller
- Model Number: XA–5HP Water Chiller
- Power: 22kW, 36kW, 44kW
- Voltage: 380V/50Hz
- Refrigerant: R22
- Warranty: 1 Year
- Place Of Origin: Jiangsu, China
Technical Specifications
| Voltage | 380V/50Hz |
|---|---|
| Power | 22kW, 36kW, 44kW |
| Refrigerant | R22 |
| Pump Type | Vane Pump |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | Motor |
| Model Number | XA–5HP Water Chiller |
| Place Of Origin | Jiangsu, China |
| Weight (Kg) | 140 |
| Brand Name | XinAn |
| Dimension(L*W*H) | 77*52*250MM |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Model | Pro vertical | Max vertical | Pro Max vertical | External 0.5HP pump | External 1HP pump | ||
Rated voltage and frequency | 380V3N~50Hz | 380V3N~50Hz | 380V3N~50Hz | 380V3~/50Hz | 380V3~/50Hz | ||
Rated cooling capacity (KW) | 22 | 36 | 44 | / | / | ||
Rated heat capacity (optional) | 12 | 12 | 24 | / | / | ||
Rated power (KW) | 4.0 | 5.5 | 8 | 0.79 | 1 | ||
Airflow (m ³/h) | 6000 | 6000 | 12000 | / | / | ||
Rated current (A) | 10.6 | 14.5 | 21.2 | 1.7 | 2.3 | ||
Diameter of water pipe (DN) | 25 | 25 | 40 | 25 | 25 | ||
Energy Efficiency Ratio (COP) | 4.4 | 4.4 | 4.4 | / | / | ||
Weight (kg) | 140 | 143 | 284 | 110 | 110 | ||
Applicable area (m ²) | 120-220 | 200-300 | 300-400 | / | / | ||
Internal machine size (LWH) cm | 77*52*183 | 77*52*183 | 77*52*250 | 80*80*140 | 80*80*140 | ||
A: Yes, we have R&D team for customization. After received ideal/ drawing/samples from client, we will offer our professional solution.
Q2: What can I do if I’m not happy with my product?
A: Please contact us via alibaba at first time. We will offer professional on-line support dependant on the issue.
Q3: How to choose a right model?
A: We support 1HP, 2HP,5HP,10HP etc. different power water chiller produce, please contact us and tell your needs for our
professional recommendation. If you have an experience in using the chiller, you can choose on your own according to the
specification data we provided at product’s detail page.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–9 piece: US $1071.43 / piece
- 10+ piece: US $519.98 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this water cooled industrial chiller?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the water cooled industrial chiller be supplied for my local voltage?
The standard configuration is 380V/50Hz. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Changzhou Xinan Refrigeration Equipment Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Changzhou Xinan Refrigeration Equipment Co., Ltd. range on HVACR Nexus.
