Key specification for this ceiling fan: voltage 220-240V, 380 V, power source Electric. Everything below is reproduced from the factory data sheet. Made by Guangzhou Qixiang Industry Co., Ltd. (12 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Ceiling Fan
- Model Number: HVD-H3000
- Power Source: Electric
- Voltage: 220-240V, 380 V
- Blade Material: Aluminum Alloy
- Material: Aluminum Alloy
- Speed: 120rpm
Technical Specifications
| Fan Type | Axial Fan |
|---|---|
| Blade Diameter | 3M(9.84ft) |
| Voltage | 220-240V, 380 V |
| Speed | 120rpm |
| Bearing Type | Ball Bearing |
| Blade Material | Aluminum Alloy |
| Power Source | Electric |
| Mounting Type | Ceiling Fan, Roof Fan |
| Material | Aluminum Alloy |
| Control Methods | App Control, Touch Control, Button Control, Remote Control |
| Customized Support | OEM, OBM, ODM |
| Warranty | 2 Years |
| After-Sales Service Provided | Online support |
| Place Of Origin | Guangdong, China |
| Brand Name | Qixiang |
| Model Number | HVD-H3000 |
| Color | Silver |
| Product Name | HVLS Ceiling Fan |
| Size | 10FT/3M |
| Blade | 5pcs |
| Motor | PMSSM |
| Package | Wooden Case Packing |
| Certification | CE, RoHS |
| Application | Workshop,warehouse |
| Noise | 39DB |
| Usage | Big Space Cooling |
| Selling Units | Single item |
| Single Package Size | 330X40X40 cm |
| Single Gross Weight | 60.0 kg |
Product Details
– High volume with efficient air flow at low power
– Low cost and free maintenance
– Large application area
-Compact size, light weight
– 5-Blade designed with Aluminum Magnesium Alloy
Specification (Big Sizes)
Model | HVD-H7200 | HVD-B6700 | HVD-B6200 |
Diameter | 7.2m(24ft) | 6.7m(22ft) | 6.2m(20ft) |
Blades Qty | 5 | 5 | 5 |
Weight | 115KG | 113KG | 110KG |
Power | 1.3KW | 1.3KW | 1.3KW |
Max Speed | 55RPM | 60RPM | 65RPM |
Max air Volume | 15197m³/min | 12560m³/min | 10747m³/min |
Voltage | 380V/220V | 380V/220V | 380V/220V |
MAX. Current | 3.1A/4.5A | 3.1A/4.5A | 3.1A/4.5A |
Noise Level | ≤39db | ≤39db | ≤39db |
Permanent magnet servo drive motor | ||
1.IP64, small size, no lubricating oil, low energy consumption, no maintenance, can work for nearly 15 years, beautiful appearance, especially suitable for villas, churches, cafes, restaurants, etc. 2. The motor is designed with high pyrolysis technology and the operating temperature is about 38 °C. 3. internal precision Hall induction digital closed-loop control, can correctly control the switch station, step-less speed change. | ||
Strong mechanical properties, precision measurement to ensure longer life.
stability and security.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–99 set: US $2100 / set
- 100+ set: US $999 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this ceiling fan?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this ceiling fan carry?
It is supplied with CE, RoHS documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the ceiling fan be supplied for my local voltage?
The standard configuration is 220-240V, 380 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Guangzhou Qixiang Industry Co., Ltd., based in China. The company 12 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Guangzhou Qixiang Industry Co., Ltd. range on HVACR Nexus.
