Centrifugal fan — type Air Handling Unit. The complete factory specification follows. Made by SANHE TOP Air Conditioning (Guangdong) Co., Ltd. (5 years on the platform, typical reply ≤1h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Centrifugal Fan
- Warranty: 1 Year
- Place Of Origin: Guangdong, China
- Application: Hotel, School, Mall
- Type: Air Handling Unit
- Mounting Type: Ceiling Mount
- Fan Motors Type: AC/EC
Technical Specifications
| Type | Air Handling Unit |
|---|---|
| Mounting Type | Ceiling Mount |
| Compressor Brand | Hitachi, Daikin |
| Fan Motors Type | AC/EC |
| Application | Hotel, School, Mall |
| Key Selling Points | Eco-Friendly, Automatic, High-Accuracy, Competitive Price, Remote Control, R410A |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | Motor |
| Place Of Origin | Guangdong, China |
| Weight (Kg) | 100 |
| Brand Name | SANHE TOP |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Commercial Rectangle Centrifugal Fan Box High Efficiency Low Noise Ventilation Exhaust System
| Name | Box Air Ventilation System |
| Voltage | 380 V, 415 V, 220 V, 575V 50Hz/60Hz |
| Power | 50KW,100kW, 150KW, 200 kW,250kW |
| Air Flow | 1500/3000/3500/4300/10000 m³/h |
| Usage | HVAC system |
| Model | Air Flow Rate | Static Pressure | Sound Power | Fan Wheel | Motor used | Voltage | |||||
| Nonimal | Range | Nominal | High | Motor Inbuilt (I) | Motor External(E) | Dia. | Qty | Nominal | High | ||
| CMH | Pa | dB(A) | MM | KW | |||||||
| TPK-H-2.2-BF-D1 | 2200 | 900~2200 | 150 | / | 58 | / | 250 | 1 | 0.18 | / | 220V 1PH 50Hz |
| TPK-H-2.2-BF-D2 | 2200 | 900~2200 | 200 | / | 58 | / | 250 | 1 | 0.23 | / | |
| TPK-H-2.2-BF-D3 | 2500 | 1200~2500 | 200 | / | 58 | / | 250 | 1 | 0.23 | / | |
| TPK-H-3.5-BF | 3500 | 2500~4400 | 300 | / | 60 | 61 | 250 | 1 | 0.75 | / | 380V 3PH 50Hz |
| TPK-H-6.2-BF | 6200 | 4600~7800 | 350 | / | 62 | 63 | 321 | 1 | 1.5 | / | |
| TPK-H-9.0-BF | 9000 | 7800~10200 | 400 | / | 63 | 64 | 381 | 1 | 2.2 | / | |
| TPK-H-12-BF | 12000 | 10000~14000 | 400 | / | 65 | 66 | 460 | 1 | 3 | / | |
| TPK-H-17-BF | 17000 | 13800~21000 | 400 | 700 | 66 | 67 | 508 | 1 | 4 | 7.5 | |
| TPK-H-22-BF | 22500 | 18800~26000 | 450 | 700 | 67 | 68 | 558 | 1 | 5.5 | 11 | |
| TPK-H-30-BF | 30500 | 25000~36000 | 450 | 700 | 68 | 69 | 635 | 1 | 7.5 | 11 | |
| TPK-H-40-BF | 40000 | 35000~45000 | 500 | 700 | 69 | 70 | 698 | 1 | 11 | 15 | |
| TPK-H-51-BF | 51000 | 43000~58000 | 500 | 700 | 71 | 72 | 762 | 1 | 15 | 18.5 | |
The TPK-BF series box-type ventilator adopts a forward-curved multi-blade double-inlet centrifugal fan, which is dynamically and statically balanced, resulting in high efficiency, smooth operation, and low noise. The box structure is robust, and the inner and outer surfaces are powder-coated, providing excellent corrosion resistance and rust prevention.
Construction &External Dimension BF
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–1 set: US $1200 / set
- 2+ set: US $1000 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal fan?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by SANHE TOP Air Conditioning (Guangdong) Co., Ltd., based in China. The company 5 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full SANHE TOP Air Conditioning (Guangdong) Co., Ltd. range on HVACR Nexus.
