Air Heater, 0000kcal, 400, 0000kcal/h

Air heater — 220V/380V, 50HZ(Arbitrary), power 0.7mw/h ~ 7mw/h. The complete factory specification follows. Made by Henan Yuji Boiler Vessel Co., Ltd. (6 years on the platform, typical reply ≤2h). For a binding price and lead time, send the volume you need and where it ships to.

Key Features of This Air Heater

• Power: 0.7mw/h ~ 7mw/h
• Power Supply: 220V/380V, 50HZ(Arbitrary)
• Material: Stainless Steel, Carbon Steel
• Warranty: 2 Years
• Place Of Origin: Henan, China
• Type: Natural Circulation

Technical Specifications

Product Details

Product Overview

Coal Wood Biomass Fired Industrial Hot air Heater Manufacturer (10 0000kcal to 400 0000kcal/h)

DZH series boiler is designed with single drum boiler with fire tube and water pipe. It has fast heat conduction, fast rise of steam pressure, movable grate as combustion equipment, and manual or mechanical fuel delivery mode.It is flexible and controllable by human beings. It is suitable for direct combustion of biomass of various shapes and has strong adaptability to fuel.

Steam volume: 0.5t/h~10t/h Steam pressure: 4-25 bar (0.4-2.5Mpa) optional Steam temperature: 150 ℃ -226 ℃ Fuel: Wood, palm shells, sugarcane bagasse, corn cobs, coconut shells, rice husks, peanut shells, tree branches, coal, cloth strips, and all other combustible materials. Application areas: Steam and heating demand in industries such as food industry, sugar processing, coffee processing, textile, printing and dyeing, pharmaceuticals, building materials, breweries, rubber, chemical industry, etc. It is also used for centralized heating and daily production in hospitals, hotels, schools, etc.

Thermal power: 300000-600000 Kcal (350-7000kw) Pressure: 0-16bar (0-1.6Mpa) optional Hot water temperature: 95-130 ℃ Fuel: Wood, palm shells, sugarcane bagasse, corn cobs, coconut shells, rice husks, peanut shells, tree branches, coal, cloth strips, and all other combustible materials. Application: Heating in residential areas, workplaces, hotels, schools, hospitals, industrial and domestic hot water supply, etc

PRODUCT SPECIFICATIONS

DZH Steam Boiler

Model

Rated evaporation(t/h)

Rated pressure(MPa)

Steam temperature(℃)

thermal efficiency (%)

Fuel consumption (kg/h)

Size L×W×H (m)

Weight(t)

DZH 1-0.7/1.0-AII

1

0.7/1.0

193/204

≥83

176.6

4.3×1.9×2.9

13.6

DZH 2-1.0/1.25-AII

2

1.0/1.25

193/204

≥83

352.3

5.14×2.5×3.1

18

DZH 3-1.25/1.6-AII

3

1.25/1.6

193/204

≥83

522.5

5.63×2.7×3.3

23

DZH 4-1.25/1.6-AII

4

1.25/1.6

193/204

≥83

697

5.92×2.7×3.5

25.3

DZH 6-1.25/1.6-AII

6

1.25/1.6

193/204

≥83

1044

6.2×3.0×3.58

31

DZH 8-1.25/1.6-AII

8

1.25/1.6

193/204

≥83

1396

6.8×3.4×3.6

34

DZH 10-1.25/1.6-AII

10

1.25/1.6

193/204

≥83

1744

7.5×3.4×3.7

39

DZH Hot Water Boiler
Model	Rated power(mw)	Rated pressure(MPa)	thermal efficiency (%)	Fuel consumption (kg/h)	Water supply temperature(℃)	Return water temperature(℃)	Weight(t)
DZH0.7-0.7/95/70	0.7	0.7	≥83	174.3	95	70	13.6
DZH1.4-1.0/95/70	1.4	1	≥83	348.6	95	70	18
DZH2.1-1.0/95/70	2.1	1	≥83	517	95	70	23
DZH2.8-1.0/95/70	2.8	1	≥83	687.2	95	70	25.3
DZH4.2-1.25/95/70	4.2	1.25	≥83	1023.8	95	70	31
DZH5.6-1.25/115/70	5.6	1.25	≥83	1374	95	70	34
DZH7-1.25/115/70	7	1.25	≥83	1708	95	70	39

Company Profile

Henan Yuji Boiler Vessel Co.,Ltd.

A state-authorized exporter of industrial boilers & pressure vessels.18,000 ㎡ factory, 70+ engineers, ISO 9001 & CE certified.27 QC procedures & 63 inspections ensure reliable quality.24/7 after-sales support.One-stop solutions: design, production, installation, retrofit & maintenance

Henan Yuji Boiler Vessel Co., Ltd. serves customers worldwide, with products exported to more than 90 countries and regions.We warmly welcome mutually beneficial cooperation, whether you intend to become our distributor or have specific OEM/ODM requirements.Choose Yuji Boiler as your trusted partner and unlock the full potential of your industrial

operations.

Project Case

FAQ

Q. Are you manufacturer?
A: Yes, we are professional manufacturer of boiler and pressure vessels in Henan, China.

Q: Do you have any Certificate?
A: Yes. Our boiler have got China GB ISO certificates and CE certificate of EU. We also can provide ASME, GHOST and other necessary certificates if you need.

Q: How can I pay you?
A: T/T, Western Union, Money Gram and Ali Trade Assurance is better.

Q: What about the delivery time?
A: 5-10 working days for single machine, and 30-40 working days for bulk order and door to door delivery service is also
available.

Q. What about the warranty?
A: We provide 1 year warranty for free and life-long time maintenance

Q. What about installation?
A: We provide 1 or 2 technicians overseas services for installation, debugging and training.

Q. What about the boiler fuel?
A: We provide boiler can use coal, charcoal, wood, rice husk, straw, biomass pellet, diesel, light oil, natural gas, city gas,
liquefied gas etc.

Ordering and Pricing

• Minimum order quantity: 1 set
• Volume pricing:
  • 1+ set: US $5000 / set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this air heater?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.

Can the air heater be supplied for my local voltage?

The standard configuration is 220V/380V, 50HZ(Arbitrary). Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
