Air handling unit — model number FCU/FP. The complete factory specification follows. Made by Guangdong Head-Power Air-Conditioning Co., Ltd. (18 years on the platform, typical reply ≤15h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Air Handling Unit
- Model Number: FCU/FP
- Warranty: 1 Year
- Place Of Origin: Guangdong, China
- Application: Hotel, Apartment, Office Building, Hospital, Mall, Sports Venues, Supermarket, Park, Farmhouse
- Design Style: Industrial
- After-Sale Service: Free Spare Parts, Online Technical Support
Technical Specifications
| Application | Hotel, Apartment, Office Building, Hospital, Mall, Sports Venues, Supermarket, Park, Farmhouse |
|---|---|
| Design Style | Industrial |
| Warranty | 1 Year |
| After-Sale Service | Free Spare Parts, Online Technical Support |
| Project Solution Capability | graphic design |
| Model Number | FCU/FP |
| Place Of Origin | Guangdong, China |
| Brand Name | Head-Power |
| Color | Customized |
| Public Places | Airports, stations, exhibition halls, stadiums, museums |
| Air Volume | 200~1400CFM, 340~2380m3/h |
| Packaging Details | Specifications subject to changes without prior notice. |
| Selling Units | Single item |
| Supply Ability | 5 sets per Week |
Product Details
Specifications:
Specifications:
| Model |
| PWD20-4H | |
| Air Flow(return air) | m3/h | 2000 | |
| External Static Pressure | Pa | 100 | |
| Power supply |
| 380V/3PH/50Hz | |
| Filter | Prefilter |
| Washable plate nylon mesh filter |
|
Cooling/Heating coil | Total/sensible capacity | kW | 12.65/8.83 |
| Heating capacity | kW | 20.93 | |
| Type |
| Copper tubes with aluminium fins | |
| Fluid |
| Chilled water/Hot water | |
| Inlet/outlet water temp. | ℃ | 7 / 12℃ | |
| Coil rows |
| 4 | |
| Water flow | m3/h | 2.2 | |
| Pipe connection | mm | DN32 | |
| Supply fan | Type |
| DIDW, centrifugal type |
| Air volume | m3/h | 2000 | |
| External static pressure | Pa | 100 | |
| Motor power | kW | 0.55 | |
| Drive method |
| Direct drive | |
| Noise level | dB(A) | 56 | |
| Dimensions(L*W*H) | mm | 890*900*510 | |
| Net weight | kg | 130 | |
Description:
1. Frame and panel: Aluminium alloy fram, anti cold bridge design; painted galvanized steel or color steel panel.
2. Fan system: DIDW backward or forward curved blade centrifugal fan; Impeller, shaft and casing have service lifespan for not less than 15years under normal condition; low running noise, high efficiency, finish dynamic balance test for delivery.
3. Motor: famous brand good quality motor, insulation class F. Belt drive, high quality V-shaped belt, anti vibration rubber or spring damper, reduce vibration transmission.
4. Chilled water/hot water coil: Copper tubes with aluminium fins. All coils are designed with CAD software, calculation as per flow speed, with excellent heat exchange effect. Galvanized steel framework, high durability. All coils are tested by 2.5MPa air pressure leak test.
5. Drain pan: Suitable slope drain pan, easy for water drainage, stainless steel or painted galvanized steel material. All pans have done leakage and pressure test.
6. Cooling condition: Return air DB 27℃, WB 19.5℃, Inlet water temperature 7℃, water diff. 5℃;
Heating condition: Return air DB 21℃, Inlet water temperature 60℃
Advantages:
1. 25mm Color steel panel or single skin galvanized steel panel are offered according to different requirements;
2. Fresh air condition and return air condition type for choice;
3. Various structure available: ceiling mounted, floor standing type, top discharge, back discharge,etc. Can be designed according to client’s requirements.
4. Large air volume units are available.
5. Cooling coil rows: 4/6/8 rows, designed according to capacity.
Applications:
1. Commercial buildings: Star hotels, restaurants, office buildings, schools, supermarkets, shopping mall, entertainment centers,theaters,etc
2. Industrial field: Electronic factory,pharmaceutical factory, precision instrument factory,petrochemical factory,tobacco factory, cooling for production process, etc.
3. Public places: Airports, stations, exhibition halls, stadiums, museums, convention centers, church,etc
1. We can provide OEM service for customers.
2. We produce according to customers' requirements.
3. Factory visitting.
4. General testing and operational test carried out for every unit before delivery.
How about the quality of your product? — Our products manufactured strictly according to national and international standard. — We have CE ,ISO certification — We take a test on every product before delivery.
How about price of this product?
— We can give the lowest price than market one. — We do quotation as soon as possible for any customer. — Discount can be given according to quantity.
What is the MOQ?
— 1 set.
Can you do custom-made machines? — We can make products according to customer's requirements.
What is the voltage and refrigerant?
— standard chiller usual use 380V/3phase/50HZ and refrigerant. — Custom-made chiller use other voltage and refrigerant by according to client's requirement.
1. Payment Terms:
T/T – 30% deposit before production,70% balance before delivery, or other terms
2. Delivery Detail:
About 30 workdays after payments.
3.Pacage Terms:
International Standard Wooden Case for Export.
Ordering and Pricing
- Minimum order quantity: 2 set
- Volume pricing:
- 2+ set: US $500 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air handling unit?
The standard minimum order quantity is 2 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
