This air cooled scroll chiller is published with the manufacturer’s full specification — voltage 3PH 220V~460V 50HZ/60HZ, air flow 11160m³/h. Made by Dongguan Dingyuan Industrial Co., Ltd. (9 years on the platform, typical reply ≤3h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Air Cooled Scroll Chiller
- Power: 8.73
- Compressor Power: 7.5KW/10HP
- Voltage: 3PH 220V~460V 50HZ/60HZ
- Water Tank Capacity: 200L
- Air Flow: 11160m³/h
- Refrigerant Type: R22/R407C/R134/R410
Technical Specifications
| Voltage | 3PH 220V~460V 50HZ/60HZ |
|---|---|
| Power | 8.73 |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Easy To Operate |
| Core Components | Motor, Pump, Compressor, PID |
| Place Of Origin | Guangdong, China |
| Weight (Kg) | 420 |
| Brand Name | Ding Yuan |
| Dimension(L*W*H) | 1420*800*1500mm |
| Working Temperature Range | 0~45°C |
| Product Name | Air Cooled Chiller |
| Application | Industrial Cooling Solutions |
| Keyword | Air Chiller System |
| Compressor Power | 7.5KW/10HP |
| Refrigerant Type | R22/R407C/R134/R410 |
| Air Flow | 11160m³/h |
| Water Tank Capacity | 200L |
| Running Current | 15.7AMP |
| Controller | PID Controller |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Model | DY-FSC10A |
Cooling capacity | 29KW |
Refrigerant type | R22/R407/R134/R410 |
Compressor power | 7.5KW |
Air flow | 11160M³/H |
Fan diameter | 450*2MM |
Voltage | 3PH 220V~460V 50HZ/60HZ |
Water tank capacity | 200L |
Pump power | 0.75KW |
Pump head | 18M |
Flow rate | 250L/MIN |
Running current | 15.7AMP |
Total input power | 8.73KW |
Insulation material | Poly-foam tape rubberized tubu insulation |
Dimension | 1420*800*1500MM |
Net weight | 420KG |
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–9 piece: US $4500 / piece
- 10+ piece: US $3500 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air cooled scroll chiller?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the air cooled scroll chiller be supplied for my local voltage?
The standard configuration is 3PH 220V~460V 50HZ/60HZ. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Dongguan Dingyuan Industrial Co., Ltd., based in China. The company 9 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Dongguan Dingyuan Industrial Co., Ltd. range on HVACR Nexus.
