Key specification for this air heater: 42500m3/h, 9.1kw. Everything below is reproduced from the factory data sheet. Made by Qingzhou Ventimax Equipment Co., Ltd. (12 years on the platform, typical reply ≤3h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Air Heater
- Power: 9.1kw
- Operating Voltage: 380v
- Airflow: 42500m3/h
- Warranty: 1 Year
- Warranty Of Core Components: 1 Year
- Place Of Origin: Shandong, China
Technical Specifications
| Type | Air heater |
|---|---|
| Airflow | 42500m3/h |
| Operating Voltage | 380v |
| Mounting Type | Floor Standing |
| Key Selling Points | Easy To Operate |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | Motor |
| Place Of Origin | Shandong, China |
| Weight (Kg) | 2600 KG |
| Brand Name | Ventimax |
| Dimension(L*W*H) | 2920*1300*2600 |
| Product Name | coal burning heater |
| Function | heating |
| Application | poultry farm/warehouse/greenhouse |
| Keyword | air heater |
| Power | 9.1kw |
| Brand | Ventimax |
| Size | 2920*1300*2600mm |
| Heating Area | 2400m2 |
| Hot Air Temperature | 80-150 |
| Heat Output | 400000kcal/h |
| Condition | New |
| Warranty Of Core Components | 1 Year |
| Applicable Industries | Farm/Greenhouse/Warehouse |
| Packaging Details | standard package |
| Port Of Dispatch | Qingdao Port |
| Selling Units | Single item |
| Single Package Size | 125X125X185 cm |
| Single Gross Weight | 50.000 kg |
Product Details
WHY CHOOSE US
* Effects of combustion chamber heightening design,with long service life
*All stainless steel dust collector, convenient for dust removal and higher efficiency
* Design of insulation three return ,the heat loss is reduced to the minimum
* the high thermal efficiency of 90%
* The unique 20mm wall thickness of heat resistant cast steel pipe,ensure the combustion
ten years without deformation
* All the indicators have reached the national first-class regional environmental standards
Technical model | Heat output(kcal/h) | Hot air temperature(degree) | Consume of fuel(kg/h) | Power(kw) | Size(mm) | weight(kg) | Heating area(m2) |
HYMR-5 | 50000 | 80-150 | 5-10 | 1.87 | 1250*800*1850 | 750 | 300 |
HYMR-10 | 100000 | 80-150 | 10-20 | 3.55 | 2030*950*2040 | 1150 | 600 |
HYMR-20 | 200000 | 80-150 | 30-40 | 5.15 | 2450*1250*2280 | 1700 | 1200 |
HYMR-30 | 300000 | 80-150 | 40-50 | 6.75 | 2720*1250*2600 | 2400 | 1800 |
HYMR-40 | 400000 | 80-150 | 50-60 | 9.1 | 2920*1300*2600 | 2600 | 2400 |
years.As a high-tech enterprise, we have a completed set of engineering design,manufacturing, installation and services.Both of the product capacity and technology are in the first place of the industry.The main products include: exhaust fans for greenhouse,poultry and factory buildings, circulation fans, no power roof fan, cooling humidification system(cooling pad), heating system(coal, electric, gas heaters), manure cleaning systems. The products have sold well in more than 20 provinces and cities of domestic market, and have exported to Southeast Asia, Middle East, Europe and other countries and regions. The products gained good reputation by the customers at home and abroad. We have been awarded the title of Ten Top SelI-Well Brands Fan of China, Quality Faith and Consumer Trust Unit of China AAA Levels of Quality and Honesty Member Unit.
A: We have factory with more than 10 years experience.
Q: What voltages you can do , if you can make special voltages ?
A: Almost all kinds of voltages we all can make , but for special voltages ,
we have a big MOQ and maybe price will be a little higher . Our normal voltage is 380V 50HZ 3phase .
Q: I want to use our own brand , is it ok?
A: Of course it's OK , we can make OEM products and also can provide our own brand products
Q:What payment term ?
A:Normally T/T or L/C we can accept .
Q:When you ship my order?
A:Normally 7-15days after receiving your payment, but it can be negotiated based on order qty and production schedule.
Q:How about the warranty?
A:All the unit we have one year warranty .
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–99 set: US $7400 / set
- 100+ set: US $1470 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air heater?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the air heater be supplied for my local voltage?
The standard configuration is 380v. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Qingzhou Ventimax Equipment Co., Ltd., based in China. The company 12 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Qingzhou Ventimax Equipment Co., Ltd. range on HVACR Nexus.
