Key specification for this blast freezer: 380V 50HZ, 1.5kw. Everything below is reproduced from the factory data sheet. Made by Tianjin Sure International Trading Co., Ltd. (16 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Blast Freezer
- Power(W): 1.5kw
- Voltage: 380V 50HZ
- Output Capacity: 1080-1224kg per batch
- Material Of Plates: Aluminum-alloy
- Material Of Panel Sheets: Stainless steel
- Refrigerant: R404A
Technical Specifications
| Type | Plate Freezer |
|---|---|
| Temperature Control | -40℃ to 0℃ |
| Voltage | 380V 50HZ |
| Warranty | 12 Months |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | PLC |
| Key Selling Points | High-Accuracy |
| Power(W) | 1.5kw |
| Place Of Origin | Tianjin, China |
| Weight (Kg) | 1250 |
| Brand Name | SURE |
| Dimension(L*W*H) | Customized |
| Output Capacity | 1080-1224kg per batch |
| Freezing Time Per Batch | Approx. 3.5 hours |
| Plate Pitch | 98mm-138mm |
| Plate Size | 1417mm*1600mm |
| Application | Meat |
| Refrigerant | R404A |
| Material Of Plates | Aluminum-alloy |
| Material Of Panel Sheets | Stainless steel |
| Compressor | BITZER 28HP*2 sets |
| Condenser | Water cooled or air cooled |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Horizontal fish plate shrimp quick machine contact freezer
Model:PF-H Series | Plate Qty | Plates Pitch | Plates Size | Dimension | Eva.Area |
PF-H-720 | 9 | 58-108mm | 1290*1260mm | 2710*1750*1685mm | 30㎡ |
PF-H-960 | 9 | 58-108mm | 1680*1260mm | 3130*1750*1685mm | 40㎡ |
PF-H-1200 | 11 | 58-108mm | 1680*1260mm | 3130*1750*1945mm | 49㎡ |
PF-H-1500 | 11 | 58-108mm | 2080*1260mm | 3540*1750*1945mm | 60㎡ |
PF-H-1950 | 14 | 58-108mm | 2080*1260mm | 3540*1750*2335mm | 76㎡ |
PF-H-2520 | 14 | 58-108mm | 2530*1260mm | 3780*1750*3305mm | 91㎡ |
Product Features:
Customized Design Service
* Customized design equipment according to floor plan
* Equipment technical consultation service
Installation & Commissioning Service
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1+ set: US $10000 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this blast freezer?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 12 Months warranty. Spare parts and technical support remain available after the warranty period.
Can the blast freezer be supplied for my local voltage?
The standard configuration is 380V 50HZ. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Tianjin Sure International Trading Co., Ltd., based in China. The company 16 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Tianjin Sure International Trading Co., Ltd. range on HVACR Nexus.
