Key specification for this blower: 12V/24V, blade material Aluminum Alloy. Everything below is reproduced from the factory data sheet. Made by Dongguan Kuhong Electronics Co., Ltd. (8 years on the platform, typical reply ≤5h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Blower
- Model Number: CM43190-PA
- Voltage: 12V/24V
- Rated Voltage: 12V/24V Optional
- Blade Material: Aluminum Alloy
- Material: Aluminum Alloy
- Speed: 2600rpm
Technical Specifications
| Voltage | 12V/24V |
|---|---|
| Speed | 2600rpm |
| Mounting | Free Standing |
| Blade Material | Aluminum Alloy |
| Material | Aluminum Alloy |
| Customized Support | OEM, ODM, OBM |
| After-Sales Service Provided | Online support |
| Warranty | 1 Year |
| Place Of Origin | Guangdong, China |
| Brand Name | coolcom |
| Model Number | CM43190-PA |
| Application | HVAC |
| Motor Type | BLDC Motor |
| OEM /ODM | Acceptable |
| Keywords | Tangential Blower Fan |
| Bearing Type | NMB Ball Bearing |
| Function | FG PWM |
| Rated Voltage | 12V/24V Optional |
| Insulation Class | Class B |
| Noise | 37dBA |
| Selling Units | Single item |
| Single Package Size | 120X11X11 cm |
| Single Gross Weight | 2.000 kg |
Product Details
| MODEL | SIZE (MM) | BEARING TYPE | RATED VOLTAGE (V) | CURRENT (A) | SPEED (RPM) | AIR FLOW (M3/H) | PRESSURE (PA) | NOISE (DB) | WEIGHT (G) |
|---|---|---|---|---|---|---|---|---|---|
| CM43090HB12-PA | A=150 B=108 C=98 | BALL*3 | 12 | 0.28 | 2600 | 63 | 14 | 36 | 210 |
| CM43090HB12-PA | A=150 B=108 C=98 | BALL*3 | 24 | 0.12 | 2600 | 63 | 14 | 36 | 210 |
| CM43150HB12-PA | A=212 B=170 C=160 | BALL*3 | 12 | 0.32 | 2600 | 85 | 15 | 36 | 260 |
| CM43150HB24-PA | A=212 B=170 C=160 | BALL*3 | 24 | 0.16 | 2600 | 85 | 15 | 36 | 260 |
| CM43190HB12-PA | A=250 B=208 C=198 | BALL*3 | 12 | 0.36 | 2600 | 105 | 15 | 37 | 300 |
| CM43190HB24-PA | A=250 B=208 C=198 | BALL*3 | 24 | 0.18 | 2600 | 105 | 15 | 37 | 300 |
| CM43250HB12-PA | A=302 B=260 C=250 | BALL*3 | 12 | 0.43 | 2600 | 133 | 16 | 37 | 490 |
| CM43250HB24-PA | A=302 B=260 C=250 | BALL*3 | 24 | 0.24 | 2600 | 133 | 16 | 37 | 490 |
| CM43290HB12-PA | A=352 B=310 C=300 | BALL*3 | 12 | 0.46 | 2600 | 160 | 17 | 38 | 530 |
| CM43290HB24-PA | A=352 B=310 C=300 | BALL*3 | 24 | 0.27 | 2600 | 160 | 17 | 38 | 530 |
| CM43350HB12-PA | A=400 B=358 C=348 | BALL*3 | 12 | 0.50 | 2600 | 185 | 18 | 39 | 570 |
| CM43350HB24-PA | A=400 B=358 C=348 | BALL*3 | 24 | 0.29 | 2600 | 185 | 18 | 39 | 570 |
| item | cross flow fan |
| Blade Material | aluminum |
| voltage | 12V/24V |
| mounting | FREE STANDING |
| speed | 2400rpm |
| customized support | OEM, ODM, OBM |
| place of origin | China |
| brand name | coolcom |
| warranty | 1 Year |
| After-sales Service Provided | Online support |
| Material | Aluminum Alloy |
Dimensions
Fan Performance Curve
1. coolcom cross flow fans with high air flow value and very good noise characteristics . Application areas:building Radator, air purifier, Stove jacket cooling, thermal storage heaters, overhead projectors, tanning beds, air-conditioning and heating units. with long life span more than 60Khours when operated in room temperature,also compatible with a high operating temperature.
Based in 2011, DONGGUAN KUHONG ELECTRONICS CO.,LTD is a distinguished manufacturer of cross flow fans, centrifugal fans, pipeline fans, brushless dc motors, and EC motors. Promoting our own branded product, 'COOLCOM FAN', we provide full support for OEM&ODM. The products are widely utilized in HVAC, ventilation, heating, air conditioning&refrigeration, home appliance, and varied industries.We're here to support your inquiries and provide customized solutions on motor and fan products. Connect with us!
1. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
2.what can you buy from us?
cross flow fan,centrifugal fan,ec fan,axial fan,dc motor
3. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW;
Accepted Payment Currency: USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,PayPal;
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–499 piece: US $29.9 / piece
- 500–999 piece: US $18.5 / piece
- 1000+ piece: US $17.5 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this blower?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the blower be supplied for my local voltage?
The standard configuration is 12V/24V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
